SDNA - Rhino Labs

1
RHINO LABS SDNAs Www.RhinoLabsInc.Com
2
What is SDNA?
SDNA or Software Defined Network Appliances means
Computer Networking that allows Network
Administrators to maintain network services
through abstraction of lower level functionality.
It performs multiple applications at one time.
3
High Performance Networking Appliance
SDNA-7890

• Rhino Labs new SDNA (software defined network
  appliances) family of products is a enterprise
  grade appliance and can perform multiple
  applications at one time in low power and low
  cost.
• All Rhino products are best in class and made
  through Cavium OCTEON III processors.
• RHM (Rhino Health Monitoring) provides appliance
  a continuous monitoring to CPU cores, board
  peripherals, voltage and temperature checkpoints.
• Key Benefits
• RHM Tool
• Low Cost
• Cavium OCTEON III 7890 Processor
• Made in The U.S.A
• Small Form Factor
• Integrated Wireless Option.

4
Enterprise - Grade Networking Appliance
SDNA-7360

• The SDNA-7360 appliance is ideal for high
  performance enterprise grade product providing
  all-inclusive networking, security and storage
  based solutions.
• Typical application including next generation
  firewall, intrusion prevention, gateway antivirus
  (AV) and anti-spam, VPN tunneling, content
  filtering, load balancing, data leak prevention,
  smart Wi-Fi access point, and remote network
  visibility and management.
• Features
• Processor - Cavium OCTEON III 73600, quad cores
  _at_2.5GH
• Memory - 32GB DDR3
• Storage - On board 4GB eMMC/SATA via M.2/USD slot
• Interfaces - 4x10GE or 8x1GE or
  4x10G4x1GE,including management - 1GE, one
  RS232 via RJ45, UDB 3.0
• Expansion - Dual mPCIe supporting 801.11ac/n and
  LTE PCIex4

5
Enterprise Grade Networking Appliance SDNA Shasta

• Rhinos Shasta is a ground breaking network
  appliance. The Shasta appliance runs OpenWRT OS
  and combines small size, high performance and
  feature scalability.
• Rhino Shasta have quad core Cavium OCTEON III
  71xx processors, providing unparalleled
  performance in the low power and low price
  categories.
• Features
• Processor - Cavium OCTEON III 7130 4 Cores
  _at_1.6GHz
• Memory - 4GB DDR3
• Storage - Onboard 4GB eMMC
• M.2 Storage module
  (128-1TB) 2.5 SATA SSD HD
  uSD Slot
• Form Factor - 3.8W x 5.5D x 1.75H (inches)
• Software - U-Boot from Rhino Labs Comes
  pre-loaded with Linux SDK or OpenWRT

6
Enterprise-grade Visibility Network
Appliance Visibility Appliance 6335 Quad 1GE

• Rhino Labs Network Visibility Appliance allows
  users to easily deploy an intelligent tap system
  at low cost. The appliance incorporates a network
  processor sub system and a DPLL unit.
• The appliance is capable of sending test traffic
  via test ports and intercepting the traffic on
  predetermined time intervals. The appliance runs
  Linux SDK and OpenWRT.
• Features
• 6 cores of MIPS64_at_1.3GHz
• Dual banks of onboard 4/8/16 GB DDR3 with ECC
  memory
• Mechanical Size 4.2x7.2
• Supports Cisco type terminal port
• Software - Rhino U-boot Linux SDK
• Supports PPS input and output, locked to GPS or
  PTP is provided.

7
Rhino Labs Inc.
Www.rhinolabsinc.com
3240 Scott BlvdSanta Clara, CA 95054 U.S.A
guy_at_rhinolabsinc.com
8
Thank You
