Embriology for Medical Students

1
EMBYRO

• IMEC. INC
• Quick Learning
• Technique

2
Important Concept

• Premordial Germs Cells (sperm and oocyte) go
  through division via meiosis and is influenced by
  Endocrine Hormones
• Cell growth happens via mitosis and is mediated
  and influenced by various growth factors, and
  local Paracrine and Juxtacrine Hormonal Influence
• As we can see with MIF in the following
  slide

3
Starting with SEX

• Obviously we know that XY is male and XX is
  female coming from the 23rd chromosone
• In the male (TDF) Testicular Determining Factor,
  and (MIF) Mullarian Inhibitory Factor, close the
  Mullarian Duct around the seventh week, and
  either the medulla develops as in the male, or it
  degenerates as in the female
• Note in the female the cortical chords develop

4
Gametogenisis

• During gametogenisis, the chromosome number is
  reduced by 50 and the shape of the cells is
  altered

5
(No Transcript)
6
(No Transcript)
7
Starting with SEX

• Obviously we know that XY is male and XX is
  female coming from the 23rd chromosone
• In the male (TDF) Testicular Determining Factor,
  and (MIF) Mullarian Inhibitory Factor, close the
  Mullarian Duct around the seventh week, and
  either the medulla develops as in the male, or it
  degenerates as in the female
• Note in the female the cortical chords develop

8
Male Spermatozoal Development
9
Sex determination

• Obviously we know that XY is male and XX is
  female coming from the 23rd chromosone
• In the male (TDF) Testicular Determining Factor,
  and (MIF) Mullarian Inhibitory Factor, close the
  Mullarian Duct around the seventh week, and
  either the medulla develops as in the male, or it
  degenerates as in the female
• Note in the female the cortical chords develop

10
Spermatogenesis

• Spermatogenesis in males starts at puberty
• Both Testosterone from the Leydig cells and FSH
  are very important in the development
• Also in the testis themselves are the Sertoli
  (follicular cells) that actually mature
  spermatids
• Note that during spermatogenesis we go through
  Mitosis, and the first and second Meotic
  divisions

11
(No Transcript)
12
64 Days Total
13
Sperm

• The sperm themselves rely heavily on glucose
• They have an Acrosomal head, for penetration
• Mitochondrial function in the body
• And a tail

14
Enzymes

• Note we add these enzymes here because you will
  be introduces to various sexual disorders in
  pathology and you might as well as see
  intragration of subjects

15
Enzymes(Notice 17-a 5-a)
16
Oogenesis

• Oogenesis is a little different.
• Girls are born with all there ovum. They oogonium
  are arranged in cluster within the ovary and
  probably developed from one cell dividing via
  Mitosis.
• Note that each oogonium to oocyte and the
  eventually follicular cell is guided by estrogen
  and progesterone

17
Note

• Primary Oocytes remain in prophase and do not
  finish their first meiotic division until puberty

18
Ovarian Follicle
19
Ovarian Follicle Formation
20
(No Transcript)
21
(No Transcript)
22
Puberty in the Female

• During this time pooling of 15-20 Follicles begin
  to grow producing a granulosa cells (primary
  epitethelium), the theca interna (fibrous
  capsule) and zona pellucida

23
Theca Interna, Granulosa Cells, Apipose
24
Female Reproductive
25
Control

• It is important to note the the reproductive
  control in this cycle actually comes from the
  hypothalmus and pituitary

26
(No Transcript)
27
Fertilization
28
Cleavage

• Once fertilized and the cell is actually now
  zygote, it actually starts at a two cell stage,
  and through mitotic division eventually and
  eventually ends up after 40 hours in a morula
  phase

29
Morula

• As we can see the mitotic division from 2 cells
  to approximatelly 16 cells

30
Blastocyst

• At about the time the morula enters the uterine
  cavity, fluid begins to penetrate through the
  zona pellucida.
• The blastocyst forms
• These trophoblastic cells begin to penetrate the
  uterine linings

