Features and specification of Electric Control panels

1
Features and specification of Electric Control
panels By
S.B. Electricals Equipments Pvt. Ltd. All
Rights Reserved
www.sbcontrolpanels.com
2
Different types of Electric Control panels
S.B. Electricals Equipments Pvt. Ltd. All
Rights Reserved
www.sbcontrolpanels.com
3
On based of Voltage

• LT Distribution Board 2-Way 15 A, 250 V
• 2) LT Distribution Board 4-Way 50 A, 440 V etc.

S.B. Electricals Equipments Pvt. Ltd. All
Rights Reserved
www.sbcontrolpanels.com
4
Auto Mains Panel (AMF)
Auto Mains Panel (AMF) - Only D.G. Control AMF
panel includes automatic mains failure detection
and starting the D.G. set and putting it
online with current limit, battery charger, power
inverters, automatic changeover and sine wave
inverters.
S.B. Electricals Equipments Pvt. Ltd. All
Rights Reserved
www.sbcontrolpanels.com
5
Motor Control Center Panel (MCC)
    Shock resistance    Compact size
 Precisely engineered    Available with Single
/ Double door design.    MS Sheet with PU Paint
/ Poweder coat.    Easy to Cable laying
Termination design.    Connection details
fixing at panel's Door.    Fix / Draw out both
type Starters.    Cable entry Top / Bottom as
per requirement.    Copper / Aluminum busbar
with P.V.C shrinkage sleeve.    Tinning to
copper busbar for prevent corrosion.
 Available protection IP54, IP55 / IP64,
IP65.    Design of panel is practically work
use to human operation.
S.B. Electricals Equipments Pvt. Ltd. All
Rights Reserved
www.sbcontrolpanels.com
6
LT Distribution Board

• We Introduce Ourselves As A Manufacturers of
  Electrical Control Panels,
• A.C D.C Drives
• L.T Distribution board
• 800 A.C D.C Drives From Fractional HP to 600
  HP Above In Modular Form And As Well As In
  Customized PLC based Panels.
• We Are Excusive OEM Suppliers a brief list of
  our OEM is attached herewith, We Are Also
  Manufacturing The L.T Panels, Power Panels etc.
  for the project according to the Constant
  Parameters.

S.B. Electricals Equipments Pvt. Ltd. All
Rights Reserved
www.sbcontrolpanels.com
7
