Ceramic Diffuser The Ideal Aeration Solution For Hatcheries

1
Ceramic Diffuser The Ideal Aeration SolutionFor
Hatcheries
2
What is Ceramic Plate Diffuser?

• Ceramic Plate Diffuser is an enormously fine
  bubble diffuser and is often considered to as a
  Nano-bubble diffuser.
• It is made using a ceramic plate with very tiny
  micro holes, not even easily noticeable to the
  naked eye.
• Read more Use Of Nano Bubble Ceramic Plate
  Diffusers For High Efficiency Aeration

3
Advantages

• Their high oxygen transfer trait makes them
  perfect for use in RAS systems and hatcheries.
• Ceramic diffuser for fine bubble aeration is
  important for a happy and healthy pond, lake and
  tank.
• Air diffusers are a competent and inexpensive
  way to introduce oxygen into the water.

4
Specifications

• The ceramic plate diffuser has an inlet of ¼ and
  a bubble size of 10 to 20 microns mm which gives
  it very high Standard Oxygen Transfer Rate
  (SOTR). Because of such small size of holes and
  bubbles, the gas / air / oxygen remains suspended
  in the water for very long hence increasing the
  gas transfer rate to almost 30 of flow.
• The designed air flow in each plate is about 35
  ltrs / minute
• The main body is made of ceramic and the border
  is made of plastic. The product size is 350 mm
  length x 115 mm width with the plastic border.
  The actual diffuser area is 300 mm x 60 mm. The
  plate is heavy enough to stay at the bottom
  without any external anchors.
• Since the holes are small, the pressure required
  to operate the diffuser is also high. So regular
  twin lobe or root or ring blowers are not
  compatible with these plate diffusers. The
  continuous operating pressure required is of 6
  PSI and above is quite high so instead of
  blowers, these plates are used with either oxygen
  / ozone generators or with cylinders of air,
  oxygen, ozone etc. For example, with a 10
  ltr/minute Oxygen generator, one can connect a
  maximum of 4 plates.
• Burst pressure is above 50 PSI (4 Kg/cm2). The
  product life is around 10 years and it is
  compatible with Air, Oxygen, Ozone, Nitrogen and
  Carbon Dioxide

5
AirOxi Tube Products

• AirOxi Tube AirOxi Ceramic Plate Diffuser
• AirOxi Tube AirOxi Flexible Hose Diffuser
• AirOxi Tubes
• AirOxi Tube Self Sinking Aeration Tube
• AirOxi Tube Grid
• AirOxi Floating Diffuser Grid

Take a look at more details of our products
here http//www.airoxitube.com/aeration-tubing-pr
oducts/