31
Corpus Luteum-Lipid Remnant
32
Graffian Follicle-Embryo
33
Meiosis

• Takes place on in germ cell
• The first is Reduction Division, because the
  chromosome number is reduced from diploid to
  haploidHomologous chromosomes separate
• These cells are primary oocytes, and
  spermatocytes
• The second meiotic division the sister chromotids
  separate
• These cells are secondary oocytes, and
  spermatocytes

34
(No Transcript)
35
(No Transcript)
36
(No Transcript)
37
(No Transcript)
38
(No Transcript)
39
(No Transcript)
40
(No Transcript)
41
(No Transcript)
42
Allantois

• -A membranous sac that develops from the
  posterior part of the alimentary canal in the
  embryos of mammals, birds, and reptiles. It is
  important in the formation of the umbilical cord
  and placenta in mammals. Also called allantois.

43
Amnion-

• The outer membrane enclosing the embryo in
  reptiles, birds, and mammals.

44
GERM LAYERS
45
FETAL LANDMARKS

• 1 week----------------Implantation
• 2 weeks---------------Bilaminar disk
• 3 weeks---------------Gastrulation
• 3 weeks-----Primitive streak/Neural Plate
• Weeks 3-8-----Organogenesis
• Week 4----------Heart begins to pump
• Week 10----------Genitalia Form

46
Rule of 2s for 2nd week

• 2 Germ Layers (epiblast, hypoblast)
• 2 Cavities (amniotic and yolk sac)
• 2 Placental Components
• Cytotrophoblast, Syncytiotrophoblast
• NOTE---(epilast invaginates to form primitive
  streak? this forms to
• intra-embryonic mesoderm and endoderm

47
Rule of 3s for 3rd week

• 3 germ layers
• PRIMITIVE STREAK FORMS
• GASTRULATION
• ECTODERM
• MESODERM
• ENDODERM

48
(No Transcript)
49
Primitive Streak
50
Notachord and Neural Tube

• At about 14-16 days the primitive streak has been
  established and the Notochord begins to develope
• The Neural Tube begins to form
• Mitotic division of cell layers begins to be
  established
• Knowing these is basic memorization

51
ECTODERM

• SURFACE ECTODERM
• NEUROECTODERM
• NEURAL CREST

52
Surface Ectoderm

• Adeno-hypophysis
• Lens of eye
• Epithelial lining
• Epidermis

53
Neuroectoderm

• Neurohypophysis
• CNS Neurons
• Oligodendrocytes
• Astocytes
• Pineal Gland

54
Neural Crest

• ANS
• Dorsal Root Ganglia
• Melanocytes
• Chromaffin cell of Adrenal Medulla
• Enterochromaffin cells
• Pia
• Celiac Ganglion
• Schwann Cells
• Odontoblasts
• Para-follicular Cells of Thyroid

55
MESODERM

• Dura connective tissue
• Muscle
• Bone
• Cardio Structures
• Lymph
• Blood
• Uro structures
• Serous Linings of body cavities
• Spleen
• Adrenal Cortex

56
Bone

• Developmental origin
• Intramembranous bone forms directly from
  mesenchyme
• Endochondrial (intracartilagenous) bone replaces
  cartilage model

57
Bone (normal fetal growth plate)
58
Intramembranous ossification

• Flat Bones
• Mechanism
• Clusters of mesanchymal cell differentiate into
  osteoblasts
• Osteoblast secrete matrix
• Spicules of bone form spongy bone
• Centers of ossicification grow together
• Bone is deposited in inner and outer surfaces
  forming layers of compact bone

59
Endochondrial ossification

• Bone replaces a cartilage model
• Long and short bones
• Mechanism
• Hyaline cartlage model of bone is formed in fetus
• Chondrocytes of model hypertrophy and then
  regenerate-this hypertrophy causes matrix to
  reduce plates
• Matrix is cacified by hydroxapatite
• Osteoclast digest channels, so progenitor
  Osteoblasts can continue to synthesize matrix

60
Ossification

• Resting zone
• an area of normal hyaline cartilage yet to be
  ossified
• Proliferative zone
• Chondrocytes divide forming isogenic groups
• Longitudal growth of entire bone
• Hypertrophic zone
• Chondrocyte enlarge and then die
• Matrix reduced to thin plates
• Calcified cartilage zone
• Hydroxapatite crystals are deposited in matrix
• Ossification zone
• Capillary invade, primary bone is deposited,
  spicules formed

