Channel Letter Bending Machine

1
Channel Letter Bending Machine Manufacturer
2
Channel Letter Bending Machine also called as CNC
letter bending machine or Channel letter Bender
is the new advertising production equipments
which are used for logos, signs, neon signs,
outdoor advertising, billboards, light boxes
production and other advertising applications.
Applicable Materials are Aluminum strip bending,
iron bending, stainless steel strip bending,
galvanized steel bending, etc.
3
A unique three-dimensional process simulation
technology and two-dimensional design file to be
able to display three-dimensional effects,
supplemented by zoom, translation, rotation and
other functions which enables full observation
and also in monitoring of working process
completely.
4
The original double-bent knife with parallel
bending technology help in saving time and
greatly improve the processing efficiency of the
system until the maximum bending angle reaches
130 curve. High precision machining and feeding
precision can reach a level of 0.01mm with
bending accuracy up to 0.4 .
5
With precision automatic calibration function
which is based on the way of processing the
materials and self-adjusting process parameters,
it can match with a variety of engraving machines
and cutting machines that meet a variety of
complex embedded processes with accuracy as much
as possible.
6
The working Principles of Channel Letter Bending
Machine - Bending ways are controlled by motor
and nearly no noise, Notching way is also
controlled by motor and nearly no noise,
similarly Feeding way is also controlled by motor
and nearly no noise and finally Control system
works with LCD screen and no need to contact PC.
7
Material Feeding Systems are working with Stable
Tray which can hold nearly 200KG weight of
materials, Efficient Material Feeding Plate which
are available with 4 pieces of wheels that make
the feeding quickly and Material Feeding Entrance
which will knock and fix the material. Also they
adjust the height of the materials and avoid
material move and waste.
8
Stainless Steel Feeding Entrance is hard to wear
and it can make sure its accuracy during the
long time usage. Control and Notching System
works with Advance Notching System which notches
the material first, adopt and observes the window
and convenient to observe the process of notching
to stop quickly if anything is wrong.
9
Air Cylinders mostly use air pressure to bend and
feed the material which makes bending and feeding
accurate that can clamp material very tight and
keep notching well. Notching Motor has no voice
and it is very quick. Control Switches are big
and conspicuous to operate easily. USB interfaces
support U-disk to insert images and the user can
transfer the images into the machine easily.
10
Software Bending Parameter Storage
functionalities are the machine already stores
the bending parameters of different materials
just by choosing the material name and thickness
and the machine can execute the bending progress
automatically. Save human cost and time. Window
Covers are stable to hold up the window of
Notching during the working of machine.
11
To Order Find Out More Information On Channel
Letter Bending Machine Please Come And Visit Us
Today Onwards..!
