Fire Rated Hurricane (FR)
http//www.profirewa.com.au/
2
For over 25 years, the Hurricane range vertical
vane natural ventilation technology has been
built to endure the tough climatic conditions and
operating environments. Edmonds ventilation
products are designed, engineered and
manufactured at its ISO9001 accredited facility
in Seven Hills, Australia. Hurricane was the
first industrial ventilator to incorporate
vertical vane design which tests at University of
Technology Sydney have shown to be have an
improved co-efficient of discharge (Cd) compared
to similar sized traditional spherical
vents. ? Hurricane range of Special Variations
ventilators such as fire rated (FR) ventilator
provides continuous ventilation and smoke release
capability in the event of a fire. It has been
tested by CSIRO and meets the fire resistant test
to AS 1668.1-1998. The use of ventilation and air
conditioning in buildings, Part 1 Fire and smoke
control in multi-compartment buildings Section
4.8. Smoke-Spill fan. The operation of FR also
does not interfere with Early Suppression Fast
Response sprinkler systems.
3
Features and Benefits 1- Advantages versus
traditional pneumatically released ventilators
include both constant ventilation and smoke
release capacity, which will be boosted by the
buoyancy effect of rising hot air 2- Does not
interfere with Early Suppression Fast Response
sprinkler systems 3- Responsive reaction to smoke
emission 4- Meets the fire resistant test to AS
1668.1-1998. The use of ventilation and air
conditioning in buildings, Part 1 Fire and smoke
control in multi-compartment buildings Section
4.8. Smoke-Spill fan 5- Unique, in-house
Australian designed glass reinforced
polyphenylene sulphide use in critical components
to provide resistance to chemical and thermal
attacks 6- Specially designed and machined shaft
to cater for metal expansion due to heat 7-
Uniquely formulated bearing grease, to Edmonds
specification, for potential high-heat
application 8- Improved co-efficient of discharge
(Cd) compared to similar sized traditional
spherical vents 9- Lightweight design entails
crane-life might not be necessary thus reducing
overall installation cost 10- Variable pitch
throat design can adapt to most roof angles 11-
Higher flow coefficients than comparable sized
traditional spherical vents 12- Design and tested
to Australian Standards AS4740 13- Available in
900mm throat sizes only 14- Mill finish or power
coated option to match most Colorbond colours
4
Colour Selections 1- Available in mill (uncoated
aluminium) and 28 colours ? Specification
Hurricane FR Roof mounted ventilators shall be
Hurricane Fire Rated 900mm (model FR 900)
vertical vanes ventilators and shall be
manufactured from non-combustible material. The
ventilators shall be tested by the CSIRO to meet
AS1668.1-1998 Section 4.8 and shall have the
ability to operate for 120 minutes at 200C and
30 minutes at 300C or longer. The ventilator
tops shall be mill finished or powder coated with
Colorbond or as specified by the customer at
time of confirmation. ? The ventilator shall be
weather-tight under proper installation and
normal operating conditions, and capable of
withstanding a wind speed of 205.2km/hr as tested
by CSIRO. The ventilator shall be manufactured by
CSR Edmonds of New South Wales (1800 332 332)
including applicable bases, dampers, fixings,
trims, straps, flashings and other specified
fittings manufactured by CSR Edmonds as
specified herein, or equivalent.
5
15 year mechanical performance warranty on
turbine/ 2 years for Accessories, until product
is subjected to fire conditions. Please refer to
warranty document for full details.
