Royal Mosquito Net Chennai - Brochure

1
TM
ROYAL FABRICS ISO 9001 2015 Certified Company C
O M P L E T E I N S E C T S C R E E N S O L
U T I O N
ENJOY the
FRESH AIR BREEZE
KEEP ALL the BUGS OUT!
2
ABOUT US
We are one of the top and ISO 9001-2015 certified
mosquito net service providers in chennai. We
have our Own brands ROYAL NET and we also
dealing with the top brands like Netlon, Saint
Gobain and Phifer. We offer environment -
friendly absolute safe solution for you your
family. We do insect screen nets by wholesale and
retails. We have been in this industry more than
a decade. Having a decade experience in this
field and by knowing the pulse of the clients, we
are providing our best services by highly
professionals. We apply quality check for each
and every material to satisfy the customers
requirements according to the current market
trends. We are glad to inform that we have done
so many higher projects like Resorts, Hotels,
Flats, Apartments, Orphanages, Government
hospitals, Colleges, Hostels, Restaurants,
Corporate offices, etc., OUR SERVICES OUR MISSION

• Quick response for your calls and free demo about
  our products.
• Meshes and frames at any size and variety of
  colors.
• Powder epoxy coated aluminium frames for strength
  and durability.
• Fire retardant, unobtrusive and easily removable
  for cleaning.
• Products made with an absolute accuracy and no
  on-site disruption.
• Factory trained labors for a perfect installation
  and best service.
• 3 years guarantee is our commitment, quality and
  service is our priority.
• Orders will be finished within maximum 4 working
  days.

Our aim to protect people from dangerous
diseases like H1N1, Malaria, Dengue, Fila-
riasis, yellow fever etc., We assist you in
protecting you from illness and prevents you
from mosquito bites with our efficient services.
PRODUCT FEATURES
Protection from Mosquitoes and other insects
Clear vision, Fresh air flow and circulation
Environment Friendly
Fire Retardant Fabrics
OUR PREMIUM CLIENTS
D?e??
Align C R A F T
SUMANTH B U I L D E R
BUILDER
3
VELCRO TYPE
DIY - MAGNETIC TYPE
WINDOW - OPENABLE TYPE
MAGNETIC - WINDOW OPENABLE TYPE
DOOR - OPENABLE TYPE
TWO TRACK - SLIDING SYSTEM
ROLLER - SHUTTER SYSTEM
PLEATED - SLIDING SYSTEM
4
VELCRO TYPE

• These type mosquito net is widely used as
  attachable detachable mosquito mesh, which is
  very economical, durable, rust free and easy
  washable. The Velcro tape has been used as a
  major part in this type. The fiber-glass mesh
  will be cut as per the measurements of the
  required windows / ventilators.
• The loop of the tape has been well sewed to four
  sides of the mesh and the normal type hook of the
  Velcro tape will be stapled (1 stapler pin / 3
  to 4 inches) on the outer wooden frame of the
  required windows / ventilators.
• Fibreglass mesh used
• Multi colours available.
• Easy to wash and Quick Install.
• Free Airflow, Rust Free and Durable.
• Fit within your Budget price.

SPECIFICATIONS SPECIFICATIONS
Fibre Mesh Sizes 18 x 16
Fibre Mesh Colors Gray, Black, White, Ivory Brown
Velcro Tape Size 20 mm thickness
Velcro Tape Colors Black, White
DIY - MAGNETIC TYPE

• This type Mosquito Net is used for windows and
  ventilator, Unique design and unbreakable PVC
  body for durable life. Insect screens are held
  to the window frame using magnets, 1 magnetic
  strip on insect screen another pasted on
  window frame with 3M adhesive magnetic tape.
• The attracting magnets forms a seal around the
  window frame yet allows you to easily open /
  close your windows or remove the whole insect
  screen to wash. Peel the screens off with the
  pull string at either corners at the bottom of
  insect screen to open/close window. Release the
  screen when you are done the insect screen
  will snap back.
• Unique Design
• PVC outer frame with Fibreglass mesh used.
• Easy to wash and Quick Install.
• Free Airflow, Rust Free and Durable.

