ALIGN
ALIGN TECHNOLOGIES COIMBATORE
2
Autodesk POWERSHAPE Align Technologies
Coimbatore
3
Autodesk POWERSHAPE

• PowerShape CAD software
  combines surface, solid and mesh modelling to
  help engineers prepare moulds, dies and other
  complex parts for manufacture. Ideal for use with
  PowerMill CAM software. CAD software for complex
  parts, electrode design, and modeling for
  manufacture it is also helps manufacturers
  import, fix, and prepare complex models in
  readiness for CNC machining. Use PowerShape as a
  modeling companion to get more from PowerMill CAM
  software.

4
Features of POWERSHAPE

• Cam Modelling Companion
• Create additional geometry
  to use inside PowerMill and get enhanced control
  of your CNC machinery.
• Imported CAD Data Repair
• Prepare third-party CAD
  models for manufacture. Find and repair common
  faults with ease using automatic wizards.
• Tolerant Solid Modelling
• Access solid modelling
  tools designed for real-world manufacturing
  problems. Quickly make whole model edits on
  imperfect data.
• Flexible Surface Modelling
• Produce complex surface
  geometry using Smart Surface. Make precise edits
  to create the manufacturing surfaces you need.

5
10 REASONS TO CHOOSE POWERSHAPE

• Import models from all mainstream CAD design
  systems.
• Find and repair critical faults that could
  complicate downstream processes.
• Use modeling tools specifically designed to help
  mould and die manufacturers.
• Carry on working, even if the imported CAD model
  is not perfect.
• Work with any combination of surfaces, solids and
  large STL meshes.
• Split models into cavity, core and slides using a
  simple wizard.
• Manage the design, manufacture and utilization of
  electrodes for EDM.
• Connect directly to scanning hardware for reverse
  engineering.
• Reverse engineer complex parts using powerful
  point-cloud and mesh modeling.
• Send finished models directly to PowerMill or
  FeatureCAM for machining

6
