VME Precast Water Tanks
Be Smart, Use Precast

• Just Dig, Drop and Use

marketing_at_vmeprecast.com
www.vmeprecast.com
2
Precast Tank Types
VMEs comprehensive range of tank types include
Commercial Tanks
Industrial Tanks
Domestic Tanks

• Suitable For
• Individual Houses
• Villas
• Low to Medium Rise Apartments
• Labour Colonies
• Small Enterprise

• Suitable For
• Offices
• Institutions
• Hotels
• Hospitals
• High Rise Apartments

• Suitable For
• Water Treatment Plants
• Sewage Treatment Plants
• Petrol Bunks
• Transport and Logistics Yards
• All Industries

3
Domestic Tanks
Circular Tank
Standard Sizes of Circular Tank
Manhole 600mm x 600 mm
Type Product Code Capacity (L) Diameter (m) Height (m)
Domestic TNDC05L 5000 2.1 1.5
Domestic TNDC06L 6000 2.1 1.8
Domestic TNDC07L 7000 2.1 2.1
Domestic TNDC08L 8000 2.1 2.4
Height
Cover Slab
Tank Wall
Base Slab
TN(Tank) D(Domestic) C(Circular)
05(Capacity) L(Light Duty)
Diameter
Rectangular Tank
Standard Sizes of Rectangular Tank
Manhole 600mm x 600 mm
Type Product Code Capacity (L) Length (m) Width (m) Height (m)
Domestic TNDR08L 8000 2.5 2.0 1.6
Domestic TNDR09L 9000 2.5 2.0 1.8
Domestic TNDR10L 10000 2.4 2.4 1.8
Height
Cover Slab
Tank Wall
Base Slab
Length
marketing_at_vmeprecast.com
www.vmeprecast.com
Width
4
Commercial Tank
Standard Sizes of Commercial Tank
Type Product Code Capacity (L) Length (m) Width (m) Height (m)
Commercial TNCR12L 12000 2.4 2.4 2.1
Commercial TNCR12H 12000 2.4 2.4 2.1
Commercial TNCR13L 13500 2.4 2.4 2.4
Commercial TNCR13H 13500 2.4 2.4 2.4
Commercial TNCR15L 15000 4.0 2.5 1.5
Commercial TNCR15H 15000 4.0 2.5 1.5
Commercial TNCR16L 16000 4.0 2.5 1.6
Commercial TNCR16H 16000 4.0 2.5 1.6
Commercial TNCR18L 18000 4.0 2.5 1.8
Commercial TNCR18H 18000 4.0 2.5 1.8
Commercial TNCR20L 20000 4.0 2.5 2
Commercial TNCR20H 20000 4.0 2.5 2
Rectangular Tank
Manhole 700mm x 700mm
Cover Slab
TN(Tank) C(Commercial) R(Rectangular)
12(Capacity) L(Light Duty)
TN(Tank) C(Commercial) R(Rectangular)
12(Capacity) H(Heavy Duty)
Ribs For Better Strength
Base Slab
marketing_at_vmeprecast.com
www.vmeprecast.com
5
Industrial Tank
Standard Sizes of Industrial Tank
Type Product Code Capacity (L) Length (m) Width (m) Height (m)
Industrial TNIR22L 22000 4 2..5 2.2
Industrial TNIR22H 22000 4 2..5 2.2
Industrial TNIR23L 23000 6 2.5 1.55
Industrial TNIR23H 23000 6 2.5 1.55
Industrial TNIR27L 27000 6 2.5 1.8
Industrial TNIR27H 27000 6 2.5 1.8
Industrial TNIR30L 30000 6 2.5 2
Industrial TNIR30H 30000 6 2.5 2
Industrial TNIR33L 33000 6 2.5 2.2
Industrial TNIR33H 33000 6 2.5 2.2
Rectangular Tank
Manhole 700mm x 700mm
Cover Slab
TN(Tank) I(Industrial) R(Rectangular)
22(Capacity) L(Light Duty)
TN(Tank) I(Industrial) R(Rectangular)
22(Capacity) H(Heavy Duty)
Ribs For Better Strength
Base Slab
marketing_at_vmeprecast.com
www.vmeprecast.com
6
Material Specification

• Concrete Grade 40 to Grade 45
• Steel Fe500
• Nominal cover 25mm

Requirements

• Bulk density of backfill soil should be 18kN/m3
• Backfill material adjacent to invert wall should
  be of granular type

Design Criteria

• Design is based on
• IS 456 2000
• IS 3370 2009
• IRC 6 - 2017 Cl. 214.1.1.3

marketing_at_vmeprecast.com
www.vmeprecast.com
7
Loads considered in the design
Heavy Duty
Light Duty
marketing_at_vmeprecast.com
www.vmeprecast.com
8
Quality Checks

• Apart from the quality checks on raw materials,
  production and finishing, tanks are scrupulously
  checked for watertightness before delivery

marketing_at_vmeprecast.com
www.vmeprecast.com
9
Benefits
Suitably designed even for areas with spatial
constraints
Easy and Quick Installation
High Strength
Maintenance Free
Factory Made
Environmental Friendly
Affordable Price
Easily Relocated
Chemically Inert
Durable
Marketing_at_vmeprecast.com
www.vmeprecast.com
10
Installation Procedure
Digging
Placing
Back filling
11
Gallery
12
(No Transcript)
13
Inter Connecting Tanks
Holes provided to connect tanks for larger
capacity
14
Our Precious Customers
Products delivered anywhere across South India
For any further queries on products, feel free to
contact us
98400 - 41400
