Clean Partition

1

• We work on the forefront of INNOVATION AND
  TECHNOLOGY to take products from an idea all the
  way to the client

2
Clean Partition
3
Table of Content

• Our Products
• About Utopias Cleanroom Partition
• Characteristics
• Product Images
• Specification
• About Us

4
Our Products

• Hospitals Equipments
• Biofit Chairs
• HVAC Equipment
• Cleanroom Products
• Cleanroom Equipment

5
Utopias Cleanroom Partition

• UTOPIA cleanroom partition wall systems are an
  innovative and easy for installation wall system.
  The system is specially designed for
  pharmaceutical, hospital Biotech industrial
  cleanroom environment.
• An ultra-thin partition type air purifier.
  Depending on the air flow, there are clean
  specifications and decontamination
  specifications. It can be used for various
  purposes such as improving indoor cleanliness,
  installing it on a workbench as a clean bench, as
  an exhaust bench, or mounting it on the ceiling
  as an FFU. BSL4.

6
Charecteristics

• It is possible to select out of clean TYPE (A-B
  TYPE) and removing contamination type (C-D TYPE).
• It is possible to install CLEAN PARTITION with
  independence, or on wall and ceiling.
• It is easy to make up clean room, germ-free room
  and infection preventive room with CLEAN
  PARTITION.
• It is possible to substitute CLEAN PARTITION for
  CLEAN BENCH. (Table and hood are options).

7
Charecteristics

• Thin and Space-saving (The depth of main body is
  about 60mm).
• Noise-less (37 phone at low speed).
• It is possible to remove a stench with active
  carbon filter.
• CLEAN PARTITION is useful for a waiting room,
  office and so on. (Useful for a ward and
  consulting room). BSL4.

8
Hospital Equipment Clean Partition
9
Specifications
ACP-897AH / ACP-897BH (Clean Specification) ACP-897AH / ACP-897BH (Clean Specification)
Model ACP-897AH / ACP-897BH (clean specification)
Dust collection efficiency 99.99 or more with 0.3 µm particles
Dust collecting element Main filter HEPA filter Pre-filter Saran net processed product
Power supply AC100V 1f 50 / 60Hz
Weight About 40 kg
Construction Steel plate baking finish
10
Specifications
ACP-897AH / ACP-897BH (Clean Specification) ACP-897AH / ACP-897BH (Clean Specification)
Air volume setting mode Large air volume / strong / weak / quiet
Processing air volume (m³ /min) About 12.5 / about 6.5 / about 5.0 / about 4.0 / about 3.0
Wind speed (m / sec) About 0.50 / about 0.26 / about 0.20 / about 0.16 / about 0.12
Noise (dBA) About 58 / about 45 / about 43 / about 40 / about 36
Power consumption (W) About 90 / about 25 / about 17 / about 11 / about 7
Installed power About 145VA
11
Specifications
ACP-897CH / ACP-897DH (Decontamination Specifications) ACP-897CH / ACP-897DH (Decontamination Specifications)
Model ACP-897CH / ACP-897DH (decontamination specifications)
Dust collection efficiency 99.99 or more with 0.3 µm particles
Dust collecting element Main filter HEPA filter Pre-filter Saran net processed product
Power supply AC100V 1f 50 / 60Hz
Weight About 43 kg
Construction Steel plate baking finish
12
Specifications
ACP-897CH / ACP-897DH (Decontamination Specifications) ACP-897CH / ACP-897DH (Decontamination Specifications)
Air volume setting mode Large air volume / strong / weak / quiet
Processing air volume (m³ /min) About 11.5 / about 6.5 / about 5.0 / about 4.0 / about 3.0
Blow-out wind speed (m / sec) About 0.46 / about 0.26 / about 0.20 / about 0.16 / about 0.12
Noise (dBA) About 58 / about 45 / about 43 / about 40 / about 36
Power consumption (W) About 90 / about 25 / about 17 / about 11 / about 7
Installed power About 145VA
13
About Us

• Utopia is all geared up for this exciting
  challenge. In our organisation, we practice
  quality like a religion. From our micro level, we
  hope our contribution will benefit the macro
  level on the world stage, in order that one and
  all, we will progress towards harmony, mutual
  understanding and better way of life.
• Preferred clean room service company offering
  high quality clean room services at affordable
  prices.
• To know more details visit https//www.utopia.com.
  sg