61
Fat Formation

• Primary Fat Formation (Brown Fat)
• Occurs early in embryogenesis
• Epitheloid precursor cells are laid down in
  specific areas
• Precursors differentiate into multi-occular
  adipocytes and accumulate lipid droplets
• Secondary Fat Formation (White Fat)
• Occurs later in embryogenesis
• Fusiform cells in many connective tissues
  differentiate into uniocular adipocytes and
  accumulate lipid

62
ENDODERM

• Gut tubular epithelium
• LUNG, LIVER, PANCREAS, THYROID, PARATHYROID

63
NOTOCHORD

• Induces ectoderm to form neuro-ectoderm
• NEURAL PLATE
• Its postnatal derivative of is nucleus pulposus
  of the inter-vertebral disk

64
FETAL ERYTHROPOESIS
65
Fetal Erythropoiesis

• (3-8 Week)------- ?Yolk Sac
• (6-30 Week)------?Liver
• (9-28 Week)------?Spleen
• (28 Week on)---- ?Bone Marrow

66
Yolk sac

• A membranous sac attached to an embryo, providing
  early nourishment in the form of yolk in bony
  fishes, sharks, reptiles, birds, and primitive
  mammals and functioning as the circulatory system
  of the human embryo before internal circulation
  begins.

67
HEART EMBYOLOGY

• MESODERM

68
Cardiac Progenation

• Cardiac Cells lie in the Epiblast cell outside
  the neural plate
• They actually migrate the cranial cells and
  position themselves rostal to the oropharyngeal
  membrane and neural folds
• Initially this region is anterior to neural
  tube, embracing it for a short period before
  final to a primitive thorax region

69
Heart Tube

• The heart tube bulges more and more into a cavity
• With further development we can see a dorsal
  region disappear creation a transverse
  pericardial sinus.
• This is formed by a cellular matrix rich in
  hyaluronic acid
• The epicardium is derived from mesothelial cell,
  thickening so called outflow tract/spectum

70
Bulbus Cordus

• The atrial portion of the heart is actually the
  bulbus cordus, a narrow area except in proximal
  third where substantial interaction occurs at
  what we now refer to the interventricular foramen

71
Formation of a Cardiac Loop

• There is a twisting/folding in the region as
  shown in the following slides that show this
  process

72
EARLY HEART

• Early Heart and Primitive Heart Tube Folding
• (NEXT SLIDE) Picture of the fusion of two
  endocardial tubes into a single primitive heart
  tube. Details the descriptions of the movement of
  the bulbis cordis, primitive ventricle, primitive
  atrium, and sinus venosus

73
(No Transcript)
74
(No Transcript)
75
(No Transcript)
76
Endocadardial Cushions
77
Primitive Heart
78
Inferior Vena Cava

• Derived from
• Common Cardinal Vein

79
Most Common Defects

• Ventricular Septal Defect (VSD)
• Patent Ductus Arteriosis
• Patent Foramen
• Jxtaposition of Vessels
• Dextrocardia
• Tetrology of Fallot

80
ARTERIAL

• TRUNCUS ARTERIOISIS
• BULBUS CORDIS
• PRIMITIVE VENTRICLE

81
TRUNCUS ARTERIOSUS

• Gives rise to ascending aorta and pulmonary trunk

82
Bulbus Cordis

• Smooth Part of Ventricles

83
Primitive Ventricle

• Trabeculated Part of Ventricles

84
VENOUS

• Left horn of sinus venosus
• Right Horn of Sinus venosus
• R- Common Cardinal Vein and Right anterior
  cardinal vein

85
Primitive Atrium

• Trabelulated atrium

86
Left Horn

• Coronary Sinus

87
Right Horn

• Smooth Right atrial area

88
Right Common Cardinal Vein

• Superior Vena Cava

89
Umbilical Vein

• Ligamentum teres hepatis

90
Urachal Cyst

• Remnant of allantois (urine drainage from bladder)