SPECIFICATIONS SPECIFICATIONS
Fibre Mesh Sizes 18 x 16
Fibre Mesh Colors Gray, Black, White, Ivory Brown
Velcro Tape Size 20 mm thickness
Velcro Tape Colors Black, White
5
WINDOW - OPENABLE TYPE

• Window Insect screens make sure the pesky bugs
  stay out of your home. We can help you find the
  right insect screens that will work you.
• The channel bars which we use are very strong and
  durable when comparing to the other dealers all
  over the city. We used high quality virgin
  engineering thermoplastics for flexible and
  unbrakable long losting life. It is also free
  from fire and easy washable since the frame has
  been attached and detached easily from the
  wooden bars. Incase of aluminium / UPVC windows,
  Wooden beadings will be fixed on four sides and
  the window frames will be attached on it. Window
  mosquito nets are available at multi colors
• Easy to Clean and suits for daily use.
• Aesthetically designed Quality products.
• High quality Channel with epoxy coated.
• Non - breakable High quality components used
• Long losting Life.

SPECIFICATIONS Outer frame Width - 20mm,
Thickness - 9mm Colour Dark brown, Golden brown,
White, Ivory,
Black
Mesh used Fiber, Aluminium, SS- 304 white and
Black
Corner 45 90 Connector MCB
Hinges (AB) Thermoplastic Stopper Virgin
Thermoplastic
Handle Thermoplastic Rubber EPDM 4.4mm
MAGNETIC - WINDOW OPENABLE TYPE

• Magnetic Window Insect screens are ideal product
  for your Interior. Strip magnets and felt gives
  extra grip and withstand windforce.
• This type of frame slightly bigger than normal
  frame. Instead of plastic hinges we can use
  aluminium hinges and instead of plastic stopper
  we can use male and female magnetic strip be used
  to lock the frame. It gives extra grip and
  withstand windforce. Also we can use weather
  strip to inside and outside of the frame. The
  purpose of weather strip can cover the gape
  between frame and window. In this type, we mostly
  used black coated SS 304 for better look and
  long losting life.
• Easy to Clean and suits for daily use.
• High quality Channel with epoxy coated.
• Aluminium hinges and handle used.
• Magnets strip used to lock the frame.
• Weather strip used to cover the gapes.

SPECIFICATIONS Outer frame Width - 25.5mm,
Thickness - 12.7 mm Colour Dark brown, Golden
brown, White, Ivory,
Black
Mesh used Fiber, Aluminium, SS- 304 white and
Black
Corner
45 - 76mm depth Strip Weather s
trip
Magnet (AB) 10mm Rubber EPDM 5.5mm
Hinges
(AB) Aluminium Hinges
Handle
(AB) Thermoplastic
6
DOOR - OPENABLE TYPE

• This type of Stripe doors that is designed by
  using superior quality of material bases sourced
  from reliable vendors of the industry.
• The entire range of screen doors provided by us
  have joint corners with a solid kick plate to
  prevent damage, with a central mid bars in the
  metal openable hinged version. Furthermore, these
  are widely used for various applications and us
  well acknowledge for their durability and easy to
  maintain properties. Effective protection
  against insects, these are available in various
  designs, sizes finish and can be custom made as
  per the clients requirements.
• Easy to Clean and suits for daily use.
• Aesthetically designed Quality products.
• High quality Channel with epoxy coated.
• Using aluminium hinges and corners ressist
• sagging and gives long life.
• SPECIFICATIONS
• Frame Outer width - 45mm, Middle width - 35mm

Colour Dark brown, Golden brown, White,
Ivory Mesh used Aluminium, SS -316L, SS- 304
white and
Black
Corner
45 Magnet (AB) attachable
Hinges
Aluminium Hinges
Felt 4mm weather strip
Handle
(AB)Thermoplastic Rubber EPDM 6mm
TWO TRACK - SLIDING SYSTEM

• Magnetic Window Insect screens are ideal product
  for your Interior. Strip magnets and felt gives
  extra grip and withstand windforce.
• This type of frame slightly bigger than normal
  frame. Instead of plastic hinges we can use
  aluminium hinges and instead of plastic stopper
  we can use male and female magnetic strip be used
  to lock the frame. It gives extra grip and
  withstand windforce. Also we can use weather
  strip to inside and outside of the frame. The
  purpose of weather strip can cover the gape
  between frame and window. In this type, we mostly
  used black coated SS 304 for better look and
  long losting life.
• Very sturdy construction and visibility.
• High quality Channel with epoxy coated.
• Unique design and perfect space saver.
• Sliding track can be easy to remove and clean.
• Bearing wheels used for smoother sliding.
• SPECIFICATIONS
• Sliding Track Width - 60mm, Thickness - 12mm
  Outer Track Width - 45mm, Thickness - 30mm
  Colour Dark brown, Golden brown, White

