SMALL ANIMAL INCINERATORS
JKA-230SA Small Animal waste incinerators to be
used to incinerate dead animals like Dog, Goat,
Pigs, Hen, Cat, Duck etc. It is commonly used in
animal hospitals, clinics, animal shelters,
animal control area etc. It is widely used to
destroy to animal infection diseases, viruses
and animal waste material. These products are
manufactured using latest technology machinery.
Dead animal incinerator with dual chambers for
complete combustible their dead bodies / carcass.
The chamber temperature is controlled by a
digital temperature controller. Separate doors
for waste burning chamber and for ash collection
and chimney is provided for emission of
fumes. The incinerator reduces most combustible
solid waste to nearly 2-3 percent by volume and 3
by weight. Easy to install and extremely
durable equipment. It is available in varied
capacity/sizes based on the requirement of Forest
Department, Animal Industries, Poultry farms and
vet. hospitals. CHARACTERISTICS -
Application Temperature range Power Requirement
Temperature monitoring
Floor-standing Min. 850 C - Max. 1450
C LPG/Diesel/Electrical Digital Display

• Ÿ Ÿ Ÿ Ÿ
• Average ash residue () 3
• Design and prepare the dead animal incinerator
  with chamber (Primary and Secondary chambers) for
  complete combustion as per CPCB Norms.
• Filtration of smoke before releasing it in
  atmosphere.

E-mail info_at_microteknik.com, incinerator_at_microte
knik.net www.microteknik.net, www.microteknik.com
, www.incineratorindia.com
4
Operating Principal The disposal of waste is
based on the principal of incineration of the
waste so as to destroy any degradable and
infectious material and reduce it volume and mass
without producing any type of pollution. Design T
he design is based on the guidelines set by
Central Pollution Control Board (CPCB)-India and
normally adopted by military installation all
over the country and worldwide. The Efficient
power is supplied by electricity as well as oil
burners for larger installation. Flame Flame Chim
ney Primary Chamber Feeding
Air
Air Secondary Chamber ID Fan FLOW DIAGRAM
Smoke Treatment

• System Capacity
• The offered system which is operating by
  automatic gas or Oil fired burners made with high
  efficiency Double
• Chambered Incinerator suitable for disposal of
  all kind of Dead animals. The equipment has got
  solid state temperature controller with Digital
  Display, Operating Switches, Indicators and high
  grade thermal insulation along with control
  panel with flue discharge system.
• General Construction
• Robust, Reliable and E?cient.
• Pre-fabricated 5mm - 8mm robust mild steel
  casing, seam welded suitably sti?ened/braced
  where necessary.
• Paint ?nishing - The Mild steel structures are
  completely painted using a two pack high grade
  paint system that is baked into the steel
  structure at 70 C for 10 hrs.
• The layers of refractory lining in the primary
  and secondary chambers totaling of 230 mm. rated
  at 1450 C, provide increased fuel e?ciency.
• Counter weight resilient refractory ?ber
  insulation lid, Gives excellent thermal e?ciency.
• Removable roof and back plate for ease of
  maintenance.
• All combustion fuel pipe work and electrical
  systems are weather proof and in accordance.
• Excess air and rapid cooling systems ?tted as
  standard, aiding cleaner burns and faster cool
  down times.
• Construction
• The incinerator is two chamber type coupled with
  air pollution control device (APCD). Detail
  specification of equipment as follows

General Description

• Type of Waste
• Mode of Heating
• Ash Removal
• Equipment
• Electrical Supply

Dead Animal Diesel/Electrical/LPG
Manual Static 240V, 1 phase 440V, 3 phase
Technical Specification
Temperature
LoPN Hkkjr
Clean India
850C - 1000C 1050C - 1450C

• Primary chamber
• Secondary chamber

LoPN n"Vh---LoPN l"Vh
E-mail info_at_microteknik.com, incinerator_at_microte
knik.net www.microteknik.net, www.microteknik.com
, www.incineratorindia.com
5
ENERGY

• Burner
• Fuel
• Consumption
• Tank

Automatic Diesel/Electricity/LPG 4-5 Litre per
animal (Diesel) 50 Litre
PRIMARY CHAMBER

• Type
• Material of construction
• Ignition
• Temperature Control
• Inside

Static M.S. 5MM - 8 MM Automatic Automatic High
alumina refractory brick IS-8-1994 line with
insulation brick IS 2042-2006 230 mm 850C
1000C

• Refractory thickness
• Temperature

SECONDARY CHAMBER

• Type
• Material of construction
• Inside

Static M.S. 5MM 8MM High alumina refractory
brick IS-8-1994 line with insulation brick IS
2042-2006 230 mm 1050C 1450C gt2
Sec Thermocouple J Type/K Type

• Refractory thickness
• Temperature
• Gas residence time
• Temperature sensor

EMERGENCY STACK
M.S Provided

• MOC
• Refractory

COMBUSTION FAN
Centrifugal Provided M.S Direct

• Type
• Modulation
• MOC
• Drive

CONTROL PANEL
Digital M.S Digital

• Type
• MOC
• Type of temperature controller
• Finish painting type
• Auto cut of Burners/heater

Powder coated Provided
CHIMNEY HEIGHT AS PER APCD

• MOC
• Type
• Paint

M.S (FRP or Rubber liming) In Built, Height
According to capacity Heat Proof Silver/Black
LoPN Hkkjr
Clean India
LoPN n"Vh---LoPN l"Vh
E-mail info_at_microteknik.com, incinerator_at_microte
knik.net www.microteknik.net, www.microteknik.com
, www.incineratorindia.com
6
G
E D
H
B
A
I
F
C
A- PRIMARY CHAMBER B- PRIMARY BURNER/HEATER
C- ASH COLLECTOR GATE D- SECONDARY CHAMBER
E- SECONDARY BURNER
F- SERVICE MAINTENANCE GATE G- CHIMNEY H- FEEDING
PORTION I- ID FAN

• SMALL ANIMAL INCINERATOR-MOVEABLE
• Whole unit mounted on wheeled cart.
• Easy to work at di?erent site.
• Batteries Genset available with mobile
  incinerator as per requirement. Ÿ No need to
  transfer all waste at one place from various
  area, Machine will go to incinerate the waste
  with help of tractor or any other vehicle at
• site.
• JKA-230SA-M
• NOTE Image/Diagram shown above is for
  illustration purpose only. Actual image may vary
  due to speci?cation, Design, Technology
