Primary current injection test system

1
Primary Current Injector
http//www.amperis.com/en/products/relay-testing/a
pci600/
2
About us
Amperis sells latest generation instrumentation
for testing, transformation diagnosis,
thermographic inspection and electrical
distribution. Our job is to understand your goals
and locate the electrical / electronic equipment
that best suits your needs, whether or not
included in our catalog. For this, we are at the
forefront of Electrical Technology and we are in
constant contact with leading manufacturers at
international trade shows. Amperis is a trade
mark registered in the whole European Union,
Amperis Products SL has the exclusive right to
use,
3
Amperis products can already be founded in 46
countries (look here at the list of countries).
As a commitment to the environment Amperis
company is registered as a producer of electronic
equipment to the Ministry of Industry (with
number REI-RAEE 5168), also has hired a
foundation for recycling equipment just once
life, see certificate here. And ISO-90012008
4
Primary Current Injection Source APCI-600
The APCI-600 is a programmable AC high-current
source designed specifically for
utility-substation applications. This device is
well suited for primary injection testing of
protective relays. This versatile device can also
be used for testing thermal, magnetic, and
solid-state motor-protection relays and
molded-case circuit-breakers, as well as any
application that requires a high-current source.
5
Built-in Timer The APCI-600s built-in timer can
test the time delay characteristics of protection
relays and molded-case circuit-breakers. Once the
test is initiated, the current source and the
timer are automatically turned on at the next
zero crossing point of the AC. The timer stops
when the APCI-600 input detects a change in the
dry contact or voltage input, or detects the
removal of the test current. The test results are
then displayed in milli-seconds and fractions of
a cycle(s) on the units back-lit LCD screen (20
characters by 4 lines).
External Current Input The APCI-600 also has an
external-current input (0 10 A). Both the
internal current source amplitude and the
external current source measurement readings can
be viewed at the same time.
6
Test currents, ranging from 100 to 600 amperes,
can be set by using the rotary dial knob on the
control panel. The test current is then measured,
and the results are displayed on the LCD screen.
When the APCI-600 is used as a current source,
the current-on time (duration of current flow) is
displayed on the LCD screen.
7
Contact us

• Amperis Products S.L. Agricultura 34, 27003 Lugo
  Spain
• T (34) 982 20 99 20
• F (34) 982 20 99 11
• E info_at_amperis.com

http//www.amperis.com/en/products/relay-testing/a
pci600/
8
Thank You for Your Time
