Pneumatic conveying system

1
SCORPIO ENGINEERING BMH PVT. LTD.

• www.scorpiobmh.com

2
About Scorpio BMH

• Scorpio Engineering BMH Pvt. Ltd., part
  of Scorpio Engineering Group is a Bulk Material
  handling systems and equipments engineering and
  manufacturing Company established in 1984. Since
  then the company has grown to be an industry
  leader in light and heavy bulk material handling
  systems.
• The heavy bulk systems are handled by Scorpio
  Engineering Pvt. Ltd. while the light in-plant
  systems and equipments are handled by Scorpio
  Engineering BMH Pvt. Ltd.
• The Company is professionally managed by an
  experienced team of Marketing, Operations and
  Technology engineers and managers.

www.scorpiobmh.com
3
Mobile Hopper Manufacturers

• The mobile hopper hopper can discharge to a belt
  conveyor or to trucks parked below. Suitable
  discharge arrangement can be provided which can
  also be controlled electrically.
• With state of the art features
• Dust control pulse jet vent filters
• With swing flaps for dust sealing
• Rail or Tyre Mounted
• Self-propelled or towed by crane or prime
  movers
• Discharge to Jetty Conveyors or Trucks
• Telescopic loading spouts
• Slide Gate or Sector Gates
• Hydraulic Jacking system
• Wind Barriers

www.scorpiobmh.com
4
Ship Unloader Manufacturers

• Scorpios F.I.B.C. (Flexible Intermediate Bulk
  Containers) FILLERS and UNLOADERS are completely
  self-contained units that come in a
  ready-to-use condition. All you have to do is
  provide a one-point power and compressed air
  supply!
• Specifications
• Bag size handled 90 cm x 90cm x 120cm. (Contact
  for other sizes)
• No. of Loops 4 Nos.
• Discharge type Bottom spout. (By untieing the
  draw string provided)
• Hopper holding capacity 1000 lit.
• MOC MS construction / SS304 contact parts
• Control Voltage 24V DC / 110V AC / 220V AC
• Dust collector In-built.
• Filter Cleaning Sequential reverse pulse jet
  cleaning

www.scorpiobmh.com
5
Pneumatic Conveying System

• Dense Phase Transporters (Denseflo Vessels) are
  the heart of systems handling material
  pneumatically in dense phase mode. They consist
  of a Coded Pressure Vessel with specially
  designed valves, instrumentation and controls.
• Specifications
• Conveying material Almost all powdered
  material
• Conveying capacity Upto 150 TPH
• Conveying distance Upto 1000m (Please check
  with SEBMH for particular application)
• MOC MS construction / SS304 contact parts
• Paint Synthetic Enamel paint - 100DFT.
  (Optional Epoxy paint)
• Offer Complete package with PLC/ SCADA,
  installation and commissioning

www.scorpiobmh.com
6
Bag Slitting Machine Manufacturers

• Scorpio Bag Slitting Machine (Model Multicut) is
  a versatile automatic slitter and earns its name
  owing to its ability to cut any type of bag be it
  paper or HDPE.
• Specifications
• MOC MS construction / SS contact parts
  (Optional)
• Capacity 300 to 600 bags/hour of 25 to 50 kg.
• Type of bag HDPE / Paper bags
• Bag dimension (L x B x H) 900 x 770 x 250 mm
• Max. Lump size Powder and pellets ( special
  design avilable for lumps application)
• Bag feed conveyor Additional based on
  requirement
• Control Voltage 24V DC / 110V AC / 220V AC
• Filter Cleaning Sequential reverse pulse jet
  cleaning mechanism

www.scorpiobmh.com
7
Storage Silos Manufacturers

• Used for material storage purposes and are
  custom-built. Available in various sizes, the
  construction can be conical, rectangular,
  cylindrical etc. Designed for mass flow discharge
  to prevent any rat holing, arching, bridging of
  materials.
• Specifications
• Type Circular / Rectangular
• MOC MS construction / SS304 construction /
  Linered silos
• Size Designed to customer requirement (Large
  silos upto 1000M3)
• Paint Synthetic enamel paint - 100 DFT.
  (Optional Epoxy paint)
• Supporting Structure Will be provided as
  additional
• Load cells and Weight indicators Will be
  provided as additional

www.scorpiobmh.com
8
Bulk Material Handling Manufacturers

• Scorpios Bulk Tankers are used to haul a major
  amount of dry bulk material across large
  distances from supplier to user for industries
  such as Food, Minerals, Cement, Chemicals,
  Petrochemicals etc. Proper logistics can lead to
  low inventories.
• Specifications
• Capacity 10 16m3 gross volume.
• Discharge type Conical discharge / Aerated
  bottom discharge
• Application Fine Powders / Pellets / PVC Resin
  etc.
• Conveying type Compressed Air/ Roots Blowers
• Conveying distance Preferably less than 30
  mtr.
• Safety Valve Provided
• MOC MS construction / SS304 contact parts
• Discharge Capacity 5 -15 TPH (Pl contact us
  for specific application)

www.scorpiobmh.com
9
Contact us

• Scorpio Engineering BMH Pvt. Ltd.
• 'Scorpio House'
• 132, Wheeler Road, Cox Town
• Bangalore 560 005, India
• Phone [phone]
• Phone [phone]
• E-mail  info_at_scorpiobmh.com
• Website  www.scorpiobmh.com
