All about flat optics

1
All about flat optics
http//www.lagauge.com/
2

• Flat Optics is specifically polished and
  flattened surfaces. They are often used as a
  reference to assess the flatness of unknown
  surfaces. The principle method by which an
  optical flat functions is as follows
• Contact is made between the polished surface and
  the surface of unknown flatness.
• Under monochromatic light, dark and light bands
  (interference fringes) form and can be seen.
• The shape of these interference fringes depicts
  the visual illustration of the flatness of the
  unknown surface.
• The surface accuracy is estimated through the
  amount of spacing between the fringes as well as
  their curving.
• A surface with parallel, straight, and evenly
  spaced fringes is indicative of being more flat
  or equally flat as compared to the reference
  surface.

http//www.lagauge.com/
3

• Applications of Flat Optics
• These versatile optical devices have multiple
  uses, such as
• Measuring the flatness of polished work surfaces
• Inspecting gauge blocks for accuracy and optimal
  working capacity
• Windows that require specific interference and
  reflection
• Materials for Flat Optics
• Fused Silica
• Very low thermal expansion
• Extremely durable
• Highly resistant to abrasions

http//www.lagauge.com/
4

• Zerodur
• Clear glass ceramic
• Very low thermal expansion
• Highly resistant to temperature fluctuations
• Metal Optics
• The best quality of reflective metal optics is
  produced through proprietary single-point diamond
  machining.
• Materials Used
• Beryllium
• Aluminum-Beryllium
• Aluminum-Silicon carbide
• Infra-red crystals
• Ferrous metals

http//www.lagauge.com/
5

• Plano Mirrors
• Specially designed elegant structures
• Available in various shapes and sizes
• Create the illusion of a wider room
• Can be framed and beveled

http//www.lagauge.com/
6
