Title: Water Purification


1
(No Transcript)
2
Purification of Water
  • Dr. Jawaid Hussain
  • Deptt of Community Medicine
  • Assistant Professor
  • Peoples Medical University of Health Sciences
    Nawabshah

3
Learning Objectives
  • The participant will be able to define
  • Purification of Water.

4
Purification Of Water
  • Purification of is done by TWO ways
  • Natural Methods
  • Artificial Methods

5
NATURAL METHODS
  • Natural Method includes-
  • Aeration
  • Sedimentation
  • Sunlight
  • Dilution
  • Oxidation
  • Plants Animals (Aquatic)

6
Artificial Methods
  • They may be carried out at
  • Purification of Water on Large Scale
  • Purification of Water on Small Scale

7
A. Purification of Water on Large Scale
  • At Large scale, it is done by Filtration, which
    may be
  • Slow sand filtration
  • Rapid sand filtration
  • Desalination

8
B. Purification of Water on Small Scale /
Domestic Level
  • At Small scale or Domestic level, is carried out
    by
  • Boiling
  • Chemical disinfection
  • Filtration
  • Solar radiation

9
A. Purification of Water on Large Scale
  • The purpose of water treatment is to produce
    water that is safe wholesome.
  • The method of treatment to use depends upon the
    nature of raw water the desired standards of
    water quality.
  • Ex Ground water (wells springs) may need no
    treatment other than disinfection.
  • Surface water (e.g River water) which tends to
    be turbid polluted, require extensive
    treatment.
  • The components of a typical water purification
    system comprise one or more of the following
    measure.

10
A. Purification of Water on Large Scale
  • A typical water supply carries the following
  • steps in Purifying the water
  • Storage
  • Sedimentation
  • Filtration
  • Disinfection

11
I. STORAGE
  • Water is drawn out from the source and impounded
    in natural or artificial reservoirs.
  • Storage provides of a reserve of water from which
    further pollution is excluded.
  • As a result of storage, a very considerable
    amount of purification takes place.
  • This natural purification we may look at it
    from three points of view

12
I. STORAGE
  • Physical
  • By mere storage the quality of water improves.
  • About 90 of the suspended impurities settle down
    in 24 hours by gravity.
  • The water becomes clearer.
  • This also improves the turbidity of water.
  • This allow penetration of light reduce the work
    of filters.

13
I. STORAGE
  • (b) Chemical
  • Certain chemical changes also take place during
    storage.
  • The aerobic bacteria oxidize the organic matter
    present in the water with the aid of dissolved
    oxygen.
  • As a result the content of free ammonia is
    reduced and a rise in nitrates occurs.

14
I. STORAGE
  • (c) Biological
  • A tremendous drop takes place in bacterial count
    during storage due to antibiosis and oxidation.
  • The pathogenic organism gradually die out.
  • It is found that when river water is stored the
    total bacterial count drops by as much as 90
    percent in the first 5-7 days.
  • This is one of the greatest benefits of storage.
  • The optimum period of storage of river water is
    considered to be about 10-14 days.

15
I. STORAGE
  • (c) Biological
  • If the water is stored for long periods, there is
    likelihood of development of vegetable growths
    such as algae which impart a bad smell and colour
    to water.

16
II. SEDIMENTATION
  • Here we add chemical coagulant Alum.
  • ALUM AL2(So4)3
  • The Dose is 35 mg/Litre is kept for 4 6
    hours. It is very necessary.
  • Prior to filtration and helps in Preventing the
    Rapid Clogging of filter.
  • The reaction is-
  • Al2 (So4)3 Ca (Hco3) ? Al(OH)3 6Co2 CaSo4
  • 2) Al2(So4)3 3Na2Co3 H2O ? 3NaSo4 2Al
    (OH)3 3Co2

17
III. FILTRATION
  • It is the oldest and Universal method of
    purification.
  • Filtration is the second stage in the
    purification of water.
  • This filtration reduces the bacterial content by
    98-99, turbidity by 50 PPM to 5 PPM and colour
    to colurless.

