Title: Jinpat Through Hole Slip Ring LPT Series


1
JINPAT Electronics Co.,Ltd
Professional Slip Ring Manufacturer
JINPAT
www.slipring.cn
2
Through bore Slip Rings
  • Circuits 1300
  • Current Rating 2A400A per circuit
  • Through bore diameter up to 500mm
  • Compatible with data bus protocols
  • Durability and Reliability
  • Low noise


3
Through bore Slip Rings
Option Inner diameter, outer diameter, length
Working speed Number of circuits Current and
voltage Wire length and connected terminal
Housing color Protection grade Can transmit
signal and power solely or together
Military equipment Medical treatment
equipment Wind power generator equipment Producing
and controlling equipment Exhibit Display
machinery Robotics, radar antenna Magnetic
driver, turn table type sensor Engineering
machine,test instrument, packing machine, and so
on
Application

4
Products Range

5
Typical Applications
Cable Reel
Security Industry
Automotive Industry
Packing Machine
BB8 Robot
Total Station
Semi-conductor Machine
Medical equipment
Lift Machine

6
Customized Slip Rings
Please provide detailed specifications of the
slip ring , we could design a special solution
for you .

7
Certification
  • We are concerned about
    environmental protection and committed to
    producing eco-friendly products of high quality.
    Besides the international certificates of
    ISO9001/UKAS and CE, we have acquired the RoHs
    to which all our raw material is compliant .
    Recently , with our constant effort , we have
    passed the evaluation of GJB standard (the
    military products standard) by the authority .
    JINPAT has been awarded the honor of high-tech
    enterprise in Shenzhen City.


8
JINPAT Outline

9
Quality Target Policy
Your satisfaction is our ultimate pursuit!
Quality target ?Customer
satisfaction98 ? Customer complaint 3
Quality policy ? Customer satisfaction ?
Employee participation ? Practical and
innovative ? Pursue perfection

10
THANK YOU