Track 2 track system Felt 4mm Weath
er strip
Corner 45 - 76mm depth Wheel Bearing whe
el
Mesh Rubber EPDM 5.5m
SS-304 Black coated m
7
ROLLER - SHUTTER SYSTEM
Spring loaded vertical screen for windows, sun
slits, narrow kitchen windows. Retrieves 100
natural light and fresh air. Washable and easy
to maintain. These mosquito net is nothing but
same mechanism as like the roller shutter
systems. Strong panels will be screwed to hold
the mesh on left and right side of the window
net. A round pipe will be cut to the size of
window width and the mesh will be rolled in it
and fixed tightly with spring systems and finally
inserted into a round alloy panel. This will be
fixed as the top panel of the windows. An plate
will be attached to the outer end of the mesh
and it contains a center hole in which a thread
will be tied to pull and push the mesh from top
to bottom
Easy to handle and suit for all type of windows. Ideal product and elegant look for Interior. Powerful spring system used for slow or fast push and pull function. Perfect space saver. Easy to handle and suit for all type of windows. Ideal product and elegant look for Interior. Powerful spring system used for slow or fast push and pull function. Perfect space saver. Easy to handle and suit for all type of windows. Ideal product and elegant look for Interior. Powerful spring system used for slow or fast push and pull function. Perfect space saver. Easy to handle and suit for all type of windows. Ideal product and elegant look for Interior. Powerful spring system used for slow or fast push and pull function. Perfect space saver. Easy to handle and suit for all type of windows. Ideal product and elegant look for Interior. Powerful spring system used for slow or fast push and pull function. Perfect space saver.
SPECIFICATIONS SPECIFICATIONS SPECIFICATIONS SPECIFICATIONS SPECIFICATIONS
Outer frame 17mm thickness 17mm thickness 17mm thickness 17mm thickness
Colour Dark brown, Golden brown, White Dark brown, Golden brown, White Dark brown, Golden brown, White Dark brown, Golden brown, White
Mesh used PHIFER brand fiberglass Grey and Bla PHIFER brand fiberglass Grey and Bla PHIFER brand fiberglass Grey and Bla PHIFER brand fiberglass Grey and Bla ck

Top panel 50mm Mesh size 18 x 16
Side panel 37mm Accessries Fiber comp spring
Bottom panel 40mm Felt 4mm / 6mm st rip
PLEATED - SLIDING SYSTEM

• The retractable systems used for double cassette
  doors and Balconies that come with wider openings
  to
• allow sunlight and fresh air
• This mosquito net is highly rich look on your
  windows. The mechanism in this design is quite
  different from comparing with the other. In this
  type, the fibre-glass will be folded like zig-zag
  and a set of ropes will be inserted in between
  the foldings. The zig-zag folded mesh will be
  pleated at one side (either at right or left) and
  pull towards the other end for closing.
  Fabricated fibre-Glass is the only material can
  be used in this Pleated model.
• Easy to handle and easy to clean.
• Perfect space saving and elegant design.
• Zig zag foldable mesh for easy sliding.
• German mechanism used
• It can be service easily and low level cost.

SPECIFICATIONS
Outer panel 25mm width
Sliding panel 40mm width
Frame colour Dark brown, Golden brown and white
Mesh used Zig zag foldable fiberglass mesh
Mesh colour Grey and Black
Accessories Virgin Thermoplastic
8
DESIGN QUALITY SAFE INNOVATION
FABRICS
HEAD OFFICE
BRANCH OFFICE
36/99, Armenian Street, 2nd Floor, Mannady,
Chennai - 600 001. Email royalmosquitonets_at_gmail
.com
88C, Kurichi Main Road, 1st Floor,
Kulavanigarpuram, Tirunelveli - 5. Email
royalmosquitonets_at_gmail.com www.royalmosquitonets.
com
044 - 4204 3734 8056 106 910 7418 014 151
ROYAL FABRICS
