Support Maker
2
Support Maker Functionality

• 3d printing is most common affordable
  technology for rapid prototyping production.
• DLP technology has drastically cut-down the
  onetime recurring production cost.
• But the most challenging part of this technology
  is support placement.
• Support placement is temporary arrangement, It is
  not part of the final print, but requires at the
  time of printing.
• Support Maker is an answer to this tedious
  time-consuming manual support placement task.
  Support Maker gives advance option for support
  generation process.
• Software takes care for automatic support
  placement as well as gives facility to place
  manual support. Software has inbuilt defined
  layer-thickness slicing mechanism.

3
Some of the advantages of this software

• Software available in two version
• a) Rhino extension or plug inn
• b) Standalone software with advance slicing
  facility.
• No need to hire skilled person for
  support-placement
• Bamboo tree-like both support are possible to
  generate.
• Easy quick support placement, anyone can learn
  in 30minute training.
• Software shows critical area where placement of
  support is essential. (shows in different color)
•

4
Some of the advantages of this software

• Facility to change support-point width, so it is
  easy to remove.
• Facility to change support thickness, to save
  resin.
• Based on design user can change distance between
  supports, that ultimately saves resin.

5
Some of the advantages of this software

• Facility to set support base plat radius its
  thickness, it ultimately saves resin cost gives
  speed in printing.
• Facility to create various platform size
  profiles, so single software we can use for
  multiple printers.
• Facility to generate whole platform zip file, so
  we can directly use in printer software.
• Facility to change support length width as well
  as add, edit, delete support.
• Software allows loading bigger size of objects
  compare to other free paid software. With 2GB
  graphics card, 16GB RAM, it allows to load single
  or multiple objects up to 700MB.
• Fastest slicing time, as software uses computer
  graphics card memory for processing.

6
Some of the advantages of this software

• Supports large number of files for slicing (STL,
  OBJ, SLC, 3DS)
• Smooth rotate, move, scale object with mouse and
  keyboard shortcuts.
• Facility writes user-defined object
  identification number, so it gets printed
  near the object base-plate.
• For bamboo like support, user has to click on
  location, where user
• wants to add or generate support.

7
Some of the advantages of this software

• For tree like support, user selects multiple
  locations click generate tree button.

8
Some of the advantages of this software

• User defines functionality call Support Shape. We
  are given 4 different levels as shown in below
  image to modified support shape as per 3d model
  requirement.

9
Some of the advantages of this software

• Facility to change the location of support and
  that support height will automatically reset
  based on their new location.
• User can select multiple supports at a time
  edit all the selected supports at the same time.
• User can see down polygon at particular angel,
  this angel value is also user define. In Below
  image Blue color indicates down polygon at 45
  degree.

10