18
III. FILTRATION
  • There are two types of Filters
  • SLOW SAND FILTERATION (BIOLOGICAL FILTER).
  • RAPID SAND FILTERS ( MECHANICAL FILTERS).

19
SLOW SAND FILTRATION (BIOLOGICAL FILTER)
  • They are cheap and easy to design and occupy less
    space.
  • Slow sand filters were first used for water
    treatment in 1804 in Scotland and subsequently in
    London.
  • During the19th century their use spread
    throughout the world.
  • Even today they are generally accepted as the
    standard method of water purification.

20
SLOW SAND FILTRATION (BIOLOGICAL FILTER)
  • They contain the concrete made basin, which
    contains the selected graded sand, supported on
    stones. The contents are
  • Supernatant Water Head 1 1.5 meter for Raw
    Water
  • Sand Bed, which consists of sand particles,
    supported by fine and coarse gravel.
  • Drainage system
  • Filter Control Valve

21
1) SUPERNATANT WATER HEAD
  • The supernatant water above the sand bed, whose
    depth varies from 1 to 1.5 meter, serves two
    important purpose.
  • 1. It provides a constant head of water so as to
    overcome the resistance of the filter bed
    thereby promote the flow of water through the
    sand bed.
  • 2. It provides waiting period of some hours (3
    to 12 hours) for the raw water to undergo partial
    purification by sedimentation, oxidation
    particle agglomeration. The level of supernatant
    water is always kept constant.

22
2. SAND BED
  • It is very important part of the sand bed.
  • The thickness of the sand bed is a about 1 meter.
  • The sand grains are carefully chosen so that they
    are preferably rounded and have an effective
    diameter b/w 0.2 to 0.3 mm.
  • The sand should be clean and free from clay
    organic matter.
  • The sand bed is supported by a layer of graded
    gravel 30 to 40 cm deep which prevents the fine
    grain being drained into the drainage pipes.

23
2. SAND BED
  • The sand bed presents a vast surface area, one
    cubic meter of filter sand presents some 15,000
    sq.meter of surface area.
  • Water percolates the through the sand bed very
    slowly, process taking 2 hours or more.
  • It is subjected to a number of purification
    processes- mechanical straining, sedimentation,
    adsorption, oxidation bacterial action, all
    playing their part.
  • The designed rate of filtration of water usually
    lies b/w 0.1 to 0.4 m3/ hour/ per square meter of
    sand bed surface.

24
2. SAND BED
  • Vital Layer/ (Biological Filter)
  • When the filter is newly laid, it acts merely as
    a mechanical strainer can not truly be
    considered as Biological.
  • But very soon the surface of the sand bed gets
    covered with a slimy growth known as
    Schmuztadecke Vital Layer Zoogleal layer or
    Biological Layer.
  • This layer is slimy gelatinous and consist of
    threadlike algae and numerous forms of life
    including plankton, diatoms and bacteria.

25
2. SAND BED
  • The formation of vital layer is known as
    ripening of the filter.
  • It may take several days for the vital layer to
    form fully and when fully formed it extends for
    2-3 cm into the top portion of the sand bed.
  • The vital layer is the heart of the slow sand
    filter.
  • It removes organic matter, holds back bacteria
    and oxidizes ammoniacal nitrogen into nitrates
    and helps in yielding bacteria-free water.
  • Un till the vital layer is fully formed, the
    first few days filtrate is usually run to waste.
  • It is Scrapped, when it becomes thick.

26
3. UNDER-DRAINAGE SYSTEM
  • At the bottom of the filter bed is the
    under-drainge system.
  • It consist of porous or perforated pipes which
    serve the dual process of providing an outlet for
    filtrated water and supporting the filter medium
    above.
  • Once filter bed been laid, the under-drainage
    system can not be seen.

27
FILTER BOX
  • The filter box is an open box, usually
    rectangular in shape, from 2.5 to 4 meters deep
    is bulit wholly or partly below ground.
  • The walls may be made of stone, brick or cement.
  • The filter box consist from top to bottom
  • 1.Supernatant water 1 to 1.5 meters.
  • 2. Sand Bed 1.2 meters
  • 3. Gravel Support 0.30 meter
  • 4. Filter bottom 0.16 meter

28
4. FITER-CONTROL
  • Filter control is equipped with certain valves
    and devices which are incorporated in the
    outlet-pipe system.
  • The purpose of these devices is to maintain a
    constant rate of filtration.

