Title: Physiology for Medical Students


1
PHYSIOLOGY
  • IMEC Inc.

2
(No Transcript)
3
(No Transcript)
4
(No Transcript)
5
(No Transcript)
6
(No Transcript)
7
OSMOSIS
  • Osmosis Net diffusion of H20

8
Osmolarity
  • Osmolarity? Osmoles/ per liter of solution
  • Osmoles (moles X species)

9
OSMOLARITY AND SODIUM CONCENTRATION Water
Conservation and Excretion obligatory urine
volume Antidiuretic hormone Countercurrent
Mechanism Loop of Henle countercurrent
multiplier distal tubule and collecting ducts
urea vasa recta Quantifying Urine
Concentration and Dilution )smolar clearance
free water clearance Control of Extracellular
Fluid Osmolarity estimation from plasma sodium
osmoreceptors and ADH feedback sequence ADH
synthesis and release neuroanatomy
cardiovascular reflexes Thirst thirst center
stimuli for thirst integration of osmoreceptors
and thirst
10
Facilitated diffusion
  • Occurs down an electro-chemical gradient
    (DOWNHILL)
  • Does not require energy
  • Therefor PASSIVE

11
Primary Active Transport
  • DIRECT INPUT OF ENERGY
  • Carrier mediated so it is STEREOSPECIFIC
  • Na-K Pump (note digitalis/oubian)
  • Ca Pump (SR Cells)
  • Proton Pump (Parietal Cells)

12
Secondary ctive Transpoty
  • Na-glucose Co transport (Kidney)
  • DOWNHILL
  • Na-Ca Co Transport (antiport)
  • Uphill and downhill

13
Normal Body fluids
  • 5 Dextrose
  • 0.9 NaCl

14
Voltage Gated channels
  • These are channels that are egulated by Na
    (Sodium). During the upstroke of nerve action
    potentia

15
Ligand gated channels
  • These are channels opened or close by hormones,
    second messenger (IP3, DAG), or neurotransmitters

16
Analogy of systems
  • Q P1-P2
  • R

17
(No Transcript)
18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
Capillary Fluid Exchange
23
Regulation
24
(No Transcript)
25
Starlings Forces
26
Starling Hypothesis
  • (Pc - Pi) s (Pp - Pi)
  • Driving Forces.
  • a. Capillary hydrostatic pressure, Pc.  20-27
    mmHg
  • (Guyton Says 17 mmHg ) b.
    Interstitial hydrostatic pressure, Pi. -7 to -1
    mmHg
  • (Guyton Says -3 mmHg) c. Plasma solute
    osmotic pressure, P. 25 mmHg
  • (Guyton Says 28 mmHg) d. Interstitial
    solute osmotic pressure, Pi. 1 to 3 mmHg.
  • (Guyton 8 mmHg)

27
Starling Forces
28
Starling Equation
29
(No Transcript)
30
(No Transcript)
31
(No Transcript)
32
(No Transcript)
33
(No Transcript)
34
(No Transcript)
35
(No Transcript)
36
Total Blood Volume
  • TBVPlasma Volume
  • 1-HCT

37
Mean Arterial Pressure
  • (2 X Diastolic) Systolic
  • 3

38
Normal Parameters
  • MAP - 70-110 mmHg
  • CO - 4-7 L/min

39
(No Transcript)
40
(No Transcript)
41
Resistance Pressures
  • SVR ( MAP - RAP/ CO ) x 80 - systemic vascular
    resistance
  • SVR - 900-1200 dynes/cm square
  • PVR ( PAP - PAOP/ CO ) x 80 - pulmonary
    vascular resistance

42
Normal Cardiac Pressures
  • RA - 0-7 mmHg
  • RV - 15-30 / 0-7 mmHg
  • ( systolic / diastolic )
  • PA - 15-30 / 8-15 / 10-17 mmHg
  • ( systolic / diastolic / mean )
  • PAOP mean - 6-12 mmHg

43
OHMs LAW
  • It is written as V/I R
  • V is the voltage of a device,
  • I is the current, and
  • R is the resulting resistance.

