Crane System - Sparkline

1
Crane System - Sparkline
www.sparklineequip.com
2
Cranes Technology
SG-US Crane
Wall Mounted Jib Crane
SG-EOT Crane
SG-Goliath Crane
Column Mounted Jib Crane
DG-Goliath Crane
DG-EOT Crane
DG-US Crane
SG-Semi-Goliath Crane
DG-Semi-Goliath Crane
www.sparklineequip.com
3
Crane Technology- Under Slung Cranes
Sparkline offers Double Girder Under Slung Crane
powered by Stahl Crane Systems to achieve full
utilization of space higher capacities. This
crane automation can be provided as per
customized. Product Range Capacity 1 Ton to
10 Ton Span 2 Mtr. to 20 Mtr. Hoist
Stahl Chain Hoist / Wire Rope
Hoist Speed type Double Speed/ Variable Speed
www.sparklineequip.com
4
Sparkline offers Single Girder Under Slung Crane
powered by Stahl Crane Systems to achieve full
utilization of space. This crane automation can
be provided as per customized. Product
Range Capacity 1 Ton to 5 Ton Span
2 Mtr. to 16 Mtr. Hoist Stahl
Chain Hoist / Wire Rope Hoist Speed type
Double Speed/ Variable Speed Protection
IP55/IP66/ Explosion Protected Power Supply
Festooning System/ Bus Bar System Crane Control
Control Pendent/ Radio Remote Control
www.sparklineequip.com
5
EOT Cranes
Product Range Capacity 2 Ton to 160
Ton Span 4 Mtr. to 36 Mtr. Hoist
Stahl Wire Rope Hoist Speed type
Double Speed/ Variable Speed Protection
IP55/IP66/ Explosion Protected Power Supply
Festooning System/ Bus Bar System Crane Control
Control Pendent/ Radio Remote Control
www.sparklineequip.com
6
Product Range Capacity 0.5 Ton to 15
Ton Span 4 Mtr. to 36 Mtr. Hoist
Stahl Chain Hoist / Wire Rope
Hoist Speed type Double Speed/ Variable
Speed Protection IP55/IP66/ Explosion
Protected Power Supply Festooning System/ Bus
Bar System Crane Control Control Pendent/ Radio
Remote Control
www.sparklineequip.com
7
Goliath Cranes
Product Range Capacity 5 Ton to
160Ton Span 4 Mtr. to 30 Mtr. Hoist
Stahl Wire Rope Hoist Speed type
Double Speed/ Variable Speed Protection
IP55/IP66/ Explosion Protected Power Supply
Festooning System/ Bus Bar System Crane Control
Control Pendent/ Radio Remote Control
www.sparklineequip.com
8
Product Range Capacity 1 Ton to 10Ton Span
2 Mtr. to 25 Mtr. Hoist
Stahl Chain Hoist / Wire Rope Hoist Speed type
Double Speed/ Variable Speed Protection
IP55/IP66/ Explosion Protected Power Supply
Festooning System/ Bus Bar System Crane Control
Control Pendent/ Radio Remote Control
www.sparklineequip.com
9
Semi Goliath Cranes
Product Range Capacity 5 Ton to
160Ton Span 4 Mtr. to 30 Mtr. Hoist
Stahl Wire Rope Hoist Speed type
Double Speed/ Variable Speed Protection
IP55/IP66/ Explosion Protected Power Supply
Festooning System/ Bus Bar System Crane Control
Control Pendent/ Radio Remote Control
www.sparklineequip.com
10
Product Range Capacity 1 Ton to 10Ton Span
2 Mtr. to 25 Mtr. Hoist
Stahl Chain Hoist / Wire Rope Hoist Speed type
Double Speed/ Variable Speed Protection
IP55/IP66/ Explosion Protected Power Supply
Festooning System/ Bus Bar System Crane Control
Control Pendent/ Radio Remote Control
www.sparklineequip.com
11
Jib Cranes

• Slewing range from 180 Deg to 360 Deg
• Suitable for Indoor outdoor application
• Capacity varies up to 3.2 ton and span up to
  6Mtr.
• Special profile rail Jib arm which is
  frictionless helps in easy and
• smooth movement of body by less effort
• Also if needed I-Beam profile as running beam
  with motorized
• motion of hoist for traveling lifting
• Jib crane is installed by using chemical bolts
  civil foundation
• bolts

www.sparklineequip.com
12
Light Weight Rail System
SR- IIB Rail System (Internal Bus Bar)
Rail System with Festooning
www.sparklineequip.com
13
Contact Us
F-II Block, Plot No 38, MIDC Pimpri, Pune,
Maharashtra.
Address
www.sparklineequip.com
Visit us at
Phone
8144645457
sales_at_sparkline.co.in
Email Id
14
Thank You
