Solidworks Classes in Pune

1
Journey Through SolidWork

• Brought To You By Classboat.com

2
Agenda

• Why What value do these features add to product
  design?
• Advance capabilities - Introduction to SolidWorks
  Advanced modeling types
• How - Determining use of Loft, Boundary, Fill,
  Freeform
• Focus on Three
• Boundary introduction and examples
• Fill introduction and examples
• Freeform introduction and examples

Mobile No. 91-7767904499 E-mail -
support_at_classboat.com www.classboat.com
3
Fill Feature Background

• Introduced to SolidWorks 2001 Useful for creating
  N sided patches (3 or 5 or more sides)
• Only one of its kind in the industry
• Pros
• Especially useful for Capping, complex surface
  patches and for repairing import surfaces.
• Curve Continuous (C2) matching (New for 2007)
• Fix Up Boundary does not require closed or
  contiguous boundary (new for 2007)
• Cons
• Can only use one or two Constraint curves
• In some cases needs edge matching to control
  surface

Mobile No. 91-7767904499 E-mail -
support_at_classboat.com www.classboat.com
4
Freeform Feature Background

• Introduced in SolidWorks 2007 to answer
  customers need to have push-pull ability in
  SolidWorks.
• Dynamically pull on surfaces to deform them
• Pros
• No need to predefine section or guide curves
• Unlike competition, can place control points
  anywhere on the surface or face not just an
  evenly spaced grid of points. Only one of its
  kind in the industry
• Especially useful for highly organic shapes
• Can move face boundaries and re-heal
  automatically.
• Cons
• Currently can only do four-side surfaces or faces

Mobile No. 91-7767904499 E-mail -
support_at_classboat.com www.classboat.com
5
Will be discussing Boundary, Fill Freeform
Classboat.com
Mobile No. 91-7767904499 E-mail -
support_at_classboat.com www.classboat.com
6
Freeform Introduction
Boundary Conditions
Tangent Face maintains tangency
Classboat.com
Mobile No. 91-7767904499 E-mail -
support_at_classboat.com www.classboat.com
7
For More Info. Just Check Out
www.classboat.com/tech/solidworks-classes-pune

• Mobile No. 91-7767904499 E-mail -
  support_at_classboat.com www.classboat.com
