Automatic Lubrication System
By Andantex USA INC. www.andantex.com
2
OVERVIEW
High-performance automatic lubrication pumps for
re-lubrication of rack and pinion, open gearing,
ball screws, chains, as well as linear and
rotary bearings. A compact smart design that
bridges the gap between centralized automatic
lubrication systems and single point systems.
01
3
Automatic Lubrication System Flexxpump
Specialized lubrication pumps with accessories
and specialty greases for automatic
re-lubrication of racks and pinions, open
gearing, linear guideways, ball screws, and
chain drives. Andantex USA offers two sizes of
the Flexxpump with grease capacities of 1500 cc
or 400 cc. The Flexxpump units can also be used
for lubrication with oil with refillable
reservoirs from 500 to 2,000 cc. The positive
displacement piston pump with built in check
valves can deliver up to 70 bar (1000 psi) of
pressure to pump greases up to NLGI 2.
02
4
Flexxpumps can be supplied with on board
programing or set up to be controlled by the
machines PLC. Our greases were developed
specifically for optimum lubrication of gearing,
linear slides, ball screws, and food industry
environments. The greases provide the correct
mix of viscosity, adhesive additives, and
corrosion resistance for the specific component
being lubricated. The open cell Polyurethane
(PU) foam applicators allow the lubricant to be
applied or absorbed to insure the correct film
thickness for optimum lubrication. Flexxpump is a
compact, cost effective system that helps take
the guess work out of lubricating components.
03
5
Complete System Consists of
FlexxPump Automatic Relubrication unit with
piston pump, programmable time, and delivery
rate settings. Automatic grease and oil
lubrication rates controlled by PLC or on-board
programming. 1-10 outlets available for
multi-point lubrication. 40 individual
lubrication points are available when using a 10
outlet FlexxPump. Powered by battery or 24V DC
supply. FlexxPump can achieve 70bar (1000PSI)
for pumping grease up to 10 meters.
04
6
Complete System Consists of
9 different greases specifically developed for
components to be lubricated. Greases for open
gearing, linear slides, ballscrews, chain
drives, and food grade available. Greases
available in replaceable 400cc, and 1500cc
cartridges, 1Kg. Tin, and 400cc cartridge for
grease gun. Oil to be held in refillable oil
reservoir. Custom greases can be put into grease
cartridges.
05
7
Polyurethane (P.U.) Foam Applicators
Open Cell polyurethane foam can absorb up to 90
of its volume allowing high viscosity lubricants
to be applied and absorbed. Thus, avoiding
hardening New gear tooth and chain sprocket
applicators insure correct film thickness Custom
PU Foam Pinions available upon request. Tubing,
Fittings, and Tools Prefilled tube with our
different greases available for quick
lubrication start up Many options for line
splitters, and progressive distributors
available.
06
8
Applications
Packaging Speed and Torque Distribution Rack
Pinion Drives Ring Gear Pinion Drives Very
High Performances Machine Tools
07
9
ABOUT ANDANTEX
Since our inception in 1980, Andantex USA
objectives remain the same Providing quality
unique gearboxes and solutions for use on
industrial machinery. All Sales, Engineering,
Manufacturing and after market support are
located at our headquarters in Wanamassa, New
Jersey. Each member of our sales and engineering
teams offer our customers the technical expertise
required to meet their application requirements,
custom designs, support and solutions to enhance
productivity. As part of the global network of
companies and products sold under the
Redex-Andantex brand name, and in conjunction
with world class rack manufactures, Andantex USA
is recognized as a leading provider of
high-precision motion control components and
systems.
