Title: Understanding Vertical Probe Cards


1
Understanding Vertical Probe Cards
  • Semi Probes

2
  • Vertical-contact probe cards for wafer testing
    have several advantages, including full array
    testing and high parallel probing flexibility.
    Regardless of how the pads are arranged, several
    dice can be probed and examined at the same time.
    Parallel testing procedures can significantly cut
    costs.

3
Full -Array Probing
  • The widespread use of flip-chips and other array
    bumping techniques necessitates the contact of a
    large number of pads on a single square
    centimeter. Because of the physical limits
    imposed by the needle's horizontal arrangement,
    this application cannot be carried out with epoxy
    ring probe cards.
  • Increasing the throughput of a probing line
    lowers test costs and, lowers manufacturing
    costs. As a result, the goal is to test as many
    chips as feasible at the same time while reducing
    the number of touchdowns per wafer. The pads on
    the wafer must be placed in specific patterns for
    epoxy ring probe cards, due to physical
    limitations in the horizontal placement of the
    needles, parallel probing was adopted. Parallel
    probing with epoxy ring probe cards are
    frequently required to be factored into the chip
    design. This highlights a few drawbacks in the
    use of parallel probing.

4
High-Temperature Range
  • During the die test, the temperature range
    gradually widens. Temperatures of 0 to 125C are
    necessary for numerous sorts of probing
    procedures. In this case, too, the traditional
    probing card technology demonstrates its
    limitations. In terms of thermal behavior, the
    construction of a needle card is exceedingly
    intricate and difficult to control.
  • Higher probing requirements can be met with
    vertical-contact probe cards. The buckling-beam
    principle is the foundation for a vertical probe
    card (or buckling wire). The bending or buckling
    of columns is defined by mathematical formulae as
    a function of loads applied to them. This
    relationship demonstrates that if a force is
    applied to the wire's end, the wire will bend and
    generate a spring force that is nearly
    independent of the wire's displacement. The force
    graph is constructed as a function of
    displacement for a buckling wire and a
    compression spring as a comparison. A significant
    non-linear spring characteristic is achieved,
    resulting in homogeneous force distribution over
    all contacts of a vertical probe card, in
    contrast to the spring concept of a needle card.

5
Vertical Probing Assembly
  • The ViP head, which contacts the wafer (DUT), and
    the ViP connection, which ensures good contact to
    the PCB, make up the vertical probing assembly.
    The ViP head is made up of guide plates that are
    drilled to match the wafer footprint. The holes
    must be placed with exceptional precision to
    ensure high probe positioning accuracy of the
    buckling wires. The ViP head's buckling beams
    align perfectly with the wires in the ViP
    connector, ensuring great contact. This design
    also makes it easy to change the ViP head for
    maintenance. The following capabilities were
    given significant consideration during
    development high density probing flexible,
    parallel probing the high accuracy of contact
    points and suitability for high-temperature
    ranges.

6
High-Density Probing
  • The vertical technology allows for the precise
    arrangement of thousands of contacts on a postage
    stamp's surface. Buckling beams (spring wires)
    that have been specially made are positioned in
    guide plates that have been perforated according
    to the footprint of the DUT. There are two types
    of vertical probe tip shapes flat and pointy.
    When contacting solder bump vertical probe card,
    a flat tip is always utilized when contacting
    aluminum surfaces, a pointed tip is better since
    it will penetrate any oxide layer and when
    contacting gold surfaces, both pointed and flat
    tips can be used. Parallel probing reduces test
    time by a significant amount. If the contact
    pattern can be easily modified according to the
    intended parallel test strategy, the vertical
    probe card is especially ideal for parallel
    probing. This is accomplished by drilling a guide
    plate based on the DUT's footprints. Parallel
    testing must be factored into the wafer design.

7
In Short
  • ViProbe can be used to probe memory wafers in a
    variety of ways, including array probing,
    peripheral parallel probing, and multi-die
    probing. When it comes to array probing, the
    ViProbe is particularly well suited to full array
    probing, such as on flip-chip wafers. Semi Probe
    offers a wide range of probe cards and
    accessories, check out for details.

8