44
(No Transcript)
45
Depolarization
  • Following a stimulus there is a sudden change in
    permeability to (Na)
  • Note-remember that sodium is not normally
    permeable
  • Opening of channels causes a rapid alteration in
    the voltage of the membrane from 70 mv to 35 mv

46
Repolarization
  • After about 0.8 miiliseconds, the Na Channels
    close, and and increased number of potassium (K)
    escape to the outside of the cell that drive the
    potential back to 70mv
  • There is a brief period of overshoot or
    hyperpolarization

47
Restorative process
  • There is a restorative process that pumps these
    to electrolytes back to there normal state,
    against there gradients
  • This can be done using metabolic energy and
    enzyme operated pumps until stable

48
ACTIVE TRANSPORT
  • Primary ATPase (ADPP)
  • Can be GTP/NADPH
  • Does not waste energy
  • More efficient
  • Na? K Pump
  • Ca Pump
  • Glucose Transport

49
Passive transport
  • Relys many on gradient
  • Faster at first then slows down

50
Myocardial Sarcomere
51
SARCOMERE
52
Sarcomere (Band, Lines, Zones)
53
Relaxation and Contraction
54
Myosin-Troponin Crossbridge
55

56
THE HEART
57
The Frank-Starling relationship
  • In general muscle fiber length-force
    relationship (force developed vs initial fiber
    length) At very short muscle length, thin actin
    filaments overlap, interfere, not optimal, force
    therefore not maximal At optimal muscle lengths,
    optimal actin-myosin interactions (sarcomere
    around 2.0 to 2.4 mm),
  • maximal force generated
  • At overly stretched muscle lengths, too few
    points of actin-myosin overlap, too few myosin
    heads engaged, force sub-maximal
  • In cardiac muscle, translates to a
    pressure-volume relationship (pressure developed
    vs initial volume)

58
Preload
  • Preload Is a case, where something determined
    the initial fiber length. In the heart, this was
    the amount of blood in the ventricle, I.e. the
    end-diastolic volume.
  • This is called the PRELOAD.

59
Afterload
  • When a muscle contracts against an opposing
    force, we can call that force to be overcome the
    AFTERLOAD.
  • AFTERLOAD. If you can generate 25 lbs of force,
    but you grab 40 lb weights, you will be unable to
    move the weights. Your biceps cannot overcome the
    afterload. Example When the left ventricle
    begins to contract, the valve between it and the
    aorta (the aortic valve) is closed and there is
    high pressure (maybe 70 mmHg) out there in the
    aorta.

60
CONTRACTILITY
  • The innate property of a muscle is to
    contract. This can be altered with a variety of
    inotropic agents, (such as, catecholes,
    digitalis, phosphodiesterase inhibitors).
  • Why would you do this? Usually this is done
    because the contractility has been diminished by
    whatever disease process is going on.

61
Pressure-Volume Curve
62
ISOMETRIC CONTRACTION
  • Isometric contraction occurs where the muscle is
    prevented from shortening. Examining such
    preparations we find that when we "preload" the
    muscle (stretch it by adding weight before
    stimulation) then there is an increase in the
    tension that the muscle develops when stimulated.
    The time to development of peak tension remains
    the same, implying that the rate of tension
    development also increases as does the preload.

63
ISOTONIC CONTRACTION
  • Isotonic contraction is slightly more complex -
    the muscle is preloaded, and then prevented from
    stretching any further. A further load is then
    added (the "afterload") and the muscle is allowed
    to shorten when stimulated. Because the
    stimulated muscle can shorten, lifting the load,
    the force that the muscle "isotonic" - that is,
    throughout contraction the force is constant.
    Here the physiologist can measure both change in
    length and change in force with respect to time.

64
The effect of inotropy
  • Inotropy is the term applied to changes in heart
    muscle performance independent of alterations in
    preload and afterload. This implies that any one
    of the active function curves that we plot will
    alter once the inotropic state of the myocardium
    changes. The curve commonly used to assess
    inotropy is the isometric length-tension curve -
    a positive inotropic stimulus shifts the curve up
    and to the left, and a negative stimulus down and
    right.
  • Inotropy varies with a variety of factors,
    including increases associated with increased
    frequency of contraction and the effect of
    post-extrasystolic potentiation, as well as
    catecholamines, glucagon, and inotropic drugs
    and decreases with myocardial isch
  • Inotropy decreases, heart failure, and depressant
    agents (including almost all anaesthetics).

