Safe Practice in Earthing and Protection
20
Sikhana to Padega Hi Follow NBC2016
21
Follow Safety in Electrical Instalation Shocks
22
Earthing Design and Require Result

• Large Power Plant below 1.00Ohm
• Small Power Plant below 2.00Ohm
• SCADA/TELECOM and Automation For Ship Power and
  Controls below 0.50Ohm
• Sea Ports and Infrastructures
• Tower and Other Structure between 8-15Ohm
• Lightning Surge Protection 50KA below 5Ohm or
  100KA between 8-15Ohm
• Follow Standard IEC /IEEE
• Surge Protection For Power and Communcation Port
• Exothermeic weld IEEE 837

23
(No Transcript)
24
Surge in Systems and Result
25
Surge in DC Application
26
Surge Protection use Recommendation
27
v
28
External/Internal Surge Source
29
(No Transcript)
30
Safety Main It Should be Remain (Protect your
Equipment for Internal External Surges)

• The 100 of lightning energy breaks down as
  follows
• a) 50 of the lightning current will flow
  through the ground
• b) 50 of the lightning current will flow over
  the connected metal parts out of the
  building
• about 10 to the water pipe (metal)
• about 10 to the gas pipe (metal)
• about 10 to the oil pipe (metal tank)
• about 10 to the sewage pipe
• about 10 to the power suppliers incoming feed
• max. 5 or 5 kA shared across all data lines

31
(No Transcript)
32
Fire Accident Reason Lose Contact Earthing
Disorder and Lightning
33
An Arcing Fault is the flow of current through
the air between phase conductors or phase
conductors and neutral or ground. Concentrated
radiant energy is released at the point of arcing
an a small amount of time resulting in Extremely
High Temperature.
34
(No Transcript)
35
JMV LPS Products
36
Copper Cladded Conductor For Electrical
Installation
The Copper Clad Steel Grounding Conductor is made
up of steel with the coating of 99.99 pure
copper. These conductors/ wires or strands are
equipped with the strength of steel with the
conductivity and copper with the better corrosion
resistance property. The concentric copper
cladding is metallurgic ally bonded to a steel
core through a continuous, solid cladding
process using pressure rolling for primary
bonding. The copper cladding thickness remains
constant surrounding steel. We use different
steel grades for the steel core result in Dead
Soft Annealed, High strength and Extra High
Strength Characteristics.  The Copper Clad Steel
Wire yields a composite conductivity of 21, 30
and 40 IACS, and available in Annealed and Hard
drawn. We are delivering products with varied
conductivity and tensile strength as per the
customer need. Further, the wire can be processed
to be silver plated or tinned copper clad steel
wire.
37
Most Efficient Joint Process/Fail Proof
It is efficient and superior to all existing
surface to-surface mechanical retention
connectors.
38
What is Exothermic Welding System Copper to
Bi-Metal and Alumenium

• Types of Exothermic Joints
• Possible to join any bi metal except aluminum
• Exothermic welding is a process of making
  maintain free highly molecular bonding process is
  superior in performance connection to any known
  mechanical or compression-type surface-to-surface
  contact connector. Exothermic weld connections
  provide current carrying (fusing) capacity equal
  to that of the conductor and will not deteriorate
  with age.
• It offers Electrical connections between two or
  more copper to copper and copper to steel
  conductors.
• Highly portable method as it does not require
  any external power source or heat source, so it
  can be done almost anywhere.
• It provides strong permanent molecular bond
  among metallic conductors that cannot loosen and
  further will not deteriorate with age.
• Connection does not corrode with time and it
  offers permanent conductivity.

39
Copper Clad Steel Solid ROD and Conductor
40
(No Transcript)
41
Lightning Safety of the structure / human/
equipments
42
LIGHTNING FORMATION
43
India Lost Due to Lightning
44
We all may be danger if not Protected
45
Hamen Babaji Nahi Science Chahiye
46
Horrifying Losses Due To Devil Lightning
47

• Facts about Lightning
• A strike can average 100 million volts of
  electricity
• Current of up to 200,000 amperes
• Can generate 54,000 oF
• 10/350MicroSec/50KA Fault Current/Discharge in
  Nano Sec
• Protection
• Earthing Design100KA Fault Current/Joints
  Exothermic /Flexible Down Conductor with
  Shortest Route Less Corner

48

• Lightning Protection Standard use in India
• (IS2309 Now IEC 62305-5)NBC2016
• Working Principle Angullar No Compromise with
  Design Max Protection 30Mtrs from One
• No Product warrenty from Manufacturer
• High Maintenance Require
• Earthing below 10.00 Ohm

49
Lightning Risk assessment Study is actually the
measure of risk of a lightning strike and
probability of damages. As Per IEC62305-2.

• All these calculations are based on
• Lightning strike density inthat particular
  area(provided byOMV i.e.Ng 8),
• Danger for people,
• Occupation coefficient of structure,
• Relative location of site,
• Fire Risk,
• Associated services,
• Electrical Lines,
• Lightning Protection Level,
• Surge Arrestor and
• Dimensions of installation.