29
FITER-CLEANING
  • Naturally the filter may run for weeks or even
    months without cleaning.
  • When the bed resistance increases to such extent
    that the regulating valve has to be kept open
    fully.
  • It is time to clean filter bed, since any further
    increase in resistance is bound to reduce the
    filtration rate.
  • At this stage supernatant water is drained off
    the sand bed is cleaned by scrapping off the
    top portion of the sand layer to the depth of 1
    to 2 cm.
  • After several years of operation say 20 to 30
    scrapings, the thickness of the sand bed will
    have reduced to about 0.5 to 0.8 meter.
  • Then the plant is closed down a new bed is
    constructed.

30
ADVANTAGE OF SLOW SAND FILTRATION
  • Simple to construct operate.
  • The cost of construction is cheaper than that of
    rapid sand filters.
  • The physical, chemical bacteriological quality
    of filter water is very high.
  • It will reduce total bacterial count by 99.99
    percent E. coli by 99.9 .

31
RAPID SAND FILTERS ( MECHANICAL FILTERS)
  • In 1885 the first rapid sand filters were
    installed in the USA.
  • Since that time, they have gained considerable
    popularity even in developing countries.
  • Rapid Sand Filters are of two types
  • A. Gravity type (e.g Patersons Filter)
  • B. Pressure type ( Candys Filter)
  • Both types are in use.
  • Following steps are involved in the purification
    of water by Rapid Sand Filters.

32
RAPID SAND FILTERS ( MECHANICAL FILTERS)
  • Following steps are involved in the purification
    of water by Rapid Sand Filters.
  • 1. COAGULATION
  • The raw water is first treated with a chemical
    coagulant such as alum.
  • The dose of alum varies from 5-40 mg or more per
    liter, depending upon the turbidity colour,
    temperature and the pH value of water
  • 2. RAPID MIXING
  • The treated water is then subjected to violent
    agitation in a mixing chamber for few minutes.
  • This allows a quick and thorough dissemination
    of alum throughout the bulk of water, which is
    very necessary.

33
RAPID SAND FILTERS ( MECHANICAL FILTERS)
  • 3. FLOCCULATION
  • The next phase involves a slow gentle stirring
    of the treated water in a Flocculation Chamber
    for about 30 minutes.
  • The mechanical type of flocculation is the most
    widely used.
  • It consist of a number of paddles which rotates
    at 2 to 4 rpm with the help of motors.
  • It results in the formation of thick, copious,
    white flocculent precipitate of aluminum
    hydroxide.
  • The thicker the precipitate or flock diameter,
    the greater the setting velocity.

34
RAPID SAND FILTERS ( MECHANICAL FILTERS)
  • 4.SEDIMENTATION
  • The coagulated water is now led into
    sedimentation tanks where it is detained for
    periods varying from 2-6 hours, when the
    flocculent precipitate together with impurities
    bacteria settle down in the tank.
  • At least 95 of the flocculent precipitate needs
    to be removed before the water is admitted into
    the rapid sand filters.
  • The precipitate or sludge is which settles at the
    bottom is removed from time to time without
    disturbing the operation of the tank.

35
RAPID SAND FILTERS ( MECHANICAL FILTERS)
  • 4.SEDIMENTATION
  • For proper maintenance the tank should be cleaned
    regularly from time to time, otherwise they may
    become a breeding ground for molluscs and
    sponges.
  • 5.FILTERATION
  • The partly clarified water is now subjected to
    rapid sand filters.

36
RAPID SAND FILTERS ( MECHANICAL FILTERS)
Chlorine
River Water
Consumption
Fitters
Mixing Chamber
Clear water storage
Flocculation Chamber
Sedimentation Tank
Alum
37
FILTER BEDS
  • Each unit of filter bed has a surface of about 80
    to 90 m2 (900 sq. feet).
  • Sand is the filtering medium.
  • The effective size of the sand particles is b/w
    0.4 to 0.7 mm.
  • The depth of the sand bed is usually about 1
    meter.
  • Below the sand bed is a layer graded gravel 30 to
    40 cm deep.
  • The gravel supports the sand bed and permits the
    filtered water to move freely towards under the
    drain.