91
Umbilical Arteries

• Medial Umbilical ligaments

92
Ductus Arteriosis

• Ligamentum Arteriosum

93
Ductus Venosus

• Ligamentum venosum

94
Foramen Ovale

• Fossa ovale

95
Aortic Arch Derivatives

• 1st Part ---------? Maxillary
• 2nd Part---------? Stapedial
• 3rd Part---------? Common Carotid
• 4th Part---------? Aortic Arch/Systemic
• 6th Part---------? Pulmonary

96
Branchial Apparatus

• Branchial Clefts derived from ectoderm
• Branchial Arches derived from mesoderm
• Branchial Pouches derived form endoderm

97
BRANCHIAL ARCH Mostly Ms

• Meckels Cartilage
• Mandible
• Malleus
• Muscles of Mastication (Masseter and medial
  pterygoids)
• Mylohyhoid
• Anterior digastric, tensor tympani, tensor veli
  palatini
• NERVE----CN V3

98
BRANCHIAL ARCH IIMostly Ss (Smile)

• Reicherts Cartilage
• Stapes
• Styloid Process
• Lesser Hyoid
• Stylohyoid ligament
• Stapedius
• Muscle of facial expression
• Stapedius, Stylohyoid, posterior digastric
• NERVE-------CN VII

99
BRANCHIAL ARCHIII Pharnyx

• Greater Hyoid
• Stylopharyngeus--? intervated by CN IX
• CN IX

100
BRANCHIAL ARCH 4-6

• Cartilages-Thyroid, crycoid, arytenoid,
  corniculate , cuniform
• Muscles (4th) Pharnygeal constrictor
• Cricothyroid, Levator veli palatini
• Muscles (6th) all intrinsic except cricothyroid
• NERVE (4th) is CN X (VAGUS)
• NERVE (6th) is CN X (VAGUS)

101
BRANCHIAL ARCH INNERVENTION

• Arch I------? CN V2 V3
• Arch II-----? CN VII
• Arch III----? CN IX
• Arch IV IV? CN X

102
BRANCHIAL CLEFT

• 1st Cleft develops into external auditory meatus
• 2nd-4th Cleft for temporary cervical sinuses
  which are obliterated by the 2nd Arch Mesenchyme
• Note- Persistent cervical sinus can lead to a
  branchial cyst in the neck

103
EAR DEVELOPEMENT

• Bones-----
• 1st Arch-----INCUS/MALLOUS
• 2nd Arch-----STAPES
• Muscles
• 1st Arch---TENSOR TYMPANI (CN V3)
• 2nd Arch---STAPEDIUS (CN VII)
• Miscellaneous
• External auditory meatus1st Cleft
• Ear drum, eustachian tube-1st pharnygeal membrane

104
Prechordial Plate

• This is an area of hypoblast cell that are
  localized in one area
• The PLATE INDICATES FUTURE SITE OF MOUTH

105
Branchial Pouch Derivatives

• 1st Pouch----Middle ear cavity, eustachian tube,
  mastoid air cell
• 2nd Pouch---lining of palentine tonsil
• 3rd Pouch (dorsal) ---inferior parathyroid
• 3rd Pouch (ventral)---thymus
• 4th Pouch----superior parathyroid
• Note abberent development of 3rd 4th
  pouches-?Digeorges syndrome?T-cell deficiency
  (thymic hypoplasia) and hypocalcemia (parthyroid
  gland)

106
THYMUS DEVELOPMENT

• Site for T-Cell Maturation
• Encapsulated
• From epithelium of 3rd Branchial Pouch
• Cortex is dense with immature T-Cells
• Medulla is pale with mature T-Cells, epithelial
  reticular tissue and Hassalls corpuscles
• Positive and negative selection occurs at the
  cortico-medullary junction

107
Thyroid Development

• Thyroid diverticulum arises from the floor of the
  primitive pharynx, and it DESCENDS into the neck.
• Connected to the tongue by the thryoglossal duct
  which normally disappear. Foramen Cecum is normal
  remnant of thyroglossal duct
• MOST COMMON ECTOPIC SITE FOR THYROID IS TONGUE

