Conveyor Belt Repair Material (2)

1
Conveyor Belt Repair Material
NIPL Engineering Pvt. Ltd
2

• Introduction to conveyor belt
• Conveyor belt is used to handle bulk material. It
  helps to transport bulk material for long
  distance. It can be used over varied terrain
  particularly for a wide range of travel paths.
• The main elements of the conveyor belt include
• Belt
• Pulleys
• Idlers
• Drive Unit
• Support structure

3

• The aspects of the design
• It helps to determine the conveyor belt capacity
• It is used for determining the maximum belt
  tension for the conveyor load
• Selection of the belt
• Selection of the driving pulley
• Motor power determination
• Selection of spacing and idlers

4

• Selection criteria for the conveyor belt
• The conveyor belts uses rubber covered belts and
  it is made of woven carcass with sufficient
  strength to support the load
• The rubber cover is used to protect the damage
• There are different types of belts based on the
  applications
• Steel cable belts
• Conventional belting
• Heat service belts

5

• Factors determining the belt selection
• Belt tension needs
• Speed and length of the conveyor
• Abrasiveness of the materials handled
• The size of the debris and their effect on the
  cover
• The conveyor loading method
• The power requirements for conveyor belt
• Power to activate empty belt
• Power to activate the load horizontally
• Power to activate the load vertically

6

• What is idlers and spacing?
• Idlers are used to protect the belt and provide
  support while carrying the load
• The idlers spacing on the loaded run is based on
  the bulk weight and the belt width.
• Benefits of the conveyor belt
• Silent transportation
• Need for restricted manpower
• Accidents are restricted
• Simple arrangements for both loading and
  unloading
• The loading happens at convenient points

7

• Benefits
• Energy efficiency in high pay load to total load
  ratio
• Breakdowns are limited
• Demerit of the conveyor belt
• Separate arrangement for conveyor belt repair
  material handling
• Materials that are hot is not transported over
  conveyor belt
• Vertical transportation of materials not possible
  on the belt
• The conveyor belt needs adequate cleaning and
  economical construction.
