Economical ROPP Capping Machine

1
Pioneer Manufacturer of Semi Automatic ROPP
Capping Machine
TO
2
1. Significance of Semi Automatic ROPP Capping
Machine

• Semi automatic ROPP Capping machine Model NKCS-
  50R is appropriate Engineering solution for
  startup industries where production demand is low
  qualitative ROPP Sealing / capping required.
• The machine can deliver 30 Bottle per minute
  output depending upon operator competence.
  Qualitative ROPP Capping result due to use of
  motorized sealing head.
• Semi Automatic ROPP Capping machine can work with
  wide shaped of container like Round, Square, and
  Triangular with minimum change part. Machine
  speed can be adjusted due to the Use of Sensor
  less vector control Variable frequency drive.

3
2. Picture of Semi Automatic ROPP Capping Machine
3
4
3. Salient Features of Semi Automatic ROPP
Capping Machine

• Compact multipurpose unit.
• Easy operating interface as operating panel
  mounted at front side of machine.
• Motorized sealing head.
• Minimum change parts require for different
  container diameter.
• Low noise level low power consumptions.

4
5
3.1 Salient Features of Semi Automatic ROPP
Capping Machine

• Adjustable bottle height gauge provided for easy
  quick setting.
• Sealing pressure can be varied to suit different
  gauges and size of caps

6
4. How does these machine works

• The Semi automatic ROPP capping machine is
  precision built on sturdy welded steel frame
  completely enclose in stainless steel sheet and
  doors are provided to facilitate the servicing of
  machine. Machine is having motorized rotating
  head mechanism, which ensures proper cap sealing
  with uniform torque.
• Require manually feeding unloading container,
  where the body and the neck of the container are
  positioned below the rotating head and sealing
  head is performing perfect operation of capping
  with uniform torque.

7
5. Typical Specification
Model NKCS -50R
Type of Capping ROPP Type Capping
Output/Hour 30 -40 bottle per minute depending upon Operator efficiency
Number of ROPP Capping head 1 Nos.
Power Consumption (KW) 1 KW
Electrical Connection 230 V , Single phase , 50 HZ
ROPP Cap Diameter (mm) 18 mm to 32 mm (With Change part)
Container Diameter (mm) Ø 22 mm to Ø 100 mm
Container Height (mm) 58 mm to 240 mm
Overall Dimension 1000 mm (L) x 720 mm (W) x 1400 (H) Approx.
Net Weight 200 Kgs. Approx.
Gross Weight 350 Kgs. Approx.
Change parts required Cap Die if cap diameter change.
8
6. Contact us
N.K industries Plot no 1521, Phase -3, GIDC
Industrial estate, Vatva,Ahmedabad , INDIA-Pin
No 382445 Phone [phone] or 91-79-
40083141 Fax [phone] Cell no
91-9824072738 E-mail info_at_nkcapingmachine.com UR
Lwww.nkcapingmachine.com