38
FILTERATION
  • As filtration proceeds, the alum-floc not
    removed by sedimentation is held on the sand bed.
  • It forms a slimy layer layer comparable to the
    Zoogleal layer in the slow sand filters.
  • It absorbs bacteria from the water effects the
    purification.
  • Oxidation of ammonia takes place during the
    passage of water through the filters.
  • As filtration proceed the suspended impurities
    and bacteria clog the filters.
  • The filters soon become dirty begin to loose
    their efficiency.

39
FILTERATION
  • When the loss of head approaches 7-8 feet,
    filtration is stopped the filters are subjected
    to a washing process known as Back Washing.

40
BACK WASHING
  • Rapid sand filters need frequent washing daily or
    weekly depending upon the loss of head.
  • Washing is accompanied by reversing the flow of
    water through the sand bed which is called Back
    Washing.
  • It removes impurities cleans the sand bed.
  • The whole process of washing takes about 15
    minutes.
  • In some rapid sand filters compressed air is used
    as part of back washing.

41
ADVANTAGE OF RAPID SAND FILTRATION
  • Rapid sand filter can deal with raw water
    directly. No preliminary storage is required.
  • The filter bed occupy less space.
  • The initial cost is high but becomes cost
    effective in future.
  • Filtration is rapid, 40 to 50 times that of slow
    sand filters.
  • The washing of the filters is easy.
  • There is more flexibility in operation.

42
METHOD OF CHLORINATION
  • For disinfection on large scale water chlorine
    is applied either as
  • Chlorine Gas.
  • Chloramines.
  • Perchloron.
  • Chlorine gas is the first choice , bcz it is
    cheap, quick in action, efficient and easy to
    apply.
  • But chlorine gas is an irritant to the eyes
    poisonous.
  • A special Chlorination equipment known as
    Patersons chloronome is required for measuring,
    regulating and administration of chlorine gas to
    water.

43
DISINFECTION/ CHLORINATION
  • Chlorination is one of the greatest advances in
    water purification.
  • It is supplement, not a substitute to sand
    filtration.
  • Chlorine kills pathogenic bacteria, but it has no
    effect on spores certain viruses (e.g Polio,
    viral hepatitis).
  • Apart from its germicidal effect, chlorine has
    several important secondary properties in water
    treatment.
  • It oxides' iron, manganese hydrogen suphide.
  • It also helps in destroying some odour producing
    constituents, so improves the taste and odour.
  • It controls algae and slim organisms acid
    coagulation.

44
USE OF CHLORINE IN PURIFICATION OF WATER
  • Chlorine can be used in different ways to purify
    the water.
  • Simple Chlorination
  • Chloramination
  • Super chlorination followed by Dechlorination

45
SIMPLE CHLORINATION
  • When Chlorine is added to water, there is a
    formation of hypochloric hypochlorous acids.
  • The hypochloric acid is neutralized by the
    alkalinity of the water.
  • The hypochlorous acid ionizes to form hydrogen
    ions hypochlorite ions.
  • H2O Cl2 HCl HOCL
  • HOCl H OCL
  • The disinfection action of chlorine is mainly due
    to the hypochlorous acid due to small extent
    due to the hypochlorite ion.
  • Hypochorous acid is the most effective form of
    chlorine for water disinfection.

46
SIMPLE CHLORINATION
  • Chlorine acts best as a disinfection when the pH
    of water is around 7 bcz of predominance of
    hypochorous acid.
  • When the pH value exceeds 8.5 it is un reliable
    as a disinfectant because about 90 of the
    hypochlorous acid gets ionized to hypochlorite
    ion.

