Conceptual Information of

• sequential controller

2
About Us

• Maniks is the most reputed Indian brand with a
  history of 30 years for manufacturing reverse jet
  pulse valves used in bag-filter applications and
  the sequential timers used in conjunction with
  them. These are used in dust collector equipment
  for cement, steel and such other industries. The
  company was started by Mr. Shekhar Kulkarni, an
  IIT Mumbai alumnus, with a vision to substitute
  imported products with Indian make products. The
  primary aim was to produce reliable products with
  excellent quality and service.

3
Introduction

• What is sequential controller?
• Specifications of sequential controller
• Working principal
• Basic part of sequential controller
• Applications

4
sequential controller

• What is sequential controller?
• sequential controller is also known as
  Sequential Controller has been designed to
  operate the pilot valves used on dust collector
  Equipment. Light emitting diodes (LEDs) provide
  visual indication of which dust collector valve
  is being energized as well as "Power On"
  indication. The number of sequenced steps is
  adjustable from 2 through 10.Controls are
  provided to adjust the length of time between
  valves being de-energized (Pulse Frequency / Off
  time) and the length of time that the valve is
  energized (Pulse Duration / On time).

5
sequential controller

• Specifications of sequential controller
• Electrical Standard Voltage
• AC 50Hz .. 24/220 Volts,
• DC... 24/Volts,
• fluctuation - - 10
• 20 W DC Current
• 19 VA AC Current
• Maximum Medium Temperature 650C
• Maximum Ambient Temperature 550C

6
sequential controller

• Working principal

7
sequential controller

• Basic part of sequential controller
• Diaphragm is essential part of sequential
  controller These spares are compatible with
  valves of various makes like Maniks, etc. The
  diaphragms are made application-specific by
  manufacturing in various materials like special
  Imported polyester, neoprene and viton( for high
  temperature)

8
sequential controller

• Applications
• sequential controller is used in different field
  such as
• Carbon Black Industry
• Asphalt Plants
• Chemical Plants
• Cement And Rock Industry
• Food Industry
• Foundries
• Iron Steel Industry
• Tobacco Industry
• Click Here to Get more Information

9
sequential controller

• Maniks Top Satisfied Client List
