Title: ADMIXTURE


1
ADMIXTURES
  • PRESENTED BY,
  • AISWARYA. A. KUMAR
  • AMINA. RASAK
  • AMRITA. P. VIJAY
  • ANAGHA .VINOD
  • ANUPAMA. GANESH
  • ARDRA. S .ANIL
  • ARDRA .SUSHEELAN
  • ANCHU. C. BABU

2
CONTENTS
3
1.RETARDERS
4
AMAZING EXPOSED AGGREGATE ARCHITECTURE
5
COMMON RETARDERS
6
RETARDING PLASTICIZERS
  • All plasticizers and the superplasticizers by
    themselves shows certain extent of retardation.
  • Retarders are mixed with plasticizers or
    superplasticizers at the time of commercial
    production.
  • Such commercial brand is known as RETARDING
    PLASTICIZERS OR RETARDING SUPERPLASTICIZERS.

7
RETARDING PLASTICIZERS
  • 4. Example for Retarding plasticizer is
  • ASTM type D and example for retarding
    superplasticizer is ASTM type G.
  • USES
  • 1.Long transportation
  • 2.During high temperature
  • 3.Avoid construction of cold joints

8
ASTM Categories of admixtures
ASTM C494 specifies the requirement for seven
chemical admixture types they are
  1. Type A
  2. Type B
  3. Type C
  4. Type D
  5. Type E
  6. Type F
  7. Type G
  1. Water reducing admixture
  2. Retarding admixture
  3. Accelerating admixtures
  4. Water reducing and retarding
  5. Water reducing and accelerating
  6. High range water reducing
  7. Water reducing,high range,retarding

9
2.WORKABILITY AGENTSWORKABILITY IS IMPORTANT
UNDER
10
MATERIALS USED AS WORKABILITY AGENTS
11
SHALL WE STUDY PROPERTIES OF FINELY DIVIDED
MATERIALS???
  • In appropiate quantity
  • Reduce rate and amount of bleeding
  • Increases strength of lean concrete
  • Maynot increase water requirement
  • drying shrinkage
  • Increases workability

12
EFFECTS IF WORKABILITY IS REDUCEDA PEEP
OUTPUT OF WORKABLE CONCRETE
13
3.WATER PROOFING /DAMPPROOFING ADMIXTURE
14
SEE WHAT WILL HAPPEN IF DMA NOT USED
15
HERE ARE THEY..
  • Accoproof
  • It is a white powder
  • Mixed at rate 1kg/ 1 bag of cement
  • It increases impermeability of concrete structures

16
  • Natsons Cement Water proofer
  • As name indicates it is a water proofing
    Admixture
  • Mixed at rate of 1.5 kg /bag of cement

17
con
  • TRIP L-SEAL
  • It is a white powder
  • Addition decreases permeability
  • Produces rapid hardening effect

18
CICO
  • Colourless liquid
  • Control setting time,increase strength,water
    proofing

19
  • CEMENT
  • It is a water proofing admixture
  • Recommended dose is 3 by weight of cement
  • Prevents effloresence and growth of fungi

20
  • Feb mix-admix
  • Light yellow coloured liquid
  • Claimed to impart water proofing quality to
    concrete
  • Increase workability and bond

21
FACING DIFFICULTY IN BYHEARTING THE NAMES
HERE THE SOLUTION
MNEMONICS
22
COMMERCIAL WATER PROOFING ADMIXTURES
  • Arzok
  • Wet seal
  • Impermo
  • Luna Ns-1
  • Omsons watse
  • Water lock

23
WHAT REALLY IS A MISCELLANEOUS ADMIXTURE? HAVE A
LOOK.
  • Specialised admixtures which are not considered
    as chemical ,airentraining or mineral admixture
  • Provides unique properties such pumping concrete,
    dampproofing,reduce shrinkage,colouring avoid
    attack of fungi

24
AREAS WHERE MISCELLANEOUS ADMIXTURE IS APPLICABLE
25
MISCELLANEOUS ADMIXTURES
26
TYPES OF SURFACE HARDENERS
  • METALCRETE
  • Metallic aggregate specially processed,size
    graded iron particles
  • Gives wear resistence,corrosion resistence,non
    dusting,slipping concrete surface
  • FERROCRETE NO 1
  • Surface hardener that makes concrete surface
    compact,dense ,homogenous

27
  • METAL CRETE STEEL PATCH
  • When added 20 by weight of cement increases
    compressive strength and abrasion resistance
  • ARCONATE NO 1
  • It is black powder
  • Composed of iron fillings
  • Surface hardener in concrete

28
MAGIC OF SURFACE HARDENERS
29
LISPOL -N
30
LET US REVISE
No Admixture Uses Examples
1. Retarders Lengthen setting time CaSO4,gypsm,starch,common sugar,acids ,their salts
2. Workability agents Improves workability Finely divided materials,Superplasticizers,Air entraining agents
3. Dampproofing agents Retards moisture penetration in dry concrete Accoproos,trip-l-Seal,cement,Feb-Mix-Admix
4. Miscellaneous admixture Reduces shrinkage,fungi,corrosion Metalcrete,Accoproos,Ferrocrete,Cico, lispol N
31
PREVIOUS UNIVERSITY QUESTIONS
WHICH ONE YOU WANT???
  • SHALL WE PREPARE.

32
(No Transcript)
33
REFERENCES
  • Note- shivkumar sir
  • Concrete technology -M S Shetty
  • Structural engg materials -N.Jackson,
  • Ravindra .K.Dhir
  • Figures google
