India First Bullet Train

1
India First High speed train

• JMV LPS LTD Earthing and ProtectionYear 2017

2
India BULLET TRAIN
3
The magnetized coil running along the track

• The magnetized coil running along the track,
  called a guide way, allowing the train to,
  allowing the train to levitate levitate between
  0.39between 0.39and 3.93 inches above the guide
  way. Once the train is and 3.93 inches above the
  guide way

4
Japan India JV for Bullet Train
5
India Japan Finance Aggrement for First India
Bullet Train
6
PROPOSED ROUTE FOR BULLET TRAIN
7
India DreaM Plan Bullet Train
8
DIAMOND QUADRILATERAL

• Project of the Indian railways to
  establish high speed rail network in India.
• Connect the four metro cities
  Delhi, Mumbai, Chennai and Kolkata.
•
• Track Gauge 1676 mm
• Speed 250-350 km/hr
• Length 6500-7000 km

9
First Bullet Train Project

• According  to Forbes India, the costs for
  constructing such rail lines in India  are
  estimated to be Rs 70-100 crores perk.
• Therefore the  Mumbai-Ahmedabad route of 500km,
  will cost Rs 37,000 crores to build.
•
• With the cost of land acquisition etc, the price
  will go up to about Rs 60,000 crores.

10
COACH VIEW Bullet Train Rolling Stock
11
Train Control Systems
12
(No Transcript)
13
MALGEV VECHILE(Rolling Stock)
14
TRAIN OPERATION CONTROL
15
Technology

• MAGLAV is the principle used in working of
  modern high speed train

• MAGLAV-derived from MAGnet and LEVitation

• Magnetic levitation transport is a form of
  transportation that suspend guides and propels
  vehicles through the harnessing of
  electromagnetic force

16
The Bullet Train Track

• Type of Magnet Uses
• This train uses superconducting electric magnets
  in the vehicle to levitate and propel the train.
  These magnets are cooled by liquid helium or
  liquid nitrogen. This means that once
  electrified these magnets do not require
  additional energy.

17
Electrodynamic suspension

• In Electrodynamic suspension, both the rail and
  the train exert a magnetic field, and the train
  is levitated by the repulsive force between these
  magnetic fields
• The magnetic field in the train is produced by
  either electromagnets or by an array of permanent
  magnets.
• The repulsive force in the track is created by an
  induced magnetic field in wires or other
  conducting strips in the track.

18
Two types of bullet train Technologies

• Electromagnetic suspension (EMS)
• Electrodynamic suspension (EDS)

19

Electrodynamic suspension (EDS)
In electrodynamic suspension (EDS), both the rail
and the train exert a magnetic field
20
Electromagnetic suspension (EMS)

• In current electromagnetic suspension (EMS)
  systems, the rail is situated between the upper
  and lower edges and use electromagnets to
  levitate the train

21
Maglev technology

• There are two primary types of maglev technology
• Electromagnetic suspension (EMS)
• Electrodynamic suspension (EDS)

22
Working of maglav

• A maglev train floats about 10mm above the
  guideway on a magnetic field.
• It is propelled by the guide way itself rather
  than an onboard engine by changing magnetic
  fields
• Once the train is pulled into the next section
  the magnetism switches so that the train is
  pulled on again.
• The Electro-magnets run the length of the guide
  way.

23
MALGEV VECHILE(Rolling Stock)
24
MaGLEV Principal/TECHNOLOGY
25
MAGLEV TECHNOLOGY
26
MAGLEV TECHNOLOGY EMS
27
MAGLEV TECHNOLOGY EDL
28
MAGLEV TECHNOLOGY COMPARISON
29
MALGEV EMS EDS CoMPARISON
30
Follow Safety in Electrical Instalation
31
An Arcing Fault is the flow of current through
the air between phase conductors or phase
conductors and neutral or ground. Concentrated
radiant energy is released at the point of arcing
an a small amount of time resulting in Extremely
High Temperature.
32
Fire Accident Due to Lightning/Short CKT
We Want India Safe Practice Earthing
and Protection
33
Why Accidents happen?

• Accidents generally happen due to lack of
  maintenance, lack of Supervision, lack of
  knowledge, over confidence and negligence.
  Accidents may also happen due to one or more of
  the following reasons
• Using improper tools
• Improper/non usage of protective devices
• Lack of proper instructions and supervision
• Mental/physical condition of the employee
• Poor Judgment

34
Surge in Systems and Result
35
JMV LPS Products
36
(No Transcript)
37
Copper Cladded Conductor For Electrical
Installation
The Copper Clad Steel Grounding Conductor is made
up of steel with the coating of 99.99 pure
copper. These conductors/ wires or strands are
equipped with the strength of steel with the
conductivity and copper with the better corrosion
resistance property. The concentric copper
cladding is metallurgic ally bonded to a steel
core through a continuous, solid cladding
process using pressure rolling for primary
bonding. The copper cladding thickness remains
constant surrounding steel. We use different
steel grades for the steel core result in Dead
Soft Annealed, High strength and Extra High
Strength Characteristics.  The Copper Clad Steel
Wire yields a composite conductivity of 21, 30
and 40 IACS, and available in Annealed and Hard
drawn. We are delivering products with varied
conductivity and tensile strength as per the
customer need. Further, the wire can be processed
to be silver plated or tinned copper clad steel
wire.
38
Most Efficient JointProcess
It is efficient and superior to all existing
surface to-surface mechanical retention
connectors.
39
What is Exothermic Welding System?Copper to
Bi-Metal and Alumenium

• Types of Exothermic Joints
• Possible to join any bi metal except aluminum
• Exothermic welding is a process of making
  maintain free highly molecular bonding process is
  superior in performance connection to any known
  mechanical or compression-type surface-to-surface
  contact connector. Exothermic weld connections
  provide current carrying (fusing) capacity equal
  to that of the conductor and will not deteriorate
  with age.
• It offers Electrical connections between two or
  more copper to copper and copper to steel
  conductors.
• Highly portable method as it does not require
  any external power source or heat source, so it
  can be done almost anywhere.
• It provides strong permanent molecular bond
  among metallic conductors that cannot loosen and
  further will not deteriorate with age.
• Connection does not corrode with time and it
  offers permanent conductivity.

40
(No Transcript)
41
(No Transcript)
42