108
Tongue Development

• 1st Branchial Arch forms anterior 2/3 of Tongue
• Pain Via CN V3, Taste via CN VII (facial)
• 3rd and 4th arches form posterior 1/3 of tongue
• Pain and taste mainly CN IX, some CN X
• Motor innervation CN XII

109
CLEFT LIP/ CLEFT PALATE

• Cleft lip - Failure of fusion of Maxillary and
  Medial Nasal Processes
• Cleft Palate -Failure of fusion of palentine
  processes, the nasal septum, and/or median
  palentine processes

110
Diaphragm Embryology

• SEVERAL PARTS BUILD DIAPHRAGM
• Diaphragm is derived from
• SEPTUM TRANSVERSUM
• PLEUROPERITONEAL FOLDS
• BODY WALL
• DORSAL MESENTARY OF ESOPHAGUS

111
Bone Formation

• Intramembranous
• Spontaneous
• Endochondrial
• Ossicification

112
Pancreas and Spleen

• Pancreas is derived from FOREGUT
• Ventral pancreas becomes head (uncinate)
• Dorsal becomes everything else (body, tail,
  isthmus, and accessory pancreatic duct)
• Spleen arises from DORSAL MESENTARY

113
POTTERs Syndrome

• Bilateral Renal Agenesis-?Oligohydramnios-?facial
  deformities-?Pulmonary Hypoplasia
• Babies CANT PEE in UTERO

114
GENITAL DUCT

• Mesonephric (Wolffian Duct) SEED
• Seminal Vesicles, Epididymis, Ejactulatory duct,
  Ductus Deferens
• Paramesonephric (Mullarian Duct)
• Fallopian Tubes, Uterus, Part of Vagina
• MULLARIAN INHIBITORY SUBSTANCE SECRETED BY TESTES
  SUPPRESSES DEVELOPMENT OF PARAMESONEPHRIC DUCT

115
SPERM DEVELOPMENT

• Spermatogenesis begins with spermatagonia (Type A
  and Type B)
• Deriving from Sertoli cells of the seminephrous
  tubules (the Blood-Testis Barrier).
  Spermatagonium first become
• Primary Speramatocytes
• Secondary Spermatocytes
• Spermatids

116
SPERM DEVELOPMENT

• Diploid---- ? spermatogonium
• (2N)
• Diploid---- ? 1 spermatocyte
• (4N)
• Haploid----? 2 spermatocyte
• (2N)
• Haploid----? spermatid
• (N)

117
Derivation of sperm parts

• Acrosome is derived from golgi
• Flagellum from one or more centrioles
• Middle (neck) has Mitochondria

118
Meiosis and Ovulation

• AN EGG (METaphase) a SPERM
• 1 oocytes begin Meiosis I during fetal life and
  complete Meiosis I just prior to ovulation.
• Meoisis I is arrested in PROPHASE until ovulation
• Meoisis II is arrested in METAPHASE until
  fertilization
• AN EGG (METaphase) a SPERM

119
WEEK 1

• Conception
• Conceptus the embryo and its membranes

120
Week 2

• The Primary Chorionic villi develop and begin to
  get a blood flow from mother
• Lacuna appear in synctiotrophoblast

121
Synctiotrophobast

• Continues to grow into endometrium and at about
  day 10 start producing (hCG)

122
Fetal Landmarks

• Week 1 ------------?Implantation of Blastocyst
• Week 2 ------------?Bilaminar Disk
• Week 3 ------------?Gastrulation
• Week 3-------------?Primitive streak/neural plate
• Week 4-------------?Heart begins to beat
• Week 10------------?Genitalia male/female
• NOTE----WEEKS 3-8 most susceptable to teratogens

123
Early Developement
124
Early Development
125
Early Developement
126
Prenatal period 3-8 weeks

• Embyonic period
• Mitotic divisions of cells called Blastomere
• Morula when 12 blastomeres have formed
• Blastocyst enters the uterus
• Gastrula- 3 layers
• Ectoderm
• Mesoderm
• Endoderm
• Neurula- (neural plate closes to form Neural tube
  at week 3)
• Embryo-(3-8th week)

