ATS Evo is a torque controlled expansion anchor which is used for high shear loading applications. It is also called with different names like heavy duty shear anchor, heavy duty safety anchor. ATS Evo comes in 3 different versions.. 1) Hex Head Version. 2) Flanged nut (threaded stud) version. 3) Countersunk Version. ATS Evo has 5 different components which are listed below. 1) STUD - Threaded Rod with 8.8 grade which is capable of handling high shear and tensile loads. 2) Shell - This acts as a outer cover to the stud protecting it from direct shear loadings. 3) Nylon Bush - Plastic bush which prevents the rotation of the sleeve in the bottom portion while application of the torque. 4) Sleeve - Three piece segment which expands uniformly creating both keying and friction principles in holding the anchor firmly in the concrete. 5) Cone - Cone provides uniform expansion of the sleeve while application of torque. – PowerPoint PPT presentation
Number of Views:4
Title: ATS-evo
1
http//www.rippleindia.in Ripple Construction
Products Pvt Ltd 22 September 2014 1
2
INDEX
- Mechanical Anchors
- Heavy Duty Metal Anchoring System
- Medium Heavy Duty Metal Anchoring System
- Medium Duty Metal Anchoring System
http//www.rippleindia.in
3
INDEX
- Heavy Duty Metal Anchoring System
- ATS Evo
- FM 753 Crack 3. FM 753
http//www.rippleindia.in
4
ATS Evo
HEAVY DUTY SAFETY BOLT
ETA 10/0423 op.1
http//www.rippleindia.in
5
ATS Evo
HEAVY DUTY SAFETY BOLT
ETA 10/0423 op.1 OPTION 1 Maximum safety with
greater loading capacity.
SAFE INSTALLATION Optimal expansion guaranteed by
the coupling of the cone and body
UNIFORM EXPANSION Single piece with three
expanding segments
ANTI-ROTATION The special bush shape prevents
rotation
http//www.rippleindia.in
6
ATS Evo
HEAVY DUTY SAFETY BOLT
CERTIFIED CE option 1
ETA 10/0423 op.1
- VERSIONS
- Hexagonal head
- threaded bar and hex nut
- Countersunk head.
- 8.8 GRADE BOLTS AND STUDS
- THICK STEEL SHEAR SLEEVE
- ANTI-ROTATION NYLON BUSH
- HEAT TREATED EXPANSION CONE.
Highly suitable for safety critical applications
involving high tensile and shear loads with a
high degree of safety.
concrete solid stone
http//www.rippleindia.in
7
ATS Evo
HEAVY DUTY SAFETY BOLT
ETA 10/0423 op.1
ATS Evo
Bolt Version
http//www.rippleindia.in
8
ATS Evo
HEAVY DUTY SAFETY BOLT
ETA 10/0423 op.1
ATS Evo
Stud Version
http//www.rippleindia.in
9
ATS Evo
HEAVY DUTY SAFETY BOLT
ATS Evo
Counter sunk Version
ETA 10/0423 op.1
http//www.rippleindia.in
10
ATS Evo
HEAVY DUTY SAFETY BOLT
ETA 10/0423 op.1
http//www.rippleindia.in
10
11
http//www.rippleindia.in
11
