Security Aluminium Roller Grilles

1
SECURITY ALUMINIUM ROLLER GRILLES
Stay Safe and Secure with Top Quality Commercial
Grilles
2
SECURITY ALUMINIUM ROLLER GRILLES
Maverick Security Roller Grilles can be used in a
variety of commercial applications. They are
suitable for both internal or external
installations. They not only ensure safety but
also allow visibility and airflow.

www.maverickrollerproducts.com.au
3
FEATURES
CURTAIN COMBINATIONS
Maverick Roller Products offer a unique feature.
Our various curtains like Polyview, Series 1,
Series 2 and Security Grill can be used for
creating different combinations. The curtains
have the same appearance from both the sides.
www.maverickrollerproducts.com.au
4
SPECIFICATIONS
SIZE Size of every security aluminium roller
grill is up to a width of 3.6m or a total of 9
square metres.
CURTAIN The curtain is manufactured by
alternating and interlocking 80mm or 100mm x 20mm
x 1.5mm extruded aluminium links with 30mm
extruded aluminium slats, in 6063-T5 alloy for
the purpose of creating a continues hinge.
www.maverickrollerproducts.com.au
5

• BOTTOM RAIL
• The bottom rail can be used as a mid rail lock at
  any position in the door which is manufactured
  from an extruded aluminium section.
• The bottom rail foot comes in two options
• One extrusion with the bottom rail.
• Separate extrusion as a add on.

LOCKING The standard locking position provides
double sided lock with operation from both inside
and out.
www.maverickrollerproducts.com.au
6
SIDE GUIDES The guides are manufactured from an
extruded aluminium section 50mm deep x 31mm wide.

MULLIONS Standard 180 degree mullions are
manufactured from an extruded aluminium section
130mm deep x 31mm wide and shall be lift out
types with shoot bolts to the base.
www.maverickrollerproducts.com.au
7
BRACKETS Manufactured by slotted 90mm x 40mm mild
steel.
DRUM It is manufactured by 200mm diameter spiral
ducted tube attached to mild steel wheels with
fully enclosed ball bearings which rotate around
a 34mm steel shaft with next to no friction.
www.maverickrollerproducts.com.au
8
OPERATION Simply push up and pull down operation
with supplied pull pole. Doors can be
electrically motorised through push button,
remote control or key switch operation.
FINISH Clear anodised standard colour powder
coating as an option in dulux powder coat range.
www.maverickrollerproducts.com.au
9
Maverick Roller Products Pty Ltd
2/52 Alfred Road Chipping Norton NSW 2170,
Australia
02 9755 4055
61 2 9755 0427
info_at_maverickrollerproducts.com.au
www.maverickrollerproducts.com.au