47
CHLORAMINATION
  • In this process NH3 is added to water First and
    is followed by addition of Chlorine.
  • It exerts its effect on bacteria by forming
    chloramines.
  • The contact time must be 2 hours.
  • These are more effective and stable for longer
    period of time.
  • The Ratio of NH3 to Cl2 is 14 or 15

48
BREAK POINT CHLORINATION
  • The addition of chlorine to ammonia in water
    produces chloramines which do not have same
    efficiency as free chlorine.
  • Further addition of chlorine in water will cause
    reduction in residual chlorine due destruction of
    total chloramines by added chlorine.
  • The end product do not represent any residual
    chlorine.
  • This fall in the residual chlorine will continue
    with further increase in chlorine dose after a
    stage the residual chlorine begins to increase in
    proportion to the added dose of chlorine.

49
BREAK POINT CHLORINATION
  • This point at which the residual chlorine appears
    when all combined chlorine have been destroyed
    is Break point chlorination.
  • Now here if further Cl2 is added this will cause
    rise in Residual Cl2 (May be free or combined).
  • This is direct proportion to chlorine added.

50
Break Point Chlorination
51
SUPERCHLORINATION FOLLOWED BY DECHLORINATION
  • Super chlorination followed by Dechlorination
    comprises the addition of large doses of chlorine
    to the water and removal of excess chlorine after
    disinfection.
  • Here we add excessive Cl2. After a suitable
    contact time, this Cl2 is removed by addition of
    sulphur Dioxide in the Ratio of 18.
  • This procedure satisfies the Cl2 demand of water
    and kills cysts, ova and bacteria which are not
    killed in ordinary chlorination.
  • This method is applicable to heavy polluted
    waters, whose quality fluctuates greatly.

52
PRINCIPLES OF CHLORINATION
  • First of the all, the water to be chlorinated
    should be clear should be free from turbidity.
    Turbidity impedes efficient chlorination.
  • Chlorine demand of water should be estimated.
  • Contact period. The presence of free chlorine for
    a contact period of at least one hour is
    essential to kill bacteria viruses.
  • Chlorine has no effect on spores, protozoal cyst,
    helminthic ova, except in higher doses.
  • The minimum recommended concentration of free
    chlorine is 0.5 mg/Liter for one hour.
  • The free residual chlorine provides a margin of
    safety against microbial contamination which may
    occur during storage distribution.

53
B. Purification of Water on Small Scale
  • At Small scale or Domestic level, is carried out
    by
  • Boiling
  • Chemical disinfection
  • Filtration
  • Solar radiation

54
i. BOILING
  • It is satisfactory method of purifying water for
    house hold purposes.
  • To be effective the water must be brought to a
    rolling boil for 10 to 20 minutes.
  • It kills all bacteria, spores, spores, cyst
    yields sterilized water.
  • Boiling also removes temporary hardness by
    driving off carbon dioxide precipitating the
    calcium carbonate.
  • The taste of water is altered, but this is
    harmless.

55
ii. CHEMICAL DISINFECTION
  • 1. Blenching Powder
  • Bleaching powder or chlorinated lime (CaOCl2) is
    a white amorphous powder.
  • When freshly made it contains about 33 of
    available chlorine.
  • It is however unstable compound.
  • On exposure to air, light moisture, it rapidly
    losses its chlorine content.
  • But when mixed with lime it retains its strength
    known as stabilized bleach.
  • Bleaching should be stored in a dark, cool, dry
    place in a closed container.

56
ii. CHEMICAL DISINFECTION
  • 2. Blenching Powder
  • The principle in chlorination is to ensure a free
    residual chlorine of 0.5 mg/L at the end of one
    hour contact.
  • Highly polluted turbid waters are not suited
    for direct chlorination.

57
ii. CHEMICAL DISINFECTION
  • 2. Chlorine Solution
  • Chlorine solution may be prepared from Bleaching
    powder.
  • If 4 kg of bleaching powder with 25 available
    chlorine is mixed with 20 liters of water, it
    will give a 5 solution of chlorine.
  • Ready-made chlorine solution in different
    strengths are available in the market.
  • Like bleaching powder, the chlorine solution is
    subject to losses on exposure to light or on
    prolong storage.
  • Bleaching should be stored in a dark, cool, dry
    place in a closed container.