65
Dicrotic Notch
66
(No Transcript)
67
Ejection Fraction
  • Stroke Volume
  • End Diastolic Volume

68
(No Transcript)
69
EINTHOVENs LAW
  • The electrical potential of any three bipolar
    leads can be determined mathematically from
    summing the values of the first two

70
(No Transcript)
71
Hexial Reference System
72
CHEST LEADS
73
Precordial Chest Lead Positioning
  • 1. V1 is placed in the fourth intercostal space
    to the right of the sternum.2. V2 is placed in
    the fourth intercostal space to the left of the
    sternum.3. V3 is placed in between V2 and V4.4.
    V4 is placed in the fifth intercostal space in
    the midclavicular line near the nipple.5. V5 is
    placed in between V4 and V6.6. V6 is placed in
    the fifth intercostal space in the midaxillary
    line.

74
Lead-views
75
(No Transcript)
76
(No Transcript)
77
Normal EKG
78
P WAVE
  • P Waves represents depolarization of the atrial
    myocardium. (Sinus node depolarization is too
    small in amplitude to be recorded from the body
    surface so it is not seen.)
  • Not wider than 0.12-.2 sec (under 3 little boxes
    on the ECG paper).
  • Not taller than 3 mm.

79
Normal QRS Characteristics
  • 0.07-0.11 sec in width. QRS widths often vary in
    different leads. The widest QRS measurement on
    the 12-lead ECG is the correct one. Best leads to
    look at are usually leads I and V1.
  • Should not be smaller than 6 mm in leads I, II,
    and III and nor should it be taller than 25-30 mm
    in the precordial leads.

80
Q-T Interval
  • QT Interval measurement of the refractory
    period or the time during which the myocardium
    would not respond to a second impulse measured
    from the beginning of the QRS complex to the end
    of the T wave.
  • If there is a U wave visible, the measurement
    is made to the end of the U wave and is called
    the Q-TU interval.
  • Q-T interval should be roughly less than half
    the preceding R-R interval.

81
R-Wave Transition
82
ST-DEPRESSION
83
Digitalis effect Due to K Flux
  • Shortened QT interval
  • Characteristic down-sloping ST depression,
    reverse tick appearence, (shown here in leads V5
    and V6)
  • Dysrhythmias
  • Ventricular / atrial premature beats
  • Paroxysmal atrial tachycardia with variable AV
    block
  • Ventricular tachycardia and fibrillation
  • many others

84
1st Degree Heart Block
85
2nd degree AV block
86
Mobitz Type I (Wenckebach)
87
2nd degree (MOBITZ II)
88
3rd Degree Heart Block
89
RBBB
90
LBBB
91
SA BLOCK
92
Idioventricular Rhythm
93
ESCAPE BEATS
94
Ischemia
95
(No Transcript)
96
Various PVCs
97
V-TACH
98
MEAN QRS AXIS DETERMINATION
99
(No Transcript)
100
(No Transcript)
101
Tachycardias
  • In adults and children over 15, resting heart
    rate faster than 100 beats/minute is labelled
    tachycardia. Tachycardia may result in
    palpitation however, tachycardia is not
    necessarily an arrhythmia. Increased heart rate
    is a normal response to physical exercise or
    emotional stress. This is mediated by the
    sympathetic nervous system on the sinus node and
    called sinus tachycardia. Other things that
    increase sympathetic nervous system activity in
    the heart include ingested or injected
    substances, such as caffeine or amphetamines, and
    an overactive thyroid gland (hyperthyroidism).

102
(No Transcript)
103
(No Transcript)
104
INOTROPIC EFFECT
105
MUSCLE-NERVOUS Conduction
106
Saltatory Conduction
  • Saltatory conduction is the process that allows
    for electrical conduction to bounce between the
    nodes of ranvier in the extracellular fluid.
  • Remember that peripheral nerves are coated with a
    lipoprotein rich myelin sheeth.

