Palletizing Sysem

1
Leading manufacturer of filling machines for
liquid and pasty products combined with storage
system, conveyors or palletizing system.
2
Table of Content

• Feige Filling Technology - Introduction
• Degree of Automation
• Palletizing Systems
• Types of Palletizing Systems
• Palletizing Robot

3
Feige Filling Technology

• Leading manufacturer of filling machines for
  liquid and pasty products. Whatever type of
  container you fill, we have a system for you...
  from semi-automatic filling station up to fully
  automatic filling plant for liquid and pasty
  products combined with storage system, conveyors
  or palletizing system.
• Use our technology to fill
• Drum fillers and other containers from 5 to 300
  kg
• Pail fillers, can fillers, hobbock and other
  containers up to 40 kg
• IBC, drums and other containers on pallets -
  pallet fillers.

4
Degree of Automation
5
Degree of Automation
6
Degree of Automation
7
Palletizing Systems
8
Palletizing Systems

• Palletizer is mechanized equipment that is used
  to load products onto a pallet. Because manual
  pallet loading can be a time-consuming task and
  creates unusual stress. The palletizing equipment
  can work with different applications such as
  boxes, cases, bags, pails, drums, buckets or
  bundles, etc,...

9
Palletizing Systems

• Types
• Palletizing robot for drums and containers
• Push palletizer for drums Type FP-S
• Vacuum palletizer for drums Type FP-VH
• Push palletizer for containers Type FP-SB
• Empty pallet magazine Type LPM

10
Palletizing Robot for Drums and Containers

• Using a palletizing robot is the best option for
  palletizing different container sizes, for
  changing pallet schemes, pallet sizes and
  container arrangements on the pallet. The
  palletizing robot is a flexible, forward-looking
  and extremely efficient solution (about 500
  cycles per hour). Reliability is another bonus to
  using palletizers. The palletizing machine offers
  great flexibility in handling numerous lines and
  pallet patterns. There are different palletizers
  available for different industrial applications.

11
Palletizing Robot for Drums and Containers
12
Palletizing Robot for Drums and Containers

• The robot depalletizes the empty drums, lifts the
  lids, places the drums on the roller conveyor and
  stacks the lids.

13
Palletizing Robot for Drums and Containers

• The robot takes a pallet out of the magazine and
  places it on the out-feed conveyor.

14
Palletizing Robot for Drums and Containers

• Oval pails are filled and closed on the filling
  line. Afterwards, the robot palletizes the pails
  as per pre-set pallet scheme.

15
Palletizing Robot for Drums and Containers

• Combination Tools
• Combination tools with grippers, suction pads,
  clamps and dedicated sensor technology handle
  most different containers and pallets.

16
Conclusion

• Palletizing robot offers quick cycle times with
  high performance. So using a palletizing robot
  can easier and speed up the palletization of
  products such as drums, pails, and containers,
  etc... Required software will be configured as
  per dedicated application, factory tested and
  optimized.
• For more information on how palletizing robot can
  benefit your own unique project, contact us _at_
  feigesgp_at_singnet.com.sg
