Weighbridge Vehicle Positioning system

1
Vehicle Positioning System On Weighbridge
Provide By - I Magic Solution
2
Benefit of VPS System

• Make Sure to Vehicle Position on Weighbridge,
• Restrict malpractice, thief Issue and
  unauthorized access on Weighment time,
• Improve weighment Speed on Weighbridge,
• System check Zero Weight before Start Weighment
  and Between Two Weighment.
• System Control Vehicle Traffic for Weighment
• Traffic Light Indicator RED/Green for Instruct to
  Driver for Weighment
• Camera image Capture at Weighment time for
  Feature Analysis

3
Accessories

• Vehicle Positioning System,
• VPS Controller,
• CCTV IP Camera,
• Traffic Signal Light RED/GREEN.
• POE LAN Switch
• VPS Weighbridge Software
• Optional RFID, Boom Barrier, Sound System, LED
  Display

4
Process Flow Step for Weighment

• Weighbridge VPS Software Connect To VPS
  Controller, Infrared Sensor, Traffic Light, CCTV
  Camera.
• System Check if weighbridge Empty and Any Weight
  Display then System make RED Light On so
  weighment not Possible.
• When all condition ok then Both Site Green Light
  On
• On Green Light Driver Start Weighment Process
• If Vehicle Position and weight Stable then System
  Show Weigh on Software
• Operator Can Capture weight and Click Save
  Weighment
• On Saving Time system Capture vehicle Position
  Image and Save With ticket.
• On Weighment time Both RED Light on so no any
  Vehicle Driver Can Drive vehicle
• Ones Successful Weighment Weighbridge Ready For
  another Weighment

5
Layout Sketch Drawing for VPS System
6
Software Technologies

• Software Develop in VB.NET
• Database is MS SQL

7
Traffic Light Specification
No Parameter Detail
1 Power Consumption 8 to 12 W
3 Voltage 230 AC / 12 DC / 24 DC
4 Voltage Range 190 to 240
5 Operating Temperature -30 to 60
6 Minimum Weight 1.9 Kg Approx
7 Diameter 200 mm / 8
8 Number of LED 102 Nos
9 Visibility 500 Feet
10 Color Red / Green
11 Lens UV Stabilized Polycarbonate
12 Body Metal
13 Power Saving 90
14 Light Source Ultra bright led enables
8
Computer PC

• I3 or Higher CPU
• 2 GB RAM
• 512 GB HDD
• LED Monitor
• Onboard LAN Port, COM Port,
• Win 10 / Win7 OS

9
The End

• Provide By - I Magic Solution
