• Building Components

• Sub-Structure

• Super structure

• Type Of Structure

• Load Bearing Structure

2. Frame Structure
3. Composite structure
3
BUILDING COMPONENTS

1. Floor
2. Wall
3. Column
4. Plinth
5. Beam
6. Roof
7. Door Windows
8. Lintel
9. Sill
10. Staircase
11. Parapet

4
rSub-Structure
A part of the structure lying below the ground
surface such as foundation of any type is known
as sub-structure
5
Foundation

• The term foundation indicates the entire
  sub-structural unit which support the
  superstructure. Thus the broader sense
  foundation includes a transmitting medium.

6
Super structure

• Superstructure denotes part of the structure
  lying above the ground surface. In context of
  buildings various part like wall, roof , door
  and window flooring constitute the
  superstructure.

7
Types of structures
1) Load bearing structure

• In this type of construction, load of the
  structure is transferred to the walls as roof,
• Floors are directly supported on walls.

8
2) Frame structure

• In frame structure load is transferred through a
  frame of slab, beam, column and footing to the
  underlying soil.

9
3) COMPOSITE STRUCTURE

• The outer walls can be of load bearing type where
  as column and beam structure can be provided
  internally.

10