127
STAGES

• Fetal-After the embyonic period (week 9-birth)
• Neonatal-first month of life
• Infancy-1 month-1 yr
• Childhood-13 months-12 years
• Puberty- 12-15
• Adolescence 12-17

128
Amniotic Fluid Abnormalities

• Polyhydraminios
• (gt1.5-2.0 L)
• Associated with esophageal/duodenal atresia and
  anacephaly
• Oligihydraminios
• (lt 0.5 L) of Amniotic Fluid Associated with
  bilateral renal agenisis or posterior urethral
  valves (in males)

129
Horseshoe Kidney

• Inferior Poles of Both Kidneys are Fused
• AS THEY ASCENDThey get trapped under the
  inferior mesenteric artery and remain lower in
  the abdomen

130
REMEMBER EMBRYO
131
Teratogens

• ACE Inhibitors---------Renal Damage
• Cocaine------------------Fetal addiction
• DES----------------------Clear Cell CA
• Iodide--------------------Goiter
• 13-cis-retinoic acid-----Many other defects
• Thalidomide-------------Limb defects
• Warfarin-----------------Multiple anomalies

132
UMBILICAL CHORD

• Contains 2 Umbilical Arteries
• DEOXYGENATED BLOOD FROM FETUS
• Contains 1 Umbilical Vein
• OXYGENATED BLOOD TO FETUS FROM PLACENTA
• Note- single umbilical artery is associated with
  chromosomal defect and/or congenital anomaly

133
ECTODERM

• SURFACE ECTODERM
• NEUROECTODERM
• NEURAL CREST

134
Surface Ectoderm

• Adeno-hypophysis
• Lens of eye
• Epithelial lining
• Epidermis

135
Neuroectoderm

• Neurohypophysis
• CNS Neurons
• Oligodendrocytes
• Astocytes
• Pineal Gland

136
Neural Crest

• ANS
• Dorsal Root Ganglia
• Melanocytes
• Chromaffin cell of Adrenal Medulla
• Enterochromaffin cells
• Pia
• Celiac Ganglion
• Schwann Cells
• Odontoblasts
• Para-follicular Cells of Thyroid

137
MESODERM

• Dura connective tissue
• Muscle
• Bone
• Cardio Structures
• Lymph
• Blood
• Uro structures
• Serous Linings of body cavities
• Spleen
• Adrenal Cortex

138
ENDODERM

• Gut tubular epithelium
• LUNG, LIVER, PANCREAS, THYROID, PARATHYROID

139
NOTOCHORD

• Induces ectoderm to form neuro-ectoderm
• NEURAL PLATE
• Its postnatal derivitive of is nucleus pulposus
  of the inter-vertebral disk

140
Early Development
141
Rule of 2s for 2nd week

• 2 Germ Layers (epiblast, hypoblast)
• 2 Cavities (amniotic and yolk sac)
• 2 Placental Components
• Cytotrophoblast, Syncytiotrophoblast
• NOTE---(epilast invaginates to form primitive
  streak? this forms to
• intra-embryonic mesoderm and endoderm

142
Rule of 3s for 3rd week

• 3 germ layers
• GASTRULA
• ECTODERM
• MESODERM
• ENDODERM

143
FETAL ERYTHROPOESIS
144
Fetal Erythropoiesis

• (3-8 Week)------- ?Yolk Sac
• (6-30 Week)------?Liver
• (9-28 Week)------?Spleen
• (28 Week on)---- ?Bone Marrow

145
HEART EMBYOLOGY
146
ARTERIAL

• TRUNCUS ARTERIOISIS
• BULBUS CORDIS
• PRIMITIVE VENTRICLE

147
TRUNCUS ARTERIOSUS

• Gives rise to ascending aorta and pulmonary trunk

148
Bulbus Cordis

• Smooth Part of Ventricles

149
Primitive Ventricle

• Trabeculated Part of Ventricles

150
VENOUS

• Left horn of sinous venosus
• Right Horn of Sinus venosus
• R- Common Cardinal Vein and Right anterior
  cardinal vein

