Conveyor Belt Vulcanizing

1
Conveyor Belt Vulcanizing
NIPL Engineering Pvt. Ltd
2
An overview on conveyor belts

• Conveyor belt is defined as belt operating
  between two or even more pulleys and it is
  supported on idlers. It can be classified
  according to
• Design Application

• General purpose
• Special purpose

• Profile path

• Horizontal
• Inclined

The conveyor belt parts include

• Belt
• Pulleys
• Idlers
• Drive mechanism
• Loading and discharging device

3

• The conveyor belt is made of
• Rubber

• For bulk material
• Made of carcass

• Woven cloth

• Light weight material

• Steel

• Suitable for metal industries

Characteristics of belt

• It provides high strength
• Low relative elongation
• Low mass
• High elasticity both longitudinally and on the
  crosswire
• High resistance to wear and tear
• Low hygroscopicity

4

• Understanding the drive mechanism
• To run a single pulley drive a range of
  30 to 50 kW is needed and it can go upto 250 kW
  based on the pulley drive.

• The head pulley turns the belt back and forth and
  it is coupled on certain occasion to drive
• The Tail Pulley returns the empty belt for
  loading on different occasions
• The Drive Pulley is linked to motor pulls belt
  for special surface grip
• The Snub Pulley is generally used for changing
  the belt direction
• Take Up Pulley is used for retaining belt tension

5

• Conveyor belt design
• The design is exclusively based on

• Space availability
• Conveying length
• Types of materials to be transported
• Capacity

Advantages of conveyor belt

• It can carry load upto 30000 t/h
• It supports a huge conveying path of 3-4 km in
  one conveyor
• The design is simple
• It comes with easy maintenance
• The operation is highly reliable
• It is highly flexible
• Conveyor belt vulcanizing provide quick and
  lasting belt repairs

6

• Conveyor belt applications
• The belt performs transportation and
  other functions like weighing, picking, sorting,
  grading, spraying, drying, cooling, sampling and
  more. It has a major role to play in mining. It
  is also used for special purpose like fire
  resistance, corrosion resistance, wear resistance
  and used to integrate with other equipment.