58
ii. CHEMICAL DISINFECTION
  • 3. Chlorine tablets
  • Under various trade names ( E.g Halozine Tab are
    available in the market.
  • They are good for disinfecting small quantities
    of water.
  • A single tablet of 0.5 g is sufficient to
    disinfect 20 liters of water.

59
ii. CHEMICAL DISINFECTION
  • 4. Iodine
  • Iodine may be used for emergency disinfection of
    water.
  • 2 drops of 2 ethanol solution of iodine will be
    sufficient for one liter of water.
  • A contact time of 20 to 30 minutes is needed for
    effective disinfection.
  • Iodine is unlikely to become a municipal water
    supply disinfectant in a broad sense.
  • High cost the fact that the element is
    physiologically active (Thyroid activity) are its
    major disadvantages.

60
ii. CHEMICAL DISINFECTION
  • 5. Potassium Permanganate
  • Once it was widely used, but now it is no longer
    recommended for water disinfection.
  • Although a powerful oxidizing agent, it is not a
    satisfactory agent for disinfecting water.
  • It may kill Vibrios Cholera but have little
    effect on other organism.
  • It has other drawbacks such as altering the
    colour, smell taste of water.

61
iii. FILTERATION
  • Water can be purified on a small scale by
    filtering through ceramic filters such as Pastuer
    Chamberland filter, Berkefeld Filter Katadyn
    Filter.
  • Filter candles usually remove bacteria found in
    drinking water but not the filter-passing
    viruses.
  • Filter candles are liable to be logged with
    impurities bacteria.
  • They should be cleaned by scrubbing with a hard
    brush under running water.
  • Only clean water should be used with ceramic
    filters.

62
Assurance of water quality
  • This is done by FOUR ways
  • Physical examination
  • Chemical examination
  • Bacteriological examination
  • Radiological examination

63
Physical examination
  • In this we see for
  • Turbidity lt 5 nephelometric turbidity unit
  • Colour 15 True colour unit (TCU)
  • Taste and odour (should be palatable)
  • Temperature cool
  • No smell

64
Chemical Examination
  1. PH 6.5 8.5
  2. Chloride 250 mg/Litre
  3. Iron .3 mg/litre
  4. Na 200 mg/Litre
  5. Hardness 200 mg/litre
  6. Copper 1 mg/litre
  7. Zinc 3 mg/litre
  8. Arsenic .01 mg/litre
  9. Lead .01 mg/litre

65
Bacteriological Examination
  • It should be free from bacteria, viruses and
    helminths and protozoa
  • To see for bacterias we perform
  • Presumptive Coliform test It is done on
    McConkeys media for 48 hours
  • We take

66
a) Presumptive Coliform test Bacteriological
Examination
  • i) 50 ml of H2O to 50 ml of D.S medium 1
  • tube
  • ii) 10 ml of H2O to 10 ml of D.S medium 5
  • tubes
  • iii) 1 ml of H20 to 5 ml of D.S medium 5
  • tubes
  • iv) 1 ml of H2O to 5 ml of D.S medium 5
  • tubes

67
Presumptive Coliform test Bacteriological
Examination
  • Presence of acid and gas confirms the presence of
    E.coli. Those who grow at 37C ? N. Faecal
    E.coli, Those who grow at 44 C ? Faecal E.coli.

68
b) Colony Count
  • It is done on Agar plate by taking 1ml of water
  • At 22C for 72 hour 20-100 colonies
  • At 37C for 48 hour 0-10 colonies, will prove
    that water is potable.

69
Radiological Examination
  1. Alpha photon emitter 15 pci/litre
  2. Beta Photon emitter 4 m ram / y
  3. Combined radium 5 Pci/litre

70
WHO Criteria for Water
  1. No sample should have E. coli in 100 ml of water
  2. Not gt 3 Coliform should be present in 100 ml of
    water
  3. Not gt 5 of sample through out the year should
    have coliform in 100 ml of H2O
  4. No TWO consecutive sample should have coliform in
    100 ml of water
Write a Comment
User Comments (0)
About PowerShow.com
