torque TESTING MACHINE MODEL & Bend Rebend Machine

1
SHAMBHAVI LAB INSTRUMENTS

Presentation on 1.torque TESTING MACHINE
MODEL  2. Bend Rebend Machine
Contact us http//www.tensiletestingmachineutm.c
om
2
1. Torque TESTING MACHINE MODEL

• Digital torque Testing Machine is designed to
  perform torque Test on Insulator of varying
  heights and for similar application on other
  products. Multiple drive options are available to
  suit customer requirement.
• The applied torque is displayed digitally with
  facility to display peak torque at end of the
  test.

3
1. Torque TESTING MACHINE MODEL..

• T-slots are provided on the mounting table to fix
  insulators of varying base dimension. The
  vertical spacing between the base plate and the
  coupler is adjustable through motorized
  operation.
• Front door is provided for the safety of operator
  during the test. Additionally emergency switch is
  provided to disable the drives.

4
Leading Specifications
 Capacity
1,000 NmAccuracy
Better than /- 1 in the torque range 5 to
F.S.torque Speed 0.5
RPMVertical Clearance 200-750mm
(motorized adjustment at 300mm/min)Mounting
plate 300mm Dia. with
T-slots at 900, for up to M12 boltsTable Height
600mmMeasurement
Digital (kg.m/Nm.
Microprocessor basedPower Supply
415V /-1, 3-phase,50 HzConnected Load
0.5KVADimensions
600x450x1800mm (WxDxH)Weight
400 KgPC
Interface RS232
(Optional)

5
2. Images of Bend Rebend Machine
6
THANK YOU !
Contact us http//www.tensiletestingmachineutm.c
om
