Palletizing Systems for Drums

1
Leading manufacturer of filling machines for
liquid and pasty products combined with storage
system, conveyors or palletizing system.
2
Table of Content

• Feige Filling Technology - Introduction
• Degree of Automation
• Palletizing Systems
• Types of Palletizing Systems
• Palletizing Systems For Drums
• Benefits of Using Palletizng Systems

3
Feige Filling Technology

• Leading manufacturer of filling machines for
  liquid and pasty products. Whatever type of
  container you fill, we have a system for you...
  from semi-automatic filling station up to fully
  automatic filling plant for liquid and pasty
  products combined with storage system, conveyors
  or palletizing system.

4
Degree of Automation
5
Degree of Automation
6
Degree of Automation
7
Palletizing Systems
8
Palletizing Systems

• Palletizer is mechanized equipment that is used
  to load products onto a pallet. Because manual
  pallet loading can be a time-consuming task and
  creates unusual stress. The palletizing equipment
  can work with different applications such as
  boxes, cases, bags, pails, drums, buckets or
  bundles, etc,...

9
Palletizing Systems

• Types
• Push palletizer for drums Type FP-S
• Vacuum palletizer for drums Type FP-VH
• Push Palletizer for containers Type FP-SB
• Empty pallet magazine Type LPM
• Palletizing robot for drums and containers

10
Palletizing Systems for Drums

• Push Palletizer
• Vacuum Palletizer

11
Push Palletizer for Drums Type FP-S
12
Push Palletizer for Drums Type FP-S

• Plates are moved above the pallet and lowered.
• A motor driven pusher pushes the first row of
  containers above the plate to its palletizing
  position.
• The plate withdraws by the size of one container
  row. The pusher returns to its initial position.
• The following rows are transferred as described
  above.

13
Vacuum Palletizer for Drums Type FP-VH
14
Vacuum Palletizer for Drums Type FP-VH

• A gripper with vacuum pads lifts rows of filled
  drums from the roller conveyor, moves them over
  the pallet and places them down according to the
  pallet arrangement scheme.

15
Palletizing System - Benefits

• It improve business operations.
• It allows pallets to be lifted and organized in
  the most efficient way.
• The major benefit of palletization is safety,
  reliability, and flexibility.
• Palletizing systems require only low maintenance.
• Faster loading and unloading.
• Reduced labor cost.
• Less risk of product damage.
• Reduced risk of worker injury.
• Easy Handling.
• Highly Efficient.

16
Conclusion

• Using a palletizing system can easier and speed
  up the palletization of products such as drums,
  pails, and containers, etc...
• For more information on how palletizing system
  can benefit your own unique project, contact us _at_
  feigesgp_at_singnet.com.sg

17
Thank You