107
PROTON PUMP
108
(No Transcript)
109
Muscle Contraction
110
Characteristic of Potentials
  • THRESHOLD
  • ABSOLUTE REFRACTION
  • RELATIVE REFRACTION
  • STRENGTH OF POTENTIAL
  • FREQUENCY

111
Nerst Equation
  • V R T
  • 2 f

112
Sodium Channels
113
SMOOTH MUSCLE
114
(No Transcript)
115
Potential ChannelsSodium/Calcium/Potassium
(ATPase used)
116
POST SYNAPTIC MEMBRANE POTENTIAL
  • EPSP- AchE/Glutamate (-) Na gated-
    (depolarizing)
  • IPSP- Glycine/ Gaba ()
  • Cl-/K (hyperpolarization)

117
Muscle Action Potential
118
Action Potential
  • All or nothing- One value
  • Depends on Voltage regulated Gates
  • Threshold dependent
  • Continuous or saltatory

119
THE NERVE
120
NERVES
  • Typing
  • A- most rapid
  • B-non-mammalian
  • Types I, II, III, and IV
  • I is largest with greatest conduction
  • IV is Unmyelinated
  • Myelin lowers resistance somewhat, but greatest
    effect is increasing capacitance

121
Neural Cleft
122
(No Transcript)
123
Fast Sodium Channels
124
Fast/Slow Channel
125
Action Potential with Chemistry
126
Excitation/Contraction Coupling
127
Actin/Tropomyosin
128
(No Transcript)
129
Muscle Contraction Steric Hinderance Model
130
(No Transcript)
131
Power/ Workload Curve
132
(No Transcript)
133
(No Transcript)
134
Acetylcholine Receptor
135
(No Transcript)
136
Normal vs. Myastenia Gravis
137
ADENYL CYCLASE
138
(No Transcript)
139
(No Transcript)
140
KIDNEYS
141
Renal Clearance
  • Cx Ux V/Px
  • This equals volume of plasma from which the
    substance is cleared completely/ per unit time

142
Free Water Clearance
  • CH20 V-Cosm
  • V urine flow rate

143
Filtration Fraction
  • FF GFR/RPE
  • GFR C insulin
  • RPF C PAF

144
(No Transcript)
145
(No Transcript)
146
THE LUNGS
147
(No Transcript)
148
RENAL BLOOD FLOW
149
(No Transcript)
150
BRONCHI
151
ALVEOLI
152
(No Transcript)
153
Laminar and Turbulent Flow
154
Pouisselles Law

155
(No Transcript)
156
DIFFUSION
  • Directly related to (solubility and diffusion
    coefficient) and the
  • Driving pressure (force)
  • 760 mmHg is atmospheric
  • 47 mmHg is water vapor pressure

157
Henrys Law
  • PressConcentration of dissolved gas
  • Solubility coefficient

158
Solubility coefficient
  • Oxygen------------------.024
  • Carbon dioxide---------.57
  • Carbon monoxide------.018
  • Nitrogen-----------------.012
  • Helium-------------------.008

159
RESPIRATORY MEMBRANE
  • HAS 6 DIFFERENT LAYERS
  • FLUID IN THE ALVEOLI
  • TYPE I- SQUAMOUS/TYPE II EPITHELIUM
  • BASEMENT MEMBRANE (ALVEOLAR)
  • BASEMENT MEMBRANE OF CAPILLARY
  • DISTANCE TO BLOOD VESSEL
  • LIPID MEMBRANE OF RBC

160
What factors effect diffusion
  • THICKNESS
  • SURFACE AREA
  • DIFFUSION COEFFICIENT
  • PARTIAL PRESSURE DIFFERENCES

161
V/Q (VENTILATION/PERFUSION) RATIO
  • THE IDEA IS TO MATCH VENTILATION AND PERFUSION AS
    WELL AS POSSIBLE IN THE VARIOUS LUNG ZONES
  • Physiologic shunt
  • Ventilation reduced relative to blood flow
  • Perfusion without ventilation
  • Physiologic dead space
  • Ventilation occurring without perfusion

162
Physiologic shuntEquation
  • Qs CIO2 CaO2
  • Qt CIO2 CvO2

163
Physiologic dead spaceEquation
  • Vd PaCO2 PeCO2
  • VT PaCO2

164
OXY-HEMOGLOBIN CURVE
165
The Respiratory Center
  • 3 major groups
  • Dorsal respiratory group
  • (inspiratory ramp)
  • Ventral respiratory group
  • (cuts off inspiratory ramp)
  • Pneumotaxic center
  • Other
  • Hering Breuer reflex that can switch off the
    inspiratory ramp when Vt get to 1.5 L

