Our Nation PrideINDIAN Airports/HeliportGreen
Airport/Heliport SAB Uden SAB Juden
Presentation on Best Practice for Electrical
Equipment Installation and Safety of
Product(Earthing Protection)
2
Importance of Public Time Money
3
Smart Airport Handle Smooth with Safety
4
We Indian Smart Indian know Value for Time and
Money
5
Fly safe Land Safe
6
My Gudget My Confidence My Safety
7
Safety for all Buildings
Smart Airport Buildings is not enough we
require Protection from
Fire and apply Safety

8
(No Transcript)
9
(No Transcript)
10
External/Internal Surge Source
11
An Arcing Fault is the flow of current through
the air between phase conductors or phase
conductors and neutral or ground. Concentrated
radiant energy is released at the point of arcing
an a small amount of time resulting in Extremely
High Temperature.
12
(No Transcript)
13
Fire Accident Reason Lose Contact Earthing
Disorder and Lightning
14
Sikhana to Padega Hi Follow NBC2016
15
Surge in Systems and Result
16
Surge in DC Application
17
(No Transcript)
18
JMV LPS Products
19
Copper Cladded Conductor For Electrical
Installation
The Copper Clad Steel Grounding Conductor is made
up of steel with the coating of 99.99 pure
copper. These conductors/ wires or strands are
equipped with the strength of steel with the
conductivity and copper with the better corrosion
resistance property. The concentric copper
cladding is metallurgic ally bonded to a steel
core through a continuous, solid cladding
process using pressure rolling for primary
bonding. The copper cladding thickness remains
constant surrounding steel. We use different
steel grades for the steel core result in Dead
Soft Annealed, High strength and Extra High
Strength Characteristics.  The Copper Clad Steel
Wire yields a composite conductivity of 21, 30
and 40 IACS, and available in Annealed and Hard
drawn. We are delivering products with varied
conductivity and tensile strength as per the
customer need. Further, the wire can be processed
to be silver plated or tinned copper clad steel
wire.
20
Most Efficient Joint Process/Fail Proof
It is efficient and superior to all existing
surface to-surface mechanical retention
connectors.
21
What is Exothermic Welding System Copper to
Bi-Metal and Alumenium
  • Types of Exothermic Joints
  • Possible to join any bi metal except aluminum
  • Exothermic welding is a process of making
    maintain free highly molecular bonding process is
    superior in performance connection to any known
    mechanical or compression-type surface-to-surface
    contact connector. Exothermic weld connections
    provide current carrying (fusing) capacity equal
    to that of the conductor and will not deteriorate
    with age.
  • It offers Electrical connections between two or
    more copper to copper and copper to steel
    conductors.
  • Highly portable method as it does not require
    any external power source or heat source, so it
    can be done almost anywhere.
  • It provides strong permanent molecular bond
    among metallic conductors that cannot loosen and
    further will not deteriorate with age.
  • Connection does not corrode with time and it
    offers permanent conductivity.

22
Copper Clad Steel Solid ROD and Conductor
23
(No Transcript)
24
LIGHTNING FORMATION
25
  • Facts about Lightning
  • A strike can average 100 million volts of
    electricity
  • Current of up to 200,000 amperes
  • Can generate 54,000 oF
  • 10/350MicroSec/50KA Fault Current/Discharge in
    Nano Sec
  • Protection
  • Earthing Design100KA Fault Current/Joints
    Exothermic /Flexible Down Conductor with
    Shortest Route Less Corner

26
  • Lightning Protection Standard use in India
  • (IS2309 Now IEC 62305-5)NBC2016
  • Working Principle Angullar No Compromise with
    Design Max Protection 30Mtrs from One
  • No Product warrenty from Manufacturer
  • High Maintenance Require
  • Earthing below 10.00 Ohm

27
Lightning Risk assessment Study is actually the
measure of risk of a lightning strike and
probability of damages. As Per IEC62305-2.
  • All these calculations are based on
  • Lightning strike density inthat particular
    area(provided byOMV i.e.Ng 8),
  • Danger for people,
  • Occupation coefficient of structure,
  • Relative location of site,
  • Fire Risk,
  • Associated services,
  • Electrical Lines,
  • Lightning Protection Level,
  • Surge Arrestor and
  • Dimensions of installation.

