How do dental loupes work?

• 514 white ave, Henderson,
• TN 38340
• customerservice_at_loupedirect.com
• https//www.loupedirect.com/

2

• Dental loupes are small magnification devices.
• magnified view of an object
• rely upon one major physical principle the
  refraction of light through a series of lenses.

3
How dental loupes works

• Light Refraction and the Lens
• Lens is a transparent object (typically made of
  plastic or glass)
• Materials offer similar optical qualities,
• View of an object by causing the refraction of
  light

4
How dental loupes works

• Objects seen through a lens seem much bigger than
  they actually are.

5
How dental loupes works

• Lenses in Dental Loupes

6
How dental loupes works

• The tooth is the object being viewed in this
  scenario
• Light (from the sun or room lighting) is
  reflected off the tooth's surface, allowing us to
  see it (or else it would appear black).
• The reflected light hits the lens (within the
  optics of the loupes), and causes the light to
  refract (change direction).
• The refracted light passes through the pupil of
  the eye (another lens)
• The light is focused onto the retina, allowing
  for image production by the brain. The focal
  point is therefore found on the retina.

7
How dental loupes works

• Loupes Magnification depends on Focal Length
• Range of magnifications - most start around 2.5x
  and some go up to even 6x magnification
• power of the lens equates to how magnified the
  image will be
• The shorter the focal length, the more powerful
  the lens will be, and the more magnified your
  image.

8
How dental loupes works
9
How dental loupes works
