Large Format 2424 S5 Engraver

1

• Specialized in Laser and Rotary Engraving,
  Cutting and
• Marking Machines

2

• Large Format 2424 S5 Engraver

3
Table Of Content

• Introduction
• Features
• Specifications
• Applications
• About Signvec Technology

4
Large Format 2424 S5 Engraver

• The 2424 S5 Engraver is perfect for light to
  heavy-duty job applications in a large engraving
  area. Great for a variety of jobs such as large
  signage, high-volume production projects,
  industrial marking, and multiple plate jobs! The
  2424 computerized engraving machine is also ideal
  for marking industrial items such as tools,
  cylinders, pipes, and gauges.

5
Large Format 2424 S5 Engraver

1. 24" x 24" Large work area
2. Aluminum T-slot table to accommodate various
   work-holding fixtures
3. Engraves items up to 1.875 thick (3.5 thick or
   more w/ custom risers)
4. Uses 11/64 or 1/4 top-loading spindle (Collet
   optional)
5. Optional Automatic Raster Braille Inserter for
   automatic Braille bead insertion
6. A limited 2-year warranty

6
Large Format 2424 S5 Engraver
7
Large Format 2424 S5 Engraver
8
Large Format 2424 S5 Engraver
Specifications Chart Specifications Chart
Software Vision Express standard (Expert or Pro optional)
Maximum work area 24" x 24"
Maximum size part 30.5" (L) x Any Width x 5" (H)
Z-Axis Stroke 1.75" Standard (3.375" with Riser Kit)
Spindle Type 11/64", 6mm or 1/4" / Top Loading, Collet Spindle Available
Resolution / Speed 0.0002" - 10"/sec
Table Type Aluminum Flat Bed Table (Optional Aluminum T-slot Table)
Interface Ethernet
9
Large Format 2424 S5 Engraver
Specifications Chart Specifications Chart
Controller Series 5 Controller with V-Touch Pendant
Warranty 2-Year Limited
Power Requirements 110/220V 5 Amp
Physical Dimensions 33"(W) x 42"(D) x 20"(H)
Series 4 Controller Dimensions 13.5"(W) x 16"(D) x 4.5"(H)
Shipping Dimensions 43"(W) x 80"(D) x 30"(H) - 532 lbs
Additional Options Automatic Braille Inserter, 50,000 RPM Spindle, 3D Engraving Software, DACS (Digitally Aligned Cutting System)
10
Large Format 2424 S5 Engraver

• Applications
• Sign making
• Trophy Plaques
• Parts Marking
• Badge Engraving
• ADA Braille Signs
• Wood Engraving
• Plastic Engraving
• Metal Engraving
• Tag Engraving
• Control Panels and more!

11
About Signvec Technology

• Signvec Technology is the authorized distributor
  for all types of Engraving Machines, Universal
  Laser Systems, Router Systems, Signvec Engravers,
  Router, Laser Systems as well as Engraving
  Materials.
• To Know more details Visit
  http//www.signvec.com
