Top 5 Solar Inverters By Amazing Solar

1
Top 5 Solar Inverters By Amazing Solar
2
1. SMA Inverters
100 Ease and Comfort With SUNNY BOY 3.06.0The
new Sunny Boy 3.06.0 ensures maximum energy
yields for private homes. Thanks to its
integrated web interface for easy commissioning
via a smartphone or tablet and SMA Smart
Connected service, this inverter offers true ease
and comfort for PV system operators and
installers. New With its integrated RS485
interface, the TS4-R module optimizers can be
easily added into the system, with all
communication and monitoring facilitated through
the inverter.
3
Quick and easy to install

• With its reduced weight, the Sunny Boy can be
  installed quickly while taking up minimal space.
  The Sunny Boy can be commissioned quickly via
  smartphone or tablet thanks to its web interface.
• One-person installation due to low weight of 17.5
  kg
• Compact design through minimum space requirements
• Quick installation thanks to external connections
• Intuitive commissioning and local monitoring via
  a smartphone or tablet

Intelligent Solar Pwer Generation
Established product features such as SMA ShadeFix
and SMA Smart Connected are now supplemented with
integrated TS4-R communication for module
optimization. Thanks to this, even shade on the
module is no problem.
4
Intelligent Solar Pwer Generation
The SMA ShadeFix integrated shade management
system ensures maximum yields in light shade. For
large amounts of shade or complex roof
structures, TS4-R module optimizers can be
installed easily and selectively for maximum
yields.

• NEW Integrated TS4-R communication for
  monitoring at the module level
• Integrated shade management with SMA ShadeFix
• Automatic inverter monitoring via SMA Smart
  Connected
• Free online monitoring via Sunny Portal and Sunny
  Places
• Dynamic active power limitation means direct use
  of excess energy, less power from the grid

5
2. Fronius Inverters

• With power categories ranging from 1.5 to 3.1 kW,
  the Fronius Galvo is perfect for households and
  is especially suitable for self-consumption
  systems. The integrated energy management relay
  allows the self-consumption component to be
  maximised. A host of other smart features make
  the Fronius Galvo one of the most future-proof
  inverters in its class for example, integrated
  datalogging, simple connection to the internet by
  WLAN, or plug-in card technology for retrofitting
  additional functions.

6

• SNAPINVERTER TECHNOLOGY
• AUTOMATIC HF TRANSFORMER SWITCHOVER
• INTEGRATED DATA COMMUNICATION
• SMART GRID READY
• MZERO FEED-IN

Four Different Types Of Inverters

• FRONIUS GALVO
• FRONIUS GALVO UL
• FRONIUS PRIMO
• FRONIUS PRIMO UL

7
3. SolarEdge Inverters
The SolarEdge DC-AC PV inverter is specifically
designed to work with the SolarEdge power
optimizers. Because MPPT and voltage management
are handled separately for each module by the
power optimizer, the inverter is only responsible
for DC to AC inversion. Consequently, it is a
less complicated, more cost effective, more
reliable solar inverter with a standard 12 year
warranty, extendable to 20 or 25 years. The fixed
string voltage ensures operation at the highest
efficiency at all times independent of string
length and temperature. In addition to its
functionality as a DC-optimized inverter, the
single phase inverter also manages battery and
system energy as part of SolarEdges battery
storage solution.
8

• Solar inverters specifically designed to work
  with power optimizers
• 2.2kW to 6kW inverter range
• Superior efficiency
• Standard 12-year warranty (extendable to 20 or 25
  years)
• Built-in module-level monitoring receiver
• Communication to internet via Ethernet or
  Wireless (Wi-Fi, ZigBee Gateway, Cellular)
• Supports PV and battery management as part of the
  StorEdge solution
• IP65 / NEMA 3R Outdoor and indoor installation
• Three Different Types Of Inverters
• Single Phase Solar Inverters
• Three Phase Solar Inverters
• Commercial Three Phase Solar Inverters

9
Highlights Of Solaredge

• Significantly reduced initial investment thanks
  to an application-oriented battery capacity of 2
  kWh
• No need to design the battery system so no
  battery expertise is required
• Quick and easy wall mounting
• Efficient charge management and load control
• Maximized reliability through lithium-ion cells
  from LG Chem

10
4. Abb Inverters
ABBs three-phase PRO-33.0 string inverter is
designed to meet the needs of the entire supply
chain from system integrators and installers to
end users. The inverter offers cost-efficiency in
a high power, wall-mountable package with very
high conversion efficiency. The all-in-one
design, with built-in and monitored PV plant
protection devices, reduces the need for costly
external devices. The high maximum DC input
voltage of up to 1100 V increases PV system
design flexibility.
11

• The inverter is available in 33 kW and is
  designed for medium and large de-centralized PV
  systems either on large-scale commercial and
  industrial rooftops or ground-mounted PV plants
  up to megawatt (MW) sizes.
• Compact, high power wall-mountable package
• High maximum DC input voltage of up to 1100 V
• Configurable all-in-one design
• Advanced grid support functions
• Safe and intuitive user interface
• Robust enclosure, with IP65 rating suitable for
  outdoor installation

12
Two Different Types Of Inverters

• Single Phase Solar Inverters
• Three Phase Solar Inverters

13
5. Solax Inverters
The new X-Hybrid 3-phase inverter from SolaX is
the latest incarnation of the market leading
range of hybrid inverters, offering a flexible
and scalable solution for both domestic and
commercial applications. The 3-phase series
includes inverters ranging in size from 5 to
10kW, and with the ability to install multiple
inverters in parallel, scalable battery storage
for commercial applications is now a reality.
14

• The inverter is equipped with a built-in EPS
  (Emergency Power Supply), had multiple
  communication options and can be controlled
  remotely.
• High Efficiency
• Wide Voltage Range
• IP65 Rated
• Increased self consumption
• Unbalanced output supported
• Generator interface
• Remote control function

15
Six Different Types Of Inverters

• X-HYBRID THREE PHASE
• X1 MINI
• X1 BOOST
• X1 AIR
• X1-LX
• X3

16
Thank You
