led display board

1
(No Transcript)
2
About Us..
SAI EXPORT and IMPORT was established in 2012
with proficient generation and administration
frameworks, its head office is situated in Pune
City, Maharashtra, India. We center around the
generation, deals and administration of LED full
shading show, offering turn-key answers for
medium and top of the line Indoor and Outdoor LED
show items Professional Manufacturer After 5
years' advancement, SAI EXPORT AND IMPORT GROUP
has amassed rich experience and has the five star
creation gear, standard clean generation plant.
It has set up an orderly, proficient creation
procedure of show, which gives a successful
certification to the change of stable quality and
practical Product. Because of the propelled
fabricating process, methods, security of value,
advancement capacity of new items, the results of
SAI EXPORT AND IMPORT are exceptionally assessed
by clients at home and abroad. We look for common
development by keeping our item unrivaled in
quality and agreeable in benefit.
Our mission..
Our Roadmap begins with our central goal, which
is persevering. It announces our motivation as an
organization and fills in as the standard against
which we measure our activities and choices. To
make new age of business people To motivate
snapshots of hopefulness and satisfaction... To
make Digital and Smart India
Our Vision..
Our vision fills in as the structure for our
Roadmap and aides each part of our business by
portraying what we have to achieve keeping in
mind the end goal to keep accomplishing feasible,
quality development..
3
Types of LED Screen
OUTDOOR
INDOOR
P6
P10
P5
P8
P4
P6
P3
P5
P2.5
P4
4
Sai Export and Import is one of the main
associations offering Led outside show, Indoor
show , Rental screen . We offer these to our
client at advertise driving rates.
5
Die casting cabinets are used for rental screen.
Cabinet weighs only 9kg that helps in easy
transportation and reduces manpower.
6
Flow Work Diagram of LED Screen..
7
(No Transcript)
8
FEATURES OF P6

• Sai Led Outdoor Advertising Display, with the
  bureau size of 768mm X 768mm, With Hot pixel
  pitch of 6mm .
• This LED bureau just weighs 30kg for ms bureau
  and 8.5 kg for diecasting bureau and with
  profundity of 120mm. That brings the advantages
  for the transportation.
• The consistent plan enhances the show quality.
• Including high determination and high brilliance,
  it can keep high differentiation level even in
  solid daylight.
• The swap for modules costs few, without changing
  the first structure.
• This unit bureau offers a financially savvy show
  answer for outside utilization.
• It will work at min Brightness additionally it
  spares control.

LED Module
Cabinet
LED Cabinets Installation
9
Specifications
Led Make Cree/Nichia/Nation Star/ King Light
Pixel Pitch(mm) 6
LED Configuration SMD 3 in1 3528
Driver IC MBI5124(Gold Wire)
Module Size 192mmX192mm
Brightness 2500 cd/m2
Scan Mode 1/16
View Angle Horizontal 140 , Vertical 140
Cabinet Size 768768mm for MS (576576mm for diecasting)
Cabinet Material Iron/ Mild steel /Aluminum
Protective Grade IP34
Temperature - Operating ?20?50?
Optimal Viewing Distance 6M-60M
Input Voltage AC230V/50Hz
Power Consumption Max 600W/?,Average 360W/?
Refresh Frequency up to Š1200Hz
Operating Humidity 10-90 RH
10
Brightness Control Red ,Green and Blue 12-16 bits/each
Brightness control mode Manual/Automatic/Programmable
Defects Rate Š0.00001
MTBF gt50,000 hours
Life Span Š100,000 hours
Controlling System Synchronous/ Asynchronous
Operating System Windows XP/2007/2008 / 2010
11
Softwares for LED Screen
OFFLINE HD Player programming is utilized for
PC/Laptop association should be possible
through LAN link, Pen Drive or WiFi. Driven Art
programming is utilized for Android Mobile
telephone. association should be possible
through WiFi. ONLINE

• ?
• WEB (clouds) Any time any where data
  operating.e.g(Google Drive)

Software Features Offline Video, Photos,
single line text, 3 D, Office files, animated
text,
timing countdown, Live clock.
Online Temperature, Humidity, Weather.
12
Fabrication Structure
13
Packaging and Installation..
14
Some of Our Valuable Projects
15
(No Transcript)
16
CONTACT US..
Corporate Office 216, Tower 2,world Trade
Centre, Kharadi, pune -411014. Factory Sai
Export and Import, Koregaon Bhima, Pune-Nagar
road, pune. Sales 8042994299 Service
7888040119 E-mail sales_at_saimpexhk.com Website
www.saimpexhk.com