28
Lightning Safety Calculation
29
Lightning Risk Calcuator as per IEC6305
30
PASSIVE PROTECTION SYSTEM
31
The Simple Rod air terminal is composed
from a metallic rod with 2 to 8 m height
dominating the structure to protect, and linked
to 2 down conductors minimum, and 2 earthing
systems. The protection radius ensured by this
air terminal which is limited to 30 m more or
less (Protection level IV, height 60 m),
especially dedicated to the protection of small
structures or areas like towers, chimneys, tanks,
water tower, antenna masts The EN 62305-3
standard describes the installation procedure for
these air terminals. 13 Simple Rods, 13 down
conductors, and 13 earthing systems are necessary
to ensure the protection below
32
The meshed cage protection is
composed from a meshing in roof surface and in
the front face around the building. Surrounding
the roof surface, and on high points, capture
points are positioned. A conductors network is
placed at the outer perimeter of the roof. This
network is completed by transverse conductors.
The size of the meshing is 5 to meters, and
depends on the efficiency needed for the
protection. On the front face of the building,
the down conductors are linked at the top to the
meshing of the roof. And, down, to specific
earthing systems. The distance between two
conductors is 10 to 25 meters, and depend on the
efficiency needed for the protection. The EN
62305-3 describes the installation procedure for
this method. Generally, this method is heavy and
expensive, due to the complexity of the
structures to protect. 26 capture points, 26 down
conductors and a grounded loop earthing system
are necessaries to ensure the protection of the
structure here below
33
The catenary wires protection is a
method closed to the meshed cage principle,
because it is constituted with meshing of the
conductors far from the structure to protect, to
avoid any contact with lightning
current. Catenary wires are located over the
structure to protect, connected to down
conductors and specific earthing systems. The
width of the meshing and distance between the
down conductors must respect the same rules as
for the meshed cage. The EN 62305-3 describes the
installation procedure for this
method. Generally, this method is heavy and
expensive, due to the complexity of the
structures to protect.
34
The ESE air terminal is a
terminal which enables to generate artificially
an upward leader earlier than a simple rod, with
an ionization system, in order to establish a
special impact on its point. The capture of the
lightning strike being faster than a simple rod,
this technology enables to benefit from larger
protection areas, ensuring protection for large
dimensions structures. The generated protection
radius depends on the early streamer emission
value of the air terminal (?t in µs), its height,
and the efficiency of the protection. The
protection radius ensured by this type of air
terminal is 120 m (Protection level IV, height
60 m , early streamer emission time 60µs) The NFC
17-102 standard describes the installation
procedure for this type of air terminal. The
installation of this type of air terminal is easy
and cheaper than other technologies. It can
protect whole buildings with one E.S.E. air
terminal. It enables the protection of a
structure and its environment, the protection of
opened areas and well integrate in the
architecture of a structure without aesthetic
alteration. 1 ESE, 2 down conductors and 2
earthing systems are necessary to ensure the
protection below
35
ESE Installation Guidence
ESE AT with radius protection form 32 mtr to 107
mtr.
DMC Insulator .
GI/FRP Mast .
Down Conductor Copper / Copper Cadmium Cable 70
sq. mm
Copper Bonded Ground Earthing
36
Thimble
Joint all phase wire/ cable with the help of
crimping tools and lugs
Step 1
Separation Sheet
Fixed the separation sheet between all wires/
cables
Gel / Silicon
Step 2
Close the filled Silicon enclosure from top and
bottom , complete installation is done.
Step 3
37
(No Transcript)
38
(No Transcript)
39
(No Transcript)
40
(No Transcript)
41
JMVs Clients
42
Contact Professionals for Advise
43
We Protect You Use Electrical SafetyEarthing
Protection
44
