Full Control Battery Monitor

1
INTRODUCING
2
Full Control Battery Monitor
https//www.amperis.com/en/products/misc/battery-c
hargers/battery-monitor/
3
About Amperis

• Amperis sells latest generation
  instrumentation for testing, transformation
  diagnosis, thermographic inspection and
  electrical distribution.Our job is to understand
  your goals and locate the electrical / electronic
  equipment that best suits your needs, whether or
  not included in our catalog. For this, we are at
  the forefront of Electrical Technology and we are
  in constant contact with leading manufacturers at
  international trade shows.

4
Amperis
5
Amperis battery monitor
This Amperis Battery monitoring Solution is an
integrated battery Monitor, Controller and
Data-logger, designed to be installed on
batteries of any type, voltage and capacity. It
measures and logs all relevant operating
parameters of the battery and it communicates in
real time through CANBUS, PWM or RS-232
interfaces, allowing a complete integration with
the vehicle Control System, the Charger and other
accessories.
The ultimate battery control and protection
system Dust-proof and vibration proof HV
isolated CANBUS interface Sealed connections Very
easy to install and configure Robust enclosure,
made of acid and oil resistant materials (IP 54)
6
Full Control Battery Monitor
All the thresholds are customizable by the user,
through a simple PC based interface (Configurator
Software) The monitor can manage the entire
charge process, by controlling battery chargers
through CANBUS and/or PWM signals. A built-in
auxiliary relay provides an additional level of
protection and can be used as a remote alarm
signal.
7
This Suite is a complete tool set that allows you
to control, manage and configure your device.
8
Real time monitor connect to your monitor and
see all measurements in real time. The quickest
tool to verify the proper operation and
configuration of the module.
9
Contact Us

• Address
• Amperis Products S.L. Agricultura 34, 27003 Lugo
  Spain
• T (34) 982 20 99 20
• F (34) 982 20 99 11
• E info_at_amperis.com

https//www.amperis.com/en/products/misc/battery-c
hargers/battery-monitor/
10
THANK YOU FOR VISITING
