Electromagnetic Clutch brake Combination

1

• Electromagnetic Clutch brake Combination
• http//www.excelclutchbrake.com/

2

• Introduction
• Electromagnetic clutch brake combination is
  used where there is frequent start and stop.
  (High frequency operation) In this case the motor
  is kept running continuously. The clutch is
  connected to the motor shaft and the brake is
  connected to the gearbox or output shaft. At this
  stage also the motor is still rotating but the
  drive is not transmitted since the clutch is
  disengaged.

3

• Salient features
•   Popularly know as CBC Clutch Brake
  Combination
• Ready to use factory fitted Aligned. Simple
  installation. Completely enclosed.
• Aluminium body for Good Heat dissipation light
  weight.

4

• Versatile design, with Hollow Input and Output
  shafts and B5 flange mountings for input and
  output available.
• Asbestos free liner is used.
• Works on 12/ 24 / 42 / 90 V DC, 2 Phase supply.

5

• Applications
•
• Textile machinery
• Wire drawing machines / Cut to Length machines /
  Coil winding machines
• Printing and Packaging machines / Bag making
  machines
• Powder and Liquid filling machines / Bottling
  plant machines
• Industrial Automation

6

• Contact as
• Mobile- 9414167841
• Web- http//www.excelclutchbrake.com
• Plot No. 14, Krishna Vihar, New Vidhya Nagar
• Hiran Magri, Sec. 4, Udaipur, Rajasthan - 313
  001, India
