Chocolate PTCA Balloon Catheter

1
Solutions for Complex Cases
Get Into the Groove
Leave Nothing Behind
2
The control you need to create a

• Chocolate is designed to reduce vessel trauma by
  providing a balloon in?ation that is
• Predictable
• Controlled
• Uniform
• Atraumatic

Unique Nitinol Constraining Structure offers key
benefits Constraining Structure Protects the
vessel from shear stress caused by balloon
in?ation
Dilatation Pillows Vessel dilatation without
cutting or scoring
Plaque Channeling Grooves Stress relief and
plaque modi?cation
3
uniform, atraumatic dilatation
Challenge Acute Vessel Trauma Inflation with
conventional balloons can result in vessel trauma
which often leads to dissection. There are
three primary reasons for this to occur
Less trauma better acute results
4
Leave Nothing Behind
Constraining Structure Nitinol
Shaft Rapid Exchange (RX)
Size Matrix
Catalog Number
Balloon Diameter (mm)
Balloon Length (mm)
Nominal Pressure (atm)
Rated Burst Pressure (atm)
French Size Compatibility
10
CH14-140-2010 RX
5F
16
10
2.0
16
10
15
2.0
CH14-140-2015 RX
5F
20
CH14-140-2020 RX
5F
16
10
2.0
16
10
10
2.5
CH14-140-2510 RX
5F
15
CH14-140-2515 RX
5F
16
10
2.5
16
10
20
2.5
CH14-140-2520 RX
5F
10
CH14-140-3010 RX
6F
16
10
3.0
16
10
15
3.0
CH14-140-3015 RX
6F
20
CH14-140-3020 RX
6F
16
10
3.0
16
10
10
3.5
CH14-140-3510 RX
6F
15
CH14-140-3515 RX
6F
16
10
3.5
16
10
20
3.5
CH14-140-3520 RX
6F
Indications for Use The Chocolate PTCA Balloon
Dilatation Catheter is indicated for balloon
dilatation of the stenotic portion of coronary
artery or bypass graft stenosis for the purpose
of improving myocardial perfusion.
Contraindications The Chocolate PTCA Balloon
Dilatation Catheter is contraindicated for use in
unprotected left main artery, coronary spasm,
post-dilatation of balloon expandable stents or
for crossing through deployed stents or stent
struts. WarningsDo not use in the presence of a
freshly deployed stent. The Chocolate PTCA
Balloon Catheter has not been tested for the
treatment of in-stent restenosis and
post-dilatation of stents or advancement through
stents or synthetic vascular grafts. STERILE
product. One time use only. Re-sterilizing or
re-using may compromise the structural integrity
of the device and may create a risk of
contamination which, in turn, may result in
health risks to patients. The inflated diameter
of the balloon should correspond to the diameter
of the vessel for treatment. See IFU for more
detail. MRK432
