Pick CNC Vision Measuring Machine from Sinowon

1
Welcome to Sinowon Innovation Metrology
Manufacture Limited
2
About Us
Founded in 2010, we Sinowon Innovation Metrology
Manufacture Limited devote ourselves to material
testing with quality from start to finish.
Integrated with brilliant Research Development
talents, and productive stuff, SINOWON team comes
to a formation full of ambition as well as
responsibility, committed to Sales and Marketing,
Technical Service. We think with customer as the
start point, manage corporation with motto
Satisfaction, Innovation, Norm, Obligation,
Worth, Openness, Nimble, focus on R D and
management to provide excellent quality and
service. SINOWON is specialized in Optical
Instant Video Measuring Machine, Profile
Projector, Manual / Fully-auto Video Measuring
Machine, Toolmaker Microscope, Video Measuring
Microscope, Metallurgical Microscope, Stereo
Microscope, etc as well as Digital Rockwell
Hardness Testers, Automatic Vickers Hardness
Tester, Digital  Brinell Hardness Tester,
Non-destructive Ultrasonic Hardness Tester,
Portable Universal Dynasonic Hardness Tester,
etc. All of our products get ISO9001 certified,
CE EU certification, widely used in machinery,
mold, metal, rubber, , connectors, household
appliances, printed circuit boards, medical
equipment, so on.
3
Horizontal Profile Projector

• Sinowon Innovation Metrology Manufacture Limited,
  offers high quality horizontal profile projector
  including
• Ø350mm Digital Horizontal Profile Projector
• Ø400mm Digital Horizontal Profile Projector at
  affordable price.

4
Digital Horizontal Profile Projector Features

• The lifting system adopts linear guide rail and
  precision screw drive, which makes lifting drive
  more comfortable and stable
• Coating process reflector, clearer image and
  great dustproof
• Adjustable contour and surface illumination, to
  meet with difference workpiece demand
• Imported high light and long using life LED
  illumination ,to ensure precision measurement
  demand
• High resolution optical system with clear image
  and magnification error is less than 0.08
• Powerful Bi-axial fan cooling system,highly
  increase using life
• Powerful and colorful DRO DP400,realized fast and
  accurate 2D Measurement
• Built-in Mini-printer, can print and save data
• With standard 10X objective, optional,20X 50X
  objective,rotary table, foot switch ,clamp, etc.

5
CNC Vision Measuring Machine

• Checkout wide range of CNC vision measuring
  machine including
• 2.5D Laser-Scanning Auto Vision Measuring Machine
  MVL Series
• Super Large Travel Automatic Vision Measuring
  Machine
• 3D Fully Auto Vision Measuring Machine MVH Series
• Non-contact Fully Auto Vision Measuring Machine
  AutoScan Series

6
2.5D Laser-Scanning Auto Vision Measuring Machine
MVL Series

• High precision X/Y/Z/Q-axis fully auto control,
  high position accuracy
• Precision linear guide, grinding ball screw and
  AC servo motor, ensure accuracy the stability of
  system  position 0.5um high resolution linear
  scales ensure the precision of position and
  measurement accurately
• 6.5X standard coaxial motorized detent zoom lens
  and high definition color digital camera, ensure
  sharp observation and stable measurement
  requirement
• Programmable 5-ring 8-division LED surface
  illumination, contour parallel LED illumination,
  can realize 256 grade brightness adjustment
  intelligently
• Laser scanning probe is as standard delivery
  special for the measurement of transparent glass,
  etc
• High-powerful auto measuring software iMeasuring
  4.3

7
Super Large Travel Automatic Vision Measuring
Machine

• Moving gantry structure, measurement workpiece is
  fixed
• Four-axis CNC fully auto close loop control, auto
  measurement 00 grade JINANQINGmarble base
  and pillar, stable and reliable
• Imported open type linear scale, resolution is
  0.001mm, high accuracy, great stability
• Imported P grade linear guide, precision grinding
  ball screw and AC servo motor, ensure accuracy
  stability of system  position
• Imported high definition color industry camera,
  ensure clear observation and stable measurement
  requirement
• 6.5X continue auto zoom lens, precision auto
  zoom, only need to make pixel calibration once
  time
• Programmable 5-ring 8-division LED surface
  illumination, contour parallel LED illumination,
  can realize 256 grade brightness adjustment
  intelligently
• With proprietary fully auto measuring software
  iMeasuring 4.1, powerful function, simple
  operation

8
(No Transcript)
9
Video Microscope

• Explore wide range of video microscope including
  Auto Focus Video Microscope including
• Auto Focus Video Microscope
• Coaxial Illumination Video Microscope
• 2D Monocular Video Zoom Microscope

10
Affiliate Information

• With the principle of cooperation, mutual benefit
  and win-win situation, SINOWON takes great
  sincere to welcome agents from all over the
  country. Please contact us and make further
  negotiations if you are in line with following
  conditions.
• Great faith in metrology
• Long-term cooperation desire, with the concept of
  mutual development and successful cooperation
• Good economy strength and business credit
• Premium sales channels and methods, as well as
  ability to take on marketing tasks
• Authorized by SINOWON, strictly adhere to
  relevant policies and regulations, be a sole
  agent in specified region
• Willing to actively expanding distribution
  channels, improving brand image and manage
  distribution channels No spanned sales,
  lower-price disturbing and other acts that
  violate the distribution agreements.

11
Contact Us
A1, KaiSong Park, 2 Baima Xianfeng Road, South
District, DongGuan, Guangdong, China (523080) Fax
0086-769-22854144
https//www.facebook.com/sinowonprecision/
https//twitter.com/sinowonw
https//plus.google.com/114693136882994331573
12
http//sinowon.com/
