Title: amperisseo- Primary Current Injector


1
Introducing
http//www.amperis.com/en/products/relay-testing/a
pci600/
2
Primary Current Injector
3
About Amperis
Amperis sells latest generation instrumentation
for testing, transformation diagnosis,
thermographic inspection and electrical
distribution.Our job is to understand your goals
and locate the electrical / electronic equipment
that best suits your needs, whether or not
included in our catalog. For this, we are at the
forefront of Electrical Technology and we are in
constant contact with leading manufacturers at
international trade shows.Amperis is a trade mark
registered in the whole European Union, Amperis
Products SL has the exclusive right to use, click
here to check the trade mark certificate.Amperis
products can already be founded in 43 countries
(look here at the list of countries).
4
As a commitment to the environment Amperis
company is registered as a producer of electronic
equipment to the Ministry of Industry (with
number REI-RAEE 5168), also has hired a
foundation for recycling equipment just once
life, see certificate here. And ISO-90012008
5
The APCI-600 is a programmable AC high-current
source designed specifically for
utility-substation applications. This device is
well suited for primary injection testing of
protective relays. This versatile device can also
be used for testing thermal, magnetic, and
solid-state motor-protection relays and
molded-case circuit-breakers, as well as any
application that requires a high-current source.
Built-in Timer
The APCI-600s built-in timer can test the time
delay characteristics of protection relays and
molded-case circuit-breakers. Once the test is
initiated, the current source and the timer are
automatically turned on at the next zero crossing
point of the AC. The timer stops when the
APCI-600 input detects a change in the dry
contact or voltage input, or detects the removal
of the test current. The test results are then
displayed in milli-seconds and fractions of a
cycle(s) on the units back-lit LCD screen (20
characters by 4 lines).
External Current Input
The APCI-600 also has an external-current input
(0 10 A). Both the internal current source
amplitude and the external current source
measurement readings can be viewed at the same
time.
6
Current Source
Test currents, ranging from 100 to 600 amperes,
can be set by using the rotary dial knob on the
control panel. The test current is then measured,
and the results are displayed on the LCD screen.
When the APCI-600 is used as a current source,
the current-on time (duration of current flow) is
displayed on the LCD screen.
Connections Primary Current Injection Source
APCI-600
7
(No Transcript)
8
  • Contact form
  • Amperis Products S.L. Agricultura 34, 27003 Lugo
    Spain
  • T (34) 982 20 99 20
  • F (34) 982 20 99 11
  • Email info_at_amperis.com

http//www.amperis.com/en/products/relay-testing/a
pci600/
9
Thank you for visiting