151
Primitive Atrium

• Trabelulated atrium

152
Left Horn

• Coronary Sinus

153
Right Horn

• Smooth Right atrial area

154
Right Common Cardinal Vein

• Superior Vena Cava

155
Umbilical Vein

• Ligamentum teres hepatis

156
Urachal Cyst

• Remnant of allantois (urine drainage from bladder)

157
Umbilical Arteries

• Medial Umbilical ligaments

158
Ductus Arteriosis

• Ligamentum Arteriosum

159
Ductus Venosus

• Ligamentum venosum

160
Foramen Ovale

• Fossa ovale

161
(No Transcript)
162
Aortic Arch Derivatives

• 1st Part ---------? Maxillary
• 2nd Part---------? Stapedial
• 3rd Part---------? Common Carotid
• 4th Part---------? Aortic Arch/Systemic
• 6th Part---------? Pulmonary

163
Branchial Apparatus

• Branchial Clefts derived from ectoderm
• Branchial Arches derived from mesoderm
• Branchial Pouches derived form endoderm

164
BRANCHIAL ARCH I Mostly Ms

• Meckels Cartilage
• Mandible
• Malleus
• Muscles of Mastication (Masseter and medial
  pterygoids)
• Mylohyhoid
• Anterior digastric, tensor tympani, tensor veli
  palatini
• NERVE----CN V3

165
BRANCHIAL ARCH II Mostly Ss (Smile)

• Reicherts Cartilage
• Stapes
• Styloid Process
• Lesser Hyoid
• Stylohyoid ligament
• Stapedius
• Muscle of facial expression
• Stapedius, Stylohyoid, posterior digastric
• NERVE-------CN VII

166
BRANCHIAL ARCH III Pharnyx

• Greater Hyoid
• Stylopharyngeus--? intervated by CN IX
• CN IX

167
BRANCHIAL ARCH 4-6

• Cartilages-Thyroid, crycoid, arytenoid,
  corniculate , cuniform
• Muscles (4th) Pharnygeal constrictor
• Cricothyroid, Levator veli palatini
• Muscles (6th) all intrinsic except cricothyroid
• NERVE (4th) is CN X
• NERVE (6th) is CN X

168
BRANCHIAL ARCH INNERVENTION

• Arch I------? CN V2 V3
• Arch II-----? CN VII
• Arch III----? CN IX
• Arch IV IV? CN X

169
BRANCHIAL CLEFT

• 1st Cleft develops into external auditory meatus
• 2nd-4th Cleft for temporary cervical sinuses
  which are obliterated by the 2nd Arch Mesenchyme
• Note- Persistent cervical sinus can lead to a
  branchial cyst in the neck

170
EAR DEVELOPEMENT

• Bones-----
• 1st Arch-----INCUS/MALLOUS
• 2nd Arch-----STAPES
• Muscles
• 1st Arch---TENSOR TYMPANI (CN V3)
• 2nd Arch---STAPEDIUS (CN VII)
• Miscellaneous
• External auditory meatus1st Cleft
• Ear drum, eustachian tube-1st pharnygeal membrane

171
Branchial Pouch Derivatives

• 1st Pouch----Middle ear cavity, eustachian tube,
  mastoid air cell
• 2nd Pouch---lining of palentine tonsil
• 3rd Pouch (dorsal) ---inferior parathyroid
• 3rd Pouch (ventral)---thymus
• 4th Pouch----superior parathyroid
• Note abberent development of 3rd 4th
  pouches-?Digeorges syndrome?T-cell deficiency
  (thymic hypoplasia) and hypocalcemia (parthyroid
  gland)

172
THYMUS DEVELOPMENT

• Site for T-Cell Maturation
• Encapsulated
• From epithelium of 3rd Branchial Pouch
• Cortex is dense with immature T-Cells
• Medulla is pale with mature T-Cells, epithelial
  reticular tissue and Hassalls corpuscles
• Positive and negative selection occurs at the
  cortico-medullary junction

