Melting Point Apparatus & ESCR Apparatus

Description:

1.Melting Point Apparatus - It is usable to estimate the Melting Point of chemicals, Pharamaceuticals, Food Etc., This is very useful to determine the melting point if any subsatance. Max Temp. up to 3500C. Consist with aluminium cylindrical block for heating, Radial holes admits a thermometer and glass capillary. Temp. Controlled by energy regulator. Regulator fitted ti the unit and with high, low heat switch. 2. ESCR Apparatus - E.S.C.R. Apparatus is used for determination of suceptibility of ethylene plastics to environmental stress cracking when subjected to certain conditions. Bent specimens of the plastics each having a controlled imperfection on the surface are exposed to the action of a surface active agent, oils or detergent. The proportion of the total number of specimens that crack in a goven times is observed. – PowerPoint PPT presentation

Number of Views:234
Slides: 6
Provided by: shambhavi786

less

Transcript and Presenter's Notes

Title: Melting Point Apparatus & ESCR Apparatus


1
SHAMBHAVI LAB INSTRUMENTS
Presentation on 1.Melting Point
Apparatus 2. ESCR Apparatus

Contact us http//www.tensiletestingmachineutm.c
om
2
1. Melting Point Apparatus
  • It is usable to estimate the Melting Point of
    chemicals, Pharamaceuticals, Food Etc.,
  • This is very useful to determine the melting
    point if any subsatance.
  • Max Temp. up to 3500C. Consist with aluminium
    cylindrical block for heating, Radial holes
    admits a thermometer and glass capillary.
  • Temp. Controlled by energy regulator.
  • Regulator fitted ti the unit and with high, low
    heat switch.

3
2.E.S.C.R. Apparatus.
E.S.C.R. Apparatus is used for determination of
suceptibility of ethylene plastics to
environmental stress cracking when subjected to
certain conditions. Bent specimens of the
plastics each having a controlled imperfection on
the surface are exposed to the action of a
surface active agent, oils or detergent. The
proportion of the total number of specimens that
crack in a goven times is observed.
4
Specifications
Specification Accessories

Insode bath is of S.s. and outside bath 1 Blanking dle 1No.
is M.s. with heat insulation. 2 Nicking jig 1No.
The heating system is having a RTD, 3 Bending cum transfering device 1No.
Heater and digital temp. Controller (PID) 4 Specimen holder 10Nos.
Max. Temperature 1500C 5 Test Tubes 10Nos.
Max. Temperature - R.T., Resolution 0.100C 6 Corks 10Nos.
Accuracy 0.500C

5
THANK YOU !
Contact us http//www.tensiletestingmachineutm.c
om