166
Chemical control of breathing
  • Central Receptor (PONS)
  • Special blood supply at glossophayrngeal nerve
  • Carbon Dioxide (Primary)
  • Increased CO2 as in emphysema
  • Oxygen (Secondary)
  • PaO2 fall below 60 mmhg
  • J- Receptors do exist juxta positional in the
  • ALVEOLAR WALL
  • Pulmonary damming

167
Types of Respiratory Patterns
  • Periodic breathing
  • Consider abnormal (10-20 second pauses)
  • Cheyne-Stokes
  • Cerebral brain damage (starts and stops)
  • Apneustic
  • Occurs at pons, shuts off insp ramp
  • Apnea Pauses in breathing greater than 20 seconds
  • Kussmaul
  • AT MIDBRAIN, can be seen in keto-acidosis,
  • Very fast, deep, regular breathing

168
(No Transcript)
169
(No Transcript)
170
Medium Flow
171
HIGH-FLOW
172
Lung Zones
173
(No Transcript)
174
(No Transcript)
175
(No Transcript)
176
(No Transcript)
177
(No Transcript)
178
(No Transcript)
179
Direct Fick Equation Gold Standard
180
Lung Volumes
181
(No Transcript)
182
Lung Volumes
  • Tidal Volume (VT) - the difference in volume
    between peak inspiration and peak expiration
    during tidal breathing. Measured with spirometry.
    The volume of the VT for normal individuals at
    rest is approximately 0.5 liters. When
    exercising, the VT increases to 1.5 - 2 liters
  • Vital Capacity (VC) - The difference in volume
    between the maximum possible exhaled and inhaled
    volumes. Measured with spirometry. A normal value
    for the VC is approximately 5 - 6.5 liters.
  • Residual Volume (RV) - Volume of gas that
    remains in the lungs at the end of maximum
    expiration. Measured with a body plethysmograph

183
Restrictive Lung Disease
184
Lung Volumes
  • Expiratory Reserve Volume (ERV) - The difference
    in volume between peak expiration during tidal
    breathing and maximum possible expiration.
    Measured by spirometry.
  • Inspiratory Reserve Volume (IRV) - The
    difference in volume between peak inspiration
    during tidal breathing and maximum possible
    inspiration. Measured by spirometry.
  • Functional Residual Capacity (FRC) - Volume of
    air remaining in the lungs after exhalation
    during tidal breathing. Measured by helium
    dilution technique.
  • FRC ERV RV.
  • Total Lung Capacity (TLC) - Maximum volume of
    gas that the lung can contain.
  • TLC VC RV.

185
Measurement of FRC
  • Helium Dilution Method
  • i. If we have a close system of known volume and
    concentration of helium, and then let the system
    equilibrate at some new volume and measure the
    resulting equilibrated helium concentration, we
    can determine the volume of the lung.
  • ii. V2 in most measurements is the FRC.
  • iii. In reality the measurement is complicated by
    the fact that oxygen is continuously absorbed
    into the blood, and CO2 is continuously released.
    This could cause a change in partial pressures of
    the system and therefore measurements of volume
    would be incorrect. This is remedied by supplying
    oxygen continuously and absorbing the CO2.
  • iv. Helium is the tracer of choice since it is an
    inert gas and will not react with other metabolic
    components, and does not readily diffuse across
    the alveolar-pulmonary capillary barrier.

186
(No Transcript)
187
(No Transcript)
188
COPD
  • Chronic obstructive pulmonary disease (COPD) has
    historically included the spectrum of chronic
    bronchitis and emphysema, with overlaps the most
    common presentation of disease. More recently it
    has been recognized that an old designation,
    asthmatic bronchitis, should also be included in
    the COPD spectrum because there are often
    asthmatic features in COPD, including nonspecific
    bronchial hyper-reactivity and atopic features
    that are interrelated with smoking. Evidence of
    smoking-related airway inflammation has been
    identified by bronchoalveolar lavage in chronic
    bronchitis. Taken together, these findings and
    concepts suggest that reversible features of COPD
    are often present that may be amenable to
    therapeutic intervention. These interventions
    include smoking cessation and the use of
    anti-inflammatory drugs. A significant number of
    patients with COPD experience increased airflow
    with the use of inhaled bronchodilators.

189
(No Transcript)
190
Bernoullis Principle
191
Venturi Effect
Write a Comment
User Comments (0)
About PowerShow.com
