Display Advertising LED Display India
WELCOME TO UH LEDISPLAY INC
2
UH-P10 - Display Advertising
3

• Product Function - Product
  Features
• Excellent visual effect, clear and exquisite
• Good flatness
• Easy to clean ,welding spots inoxidizable
• Closer look available, better effects without
  glare and mosaic

4

• Product Function - Product Features
• Good viewing angle
• Easy to assembly, install and transport with
  simple packing and convenient use
• Vivid mixed colors
• no color cast when look from different angles
• Excellent heat-sinking, high stability ,no
  scrapped lamp

5
Application and Functions Advertising LED
display, shopping mall LED display for logo
showing, bank stock exchange LED display for
rates showing , train bus station, airport ,
telecommunication LED screen system for
information showing and instruction , Stage
performances and so on.
6
UH - P10 - Display Advertising
7
Outdoor Full Color LED Display -- P 10
8
Module Parameters
Pixel Pitch 10mm
LED Configuration DIP (1R 1G 1B)
Module Size 160mm X 160mm
Module Resolution 16dots X 16dots
Module Pixels 256 dots
Module Weight 0.5 Kg.
9
Cabinet Parameters
Cabinet Size 960mm X 960mm
Area 0.92m2/Cabinet
Cabinet Resolution 96dots X 96dots
Cabinet Pixels 9216 dots
Module Quantity 36
Pixel Desity by Area 10000dots / m2
Lose Control Rate / Blind Spot Ratio Less Than 0.03, The Discrete Distribution
Cabinet Weight 60 KGS
10
Display Parameters
Brightness 8000 cd/m2
Viewing Distance 10m.
Viewing Angle Horizonatl 120 / Vertical 60
Life Time 100000 Hours
Operating Temperature 40 C To 60 C
Operating Humidity 10 85
Operating Voltage AC220V 10 / AC380V10, 50hertz10
11
Display Parameters
Maximum Power 1000 W/m²
Average Power 500 W/m²
Control Method Synchronous
Frame Frequency 60 Hz
Refresh Frequency 400 Hz, Max 1000 Hz
Gray Level 4K
12
Control System
Communication Distance lt100M (BY CAT 5 NET CABLE),500meters of muti-mode optical fiber1000meters of single-mode optical fiber
Brightness Adjustment Manual Or Auto Adjustible
Grey Scale 10 Bit/Color
LED Driving Method 1/8 Static Scan Constant Current Drive
Control System LED Special Video Card Professional LED Control System
Input Signal HDTV / PAL / S-Video / VGA
13
Display Advertising LED Display
India UHLEDISPLAY INC. is a leading
Manufacturer, Supplier and Service Provider of
Display Advertising LED in India.
