Title: SKZ1050B Fixed Online Gas Detector


1
WELCOME TO
http//www.skzindustrial.com/
2
INTRODUCTION
OF
SKZ1050B Fixed Online Gas Detector
SKZ1050B Fixed Online Gas Detector- Furniture,
flooring, wallpaper, paint, gardening, interior
decoration and renovation, dyes, paper,
pharmaceutical, medical, food, corrosion Disinfect
ion, chemical fertilizers, resins, adhesives and
pesticides, raw materials, samples, process and
breeding plants, waste treatment plants, perm
places
3
Online Gas Detector
4
FEATURES
  • 1. Imported from sensor
  • 2. Standard three-wire 4-20mA signal output
    relay output, RS485 output
  • 3. The unique infrared remote control, operation
    and maintenance can be a non-contact
  • 4. Compatible with various control alarms, PLC,
    DCS, remote monitoring,
  • 5. Proof design, fast, reliable, stable proof
    grade Ex dII CT6
  • 6. Full software automatic calibration, zero
    calibration function, the gas monitoring is more
    accurate, more reliable
  • 7. Software is available maximum connect with128
    probes

5
(No Transcript)
6
(No Transcript)
7
Application
  • 1. Furniture, flooring, wallpaper, paint,
    gardening, interior decoration and renovation,
    dyes, paper, pharmaceutical, medical, food,
    corrosion
  • 2. Disinfection, chemical fertilizers, resins,
    adhesives and pesticides, raw materials, samples,
    process and breeding plants, waste treatment
    plants, perm places
  • 3. Biopharmaceutical production workshops, home
    environment, livestock breeding, greenhouse
    cultivation, storage and logistics, brewing
    fermentation, agricultural production

8
Function
  • 1. Monitoring of the environment or the
    concentration pipeline and alarm
  • 3. With temperature compensation, the
    compensation can achieve the perfect environment
    for different temperatures of gas concentration
  • 4. Two sound and light alarm, alarm point can be
    set
  • 5. Infrared remote control can be remotely
    achieved without opening the alarm set point,
    zero calibration, modify the address and other
    functions
  • 6. One or two switches can output signals can be
    driven fan or external devices such as solenoid
    valves
  • 7. Operating voltage 12-36V DC power supply
  • 8. Shell material Aluminum Stainless Steel
    (alarm lights)

9
Technical parameters
Gas Detected As requested
Detection principle Electrochemical principles/ PID/IR sensor
Sampling Method Wall-mounted, pipeline, flow type
Measure Range As requested
Resolution It depends on the measure range
Precision 2 FS
Signal Output 4-20mA signal output relay output, RS485 output (optional)
Response Time 10S
Repeatability 1
Zero shift 1 (F.S / Year)
10
Operating language Support in English
Temperature -40 ? 70 ?
Explosion-Proof Ex d II CT6
Alarm mode Sound, light
Display 18015090mm
Dimensions Automatically activated when working in poor lighting environment or the alarm sounding or the button is knobbed down.
Recovery Time 10S
Linearity error 1
Display LED
Gas unit PPM
Humidity 0-95 RH
Degree of protection IP65
Weight(net/gross) 1.6KG
11
Contact-Us
  • Contact-Us
  • Telephone- 0086-15692312640/13791019917
  • Fax- 0531- 82731861
  • Email - skzindustrial_at_live.cn,

  • info_at_skzindustrial.com,

  • sales_at_skzindustrial.com,

  • service_at_skzindustrial.com.
  • Skype stellasong831205
  • Address- D-11, No.9, Langxiang
    road,
  • Tianqiao
    District, Jinan city,
  • Shandong
    province,China, 250031
  • Website- http//skzindustrial.com/

12
http//www.skzindustrial.com/
