Broil Tech

1
Broil Sensotek Industry

• The Broil Group of Companies provide Turbine Flow
  Meter Fuel Flow Sensor Temperature Sensor
  Pressure Transmitter. BROIL Group is the
  'ISO-9001' AND 'CE' Certified Manufacturer and
  Supplier.

2
Our Products

1. Fuel Consumption Meter
2. Water Flow Sensor Meter
3. Over Gear Positive Displacement Flow Meter
4. Helical Rotor Positive Displacement Flow Meter
5. Turbine Flow Meter
6. Ultrasonic Flow Meter
7. Electromagnetic Flow Meter
8. Vortex Flow Meter
9. Pressure Transmitter
10. Temperature Sensor

3
Fuel Consumption Meter
BROILTECH  diesel engine fuel consumption meter
is creation from two fuel flow sensor and one
fuel calculator, full product is design,
developed and tested by broiltech, and
successfully run from last three years.

• Product Applications
• Agriculture equipment
• Real Estate
• Earth Moving Equipment
• Construction Equipment
• mines and mineral Equipment
• ship and boat
• Marine industries
• INDIAN RAILWAY SLEEPER PLANT
• Transportation
• Diesel Generator
• Automobile vehicle

Range fuel consumption meter for diesel engine,
diesel generator, automobile vehicle, mobile BTS
tower, marine ship and boat, minies vehicle and
equipment
4
Water Flow Sensor Meter
Broil Sensotek Industries produced Low Cost water
flow sensor and digital water meter from food
grade plastic so its suitable for all food and
beverage application and vending machine,BROIL
developed and produced helical rotor flow sensor
specially for Liquid dispensing industries, now a
day water dispensing industries use plastic
turbine flow sensor its k factor change with flow
rate so for solution we developer helical rotor
plastic flow sensor with same pulse k factor for
full range also provide very good accuracy and
repeatability in full range of measurement, BT
PHTFS meter and sensor start from minimum 4
litter/hour to 15000 litter/hour, with different
model and line size
5
Oval Gear Positive Flow Meter
Broiltech brand oval gear positive displacement
flow sensor is high accurate flow sensor for
measuring flow rate and cumulative total of fuel,
diesel, petrol, oil, kerosene and any high
viscous liquid, Broiltech oval gear flow sensor
is CE certified, and 40 export ratio, Oval gear
flow sensor distribute in four type as per its
flow rate and line size, micro fuel flow sensor
3 model cover flow range 0.2 litter to 150
litter/hour and line size cover 3mm , 4mm and 6
mm, mini fuel flow sensor 2 model cover flow
range 20 litter to 1200 litter/hour and line
size 8mm and 12 mm midi fuel flow sensor 3
model cover flow range 150 litter to 10,000
litter/hour and line size 20mm , 25mm and 40 mm
maxi fuel flow sensor 4 model cover flow range
600 litter to 1,50,000 litter/hour and line size
50mm , 80mm, 100 mm and 150 mm
6
Helical Rotor Positive Displacement Flow meter
Broil Sensotek industries indigenous producer and
developer of turbine flow sensor and turbine flow
meter, Broiltech developed two type of turbine
rotor for suite different industrial
application 1) Helical rotor turbine flow
sensor, Helical Rotor turbine flow meters are
positive displacement meters with a very
favorable pressure drop behavior therefore
perfectly suited for the flow measurement of very
high viscosity fluids
7
Turbine Flow Meter
Broil sensotek industries developed and design
conventional turbine flow sensor for low viscous
liquid and gas application, turbine flow sensor
model no defined in two category1) heavy duty
turbine flow sensor and meter its a fully
Stainless steel meter with carbide bearing and
available from 4 mm to 400 mm line size,  2)
economical turbine flow sensor and meter
economical turbine flow sensor available with
plastic/ aluminium rotor and body material
aluminium /stainless steel, its available from 4
mm to 50 mm line size
8
UltraSonic Flow Meter
Broil senostek industries has Exclusive
collaborate with Germany Russia producer for
sales and service Electromagnetic flow
meter, leading GERMAN/RUSSIAN company for
Electromagnetic flow meter /Ultrasonic flow meter
/ Vortex flow meter with OIML, MID, 2014/32/EC,
EX , AND IP 65 APPROVAL, Also production licencee
for produce flow meter for nuclear power
9
Electromagnetic Flow Meter
Broil senostek industries has Exclusive
collaborate with Germany Russia producer for
sales and service Electromagnetic flow
meter, leading GERMAN/RUSSIAN company for
Electromagnetic flow meter /Ultrasonic flow meter
/ Vortex flow meter with OIML, MID, 2014/32/EC,
EX , AND IP 65 APPROVAL, Also production licencee
for produce flow meter for nuclear power plant
10
Vortex Flow Meter
Broil senostek industries has Exclusive
collaborate with Germany Russia producer for
sales and service Electromagnetic flow
meter, leading GERMAN/RUSSIAN company for
Electromagnetic flow meter /Ultrasonic flow meter
/ Vortex flow meter with OIML, MID, 2014/32/EC,
EX , AND IP 65 APPROVAL, Also production licencee
for produce flow meter for nuclear power plant
11