173
Thyroid Development

• Thyroid diverticulum arises from the floor of the
  primitive pharynx, and it DESCENDS into the neck.
• Connected to the tongue by the thryoglossal duct
  which normally disappear. Foramen Cecum is normal
  remnant of thyroglossal duct
• MOST COMMON ECTOPIC SITE FOR THYROID IS TONGUE

174
Tongue Development

• 1st Branchial Arch forms anterior 2/3 of Tongue
• Pain Via CN V3, Taste via CN VII (facial)
• 3rd and 4th arches form posterior 1/3 of tongue
• Pain and taste mainly CN IX, some CN X
• Motor innervation CN XII

175
CLEFT LIP/ CLEFT PALATE

• Cleft lip - Failure of fusion of Maxillary and
  Medial Nasal Processes
• Cleft Palate -Failure of fusion of palentine
  processes, the nasal septum, and/or median
  palentine processes

176
Diaphragm Embryology

• SEVERAL PARTS BUILD DIAPHRAGM
• Diaphragm is derived from
• SEPTUM TRANSVERSUM
• PLEUROPERITONEAL FOLDS
• BODY WALL
• DORSAL MESENTARY OF ESOPHAGUS

177
Bone Formation

• Intramembranous
• Spontaneous
• Endochondrial
• Ossicification

178
Pancreas and Spleen

• Pancreas is derived from FOREGUT
• Ventral pancreas becomes head (uncinate)
• Dorsal becomes everything else (body, tail,
  isthmus, and accessory pancreatic duct)
• Spleen arises from DORSAL MESENTARY

179
GENITAL DUCT

• Mesonephric (Wolffian Duct) SEED
• Seminal Vesicles, Epididymis, Ejactulatory duct,
  Ductus Deferens
• Paramesonephric (Mullarian Duct)
• Fallopian Tubes, Uterus, Part of Vagina
• MULLARIAN INHIBITORY SUBSTANCE SECRETED BY TESTES
  SUPPRESSES DEVELOPMENT OF PARAMESONEPHRIC DUCT

180
SPERM DEVELOPMENT

• Spermatogenisis begins with spermatagonia (Type A
  and Type B)
• Deriving from Sertoli cells of the seminephrous
  tubules (the Blood-Testis Barrier).
  Spermatagonium first become
• Primary Speramatocytes
• Secondary Spermatocytes
• Spermatids

181
SPERM DEVELOPMENT

• Diploid---- ? spermatogonium
• (2N)
• Diploid---- ? 1 spermatocyte
• (4N)
• Haploid----? 2 spermatocyte
• (2N)
• Haploid----? spermatid
• (N)

182
Derivation of sperm parts

• Acrosome is derived from golgi
• Flagellum from on or more centrioles
• Middle (neck) has Mitochondria

183
Meiosis and Ovulation

• AN EGG (METaphase) a SPERM
• 1 oocytes begin Meiosis I during fetal life and
  complete Meiosis I just prior to ovulation.
• Meoisis I is arrested in PHOPHASE until ovulation
• Meoisis II is arrested in METAPHASE until
  fertilization
• AN EGG (METaphase) a SPERM

184
Amniotic Fluid Abnormalities

• Polyhydraminios
• (gt1.5-2.0 L)
• Associated with esophageal/duodenal atresia and
  anacephaly
• Oligihydraminios
• (lt 0.5 L) of Amniotic Fluid Associated with
  bilateral renal agenisis or posterior urethral
  valves (in males)

185
POTTERs Syndrome

• Bilateral Renal Agenisis-?Oligohydramnios-?facial
  deformities-?Pulmonary Hypoplasia
• Babies CANT PEE in UTERO

186
Horshoe Kidney

• Inferior Poles of Both Kidneys are Fused
• AS THEY ASCENDThey get trapped under the
  inferior mesenteric artery and remain lower in
  the abdomen

187
Bifid Uterus
188
Bifid Uterus

• A uterus that is more or less completely divided
  into two lateral horns as a result of imperfect
  union of the paramesonephric ducts it differs
  from septate uterus, in which there is no
  external mark of separation in bicornate uterus,
  the cervix may be single (uterus bicornis
  unicollis)
• The usually involves the paramesonephic duct not
  releasing