50
Lightning Safety Calculation
51
Lightning Risk Calcuator as per IEC6305
52
PASSIVE PROTECTION SYSTEM
53
The Simple Rod air terminal is composed
from a metallic rod with 2 to 8 m height
dominating the structure to protect, and linked
to 2 down conductors minimum, and 2 earthing
systems. The protection radius ensured by this
air terminal which is limited to 30 m more or
less (Protection level IV, height 60 m),
especially dedicated to the protection of small
structures or areas like towers, chimneys, tanks,
water tower, antenna masts The EN 62305-3
standard describes the installation procedure for
these air terminals. 13 Simple Rods, 13 down
conductors, and 13 earthing systems are necessary
to ensure the protection below
54
The meshed cage protection is
composed from a meshing in roof surface and in
the front face around the building. Surrounding
the roof surface, and on high points, capture
points are positioned. A conductors network is
placed at the outer perimeter of the roof. This
network is completed by transverse conductors.
The size of the meshing is 5 to meters, and
depends on the efficiency needed for the
protection. On the front face of the building,
the down conductors are linked at the top to the
meshing of the roof. And, down, to specific
earthing systems. The distance between two
conductors is 10 to 25 meters, and depend on the
efficiency needed for the protection. The EN
62305-3 describes the installation procedure for
this method. Generally, this method is heavy and
expensive, due to the complexity of the
structures to protect. 26 capture points, 26 down
conductors and a grounded loop earthing system
are necessaries to ensure the protection of the
structure here below
55
The catenary wires protection is a
method closed to the meshed cage principle,
because it is constituted with meshing of the
conductors far from the structure to protect, to
avoid any contact with lightning
current. Catenary wires are located over the
structure to protect, connected to down
conductors and specific earthing systems. The
width of the meshing and distance between the
down conductors must respect the same rules as
for the meshed cage. The EN 62305-3 describes the
installation procedure for this
method. Generally, this method is heavy and
expensive, due to the complexity of the
structures to protect.
56
The ESE air terminal is a
terminal which enables to generate artificially
an upward leader earlier than a simple rod, with
an ionization system, in order to establish a
special impact on its point. The capture of the
lightning strike being faster than a simple rod,
this technology enables to benefit from larger
protection areas, ensuring protection for large
dimensions structures. The generated protection
radius depends on the early streamer emission
value of the air terminal (?t in µs), its height,
and the efficiency of the protection. The
protection radius ensured by this type of air
terminal is 120 m (Protection level IV, height
60 m , early streamer emission time 60µs) The NFC
17-102 standard describes the installation
procedure for this type of air terminal. The
installation of this type of air terminal is easy
and cheaper than other technologies. It can
protect whole buildings with one E.S.E. air
terminal. It enables the protection of a
structure and its environment, the protection of
opened areas and well integrate in the
architecture of a structure without aesthetic
alteration. 1 ESE, 2 down conductors and 2
earthing systems are necessary to ensure the
protection below
57
IEC Declaration by CENELEC for NFC17-102
58
BT has confirmed that ESE National Standards
would remain valid and thus BT recognizedthere
would be no evidence of conflict between NF C
17-102 and IEC EN 62-305 standards and
consequently there is no reason, technical or
otherwise, for the withdrawal of the respective
national standard.BT has requested that this
standard be modified in order to cancel all
reference to the IEC EN 62-305 series, allowing
the NF C 17-102 standard to exist, with the
proposal of possible future migration to
international level (lEC). Accordingly, it was
establishedthat European ESE standards (France,
Spain, Portugal, Slovaquia, etc.) will
notconflict with other European standards and
will remain valid.

• GIMELEC would draw your attention to the fact
  that the terms of reference of NF C 17-102 and
• other standards, addressing alternative terminals
  (NF C 17-100, PR EN 61-024-1) were from the
• outset, very different. It is a fact that NF C
  17-102, whilst referring to ESE Technology also
• comments on other standards for lightning
  protection systems, particularly incorporating
• faraday cage, franklin rod and catenary wire
  systems. the 'camouflaging' of NF C 17-102 by IEC
  EN
• 62-305 and its proponents, that FRENCH STANDARD
  NF C 17-102 is still in full force.

59
ESE Installation Guidence
ESE AT with radius protection form 32 mtr to 107
mtr.
DMC Insulator .
GI/FRP Mast .
Down Conductor Copper / Copper Cadmium Cable 70
sq. mm
Copper Bonded Ground Earthing
60
Thimble
Joint all phase wire/ cable with the help of
crimping tools and lugs
Step 1
Separation Sheet
Fixed the separation sheet between all wires/
cables
Gel / Silicon
Step 2
Close the filled Silicon enclosure from top and
bottom , complete installation is done.
Step 3
61
(No Transcript)
62
(No Transcript)
63
We are offering Surge Protection Devices as
IS/IEC 62305-4
64
(No Transcript)
65
(No Transcript)
66
Contact Professionals for Advise
67
We Protect You Use Electrical SafetyEarthing
Protection
68
Contact Our Team JMV INDIALeader and
Inspiration behind Mr. Neeraj Saini
neeraj_at_jmv.co.inMr. Mahesh Chandra Manav Brand
JMV HOD manav_at_jmv.co.inwww.jmv.co.inMobile
-919910398999 Landline -01204590000
69
JMVs Clients
